Sharp CD-SW200 Service Manual

CD-SW200
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
!
F802 QFS-D502BSJNI AE Fuse,5A/125V
!
F803 QFS-D202BSJNI AB Fuse,2A/125V
!
F804 QFS-D202BSJNI AB Fuse,2A/125V
!
F805 QFS-D802BSJNI AC Fuse,8A/125V
FFC1 QCNWN2700AWPZ AE Flat Cable,16Pin
FFC4 QCNWN2701AWPZ AD Flat Cable,11Pin
FFC701 QCNWNA128AWPZ AF Flat Cable,20Pin
FFC702 QCNWN2495AWZZ AD Flat Cable,7Pin
FFC704 QCNWN2717AWPZ AF Flat Cable,14Pin
FL701 VVKNA12MM54-1 AU FL Display
FW901 QCNWN2711AWPZ AD Flat Wire,5Pin
JK690 QSOCJ0313AWZZ AF Jack,Game Input
JK691 QSOCJ0120AWZZ AD Jack,Video Out
JK692 QJAKM0004AWZZ AK Jack,Headphones
JOG701 QSW-ZA001AWZZ AE Switch,Jog Type [Volume]
LG1 QLUGP0001AWZZ AC Lug
LG2 QLUGP0001AWZZ AC Lug
LG3 QLUGP0001AWZZ AC Lug
LG4 QLUGP0001AWZZ AC Lug
LG5 QLUGP0001AWZZ AC Lug
LG6 QLUGP0001AWZZ AC Lug
M1 92LMTR5529AASY AD Motor with Gear [Tray]
M2 92LMTR5529AASY AD Motor with Gear [Main Cam]
M901 RMOTV0059AWZZ AL Motor,Fan
NM1 92LMTR5515CASY AS Motor with Chassis [Spindle]
NM2 92LMTR1854BASY AP Motor with Gear [Sled]
NSW1 QSW-F9001AW01 AD Switch,Push Type [Pickup In]
RL890 RRLYD0018AWZZ AH Relay
RL901 RRLYD0016AWZZ AH Relay
RL902 RRLYD0016AWZZ AH Relay
RX1 VHPGP1S094HCZ AF Photo Interrupter
RX701 VHLK603TH2E-1 AG Remote Sensor
SO302 QTANC0206AWZZ AD FM Terminal
SO901 QTANA0424AWZZ AE Terminal,Speaker
SO902 QTANAA005AWZZ AD Terminal,Subwoofer
SW1 QSW-P9003AWZZ AD Switch,Push Type [Clamp]
SW2 QSW-P9003AWZZ AD Switch,Push Type [Tray SW1]
SW3 QSW-P9003AWZZ AD Switch,Push Type [Tray SW2]
SW4 QSW-P9006AWZZ AF Switch,Push Type [Disc]
SW701 92LSWICHT1663T AC Switch,Key Type [Power On/Stand-by]
SW702 92LSWICHT1663T AC Switch,Key Type [Clock/Timer]
SW703 92LSWICHT1663T AC Switch,Key Type [Tuning Up]
SW704 92LSWICHT1663T AC Switch,Key Type [Tuning Down]
SW705 92LSWICHT1663T AC Switch,Key Type [Fast Rewind/Preset Down]
SW706 92LSWICHT1663T AC Switch,Key Type [Equalizer]
SW707 92LSWICHT1663T AC Switch,Key Type [Fast Forward/Preset Up]
SW712 92LSWICHT1663T AC Switch,Key Type [Tuner (Band)]
SW713 92LSWICHT1663T AC Switch,Key Type [CD]
SW714 92LSWICHT1663T AC Switch,Key Type [Tape]
SW715 92LSWICHT1663T AC Switch,Key Type [Game/Video]
SW716 92LSWICHT1663T AC Switch,Key Type [X-Bass/Demo]
SW724 92LSWICHT1663T AC Switch,Key Type [Play]
SW725 92LSWICHT1663T AC Switch,Key Type [Stop]
SW726 92LSWICHT1663T AC
Switch,Key Type [Rec./Pause]
SW727 92LSWICHT1663T AC Switch,Key Type [Memory/Set]
SW728 92LSWICHT1663T AC Switch,Key Type [Open/Close]
SW729 92LSWICHT1663T AC Switch,Key Type [Direct Play]
SW730 92LSWICHT1663T AC Switch,Key Type [Disc 2]
SW731 92LSWICHT1663T AC Switch,Key Type [Disc 4]
SW732 92LSWICHT1663T AC Switch,Key Type [Disc 5]
SW733 92LSWICHT1663T AC Switch,Key Type [Disc 3]
SW734 92LSWICHT1663T AC Switch,Key Type [Disc 1]
WTM901 QCNCW019EAWZZ AB Socket,5Pin
[11] OTHER CIRCUITRY PARTS
