Sharp CD-MD3000H Service Manual

CD-MD3000H/CD-MD3000W
– 24 –
Figure 24
31
TRAY BIG GEAR
31
TRAY BIG GEAR
37
TRAY GEAR C
38
TRAY IDLER GEAR
37
TRAY GEAR C
38
TRAY IDLER GEAR
47
STB GEAR C
47
STB GEAR C
46
STB GEAR B
46
STB GEAR B
10
STB DRIVE GEAR A
29
01
MAIN BASE
29
23
23
24
25
26
27
Mark position
03
STB HOLDER
48
STB GEAR D
12
STB DRIVE GEAR R
(ASS'Y)
11
STB DRIVE GEAR L
(ASS'Y)
11(/12) (10)
STB DRIVE GEAR L(/R)
(ASS'Y)
10
STB DRIVE GEAR A
45
STB GEAR A
45
STB GEAR A
53
STB GEAR ANG.
53
STB GEAR ANG.
After assembling TRAY BIG GEAR, turn it in the arrow direction.
TRAY BIG GEAR ASSEMBLING POSITION
