Sharp CD-SW200 Service Manual

CD-SW200
13
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
R954 VRD-RT2HD152J AA 1.5 kohms,1/2W
R955 VRD-RT2HD152J AA 1.5 kohms,1/2W
R956 VRS-CY1JB563J AA 56 kohms,1/16W
R957 VRS-CY1JB563J AA 56 kohms,1/16W
R958 VRS-CY1JB563J AA 56 kohms,1/16W
R959 VRD-RT2HD100J AA 10 ohm,1/2W
R960 VRD-RT2HD100J AA 10 ohm,1/2W
R961 VRD-RT2HD100J AA 10 ohm,1/2W
R962 VRD-RT2HD100J AA 10 ohm,1/2W
R963 VRS-VV3DA391J AC 390 ohms,2W
R964 VRS-VV3DA391J AC 390 ohms,2W
R965 VRS-CY1JB473J AA 47 kohms,1/16W
R966 VRS-CY1JB102J AA 1 kohm,1/16W
R967 VRS-VV3DA391J AC 390 ohms,2W
R968 VRS-VV3DA391J AC 390 ohms,2W
R969 VRS-CY1JB152J AA 1.5 kohms,1/16W
R970 VRS-CY1JB152J AA 1.5 kohms,1/16W
R971 VRS-CY1JB152J AA 1.5 kohms,1/16W
R972 VRS-CY1JB152J AA 1.5 kohms,1/16W
R973 VRD-RT2HD102J AA 1 kohm,1/2W
R974 VRS-CY1JB153J AA 15 kohms,1/16W
R975 VRS-CY1JB683J AA 68 kohms,1/16W
R977 VRD-ST2EE221J AA 220 ohms,1/4W
R987 VRS-CY1JB333J AA 33 kohms,1/16W
R988 VRS-CY1JB562J AA 5.6 kohms,1/16W
R989 VRS-CY1JB153J AA 15 kohms,1/16W
RD01 VRS-CY1JB681J AA 680 ohms,1/16W
RD02 VRS-CY1JB821J AA 820 ohms,1/16W
RD03 VRS-CY1JB102J AA 1 kohm,1/16W
RD04 VRD-ST2CD152J AA 1.5 kohms,1/6W
RD05 VRD-ST2CD222J AA 2.2 kohms,1/6W
RD06 VRD-ST2CD272J AA 2.7 kohms,1/6W
RD11 VRS-CY1JB681J AA 680 ohms,1/16W
RD12 VRS-CY1JB821J AA 820 ohms,1/16W
RD13 VRD-ST2CD102J AA 1 kohm,1/6W
RD14 VRS-CY1JB152J AA 1.5 kohms,1/16W
RD22 VRS-CY1JB681J AA 680 ohms,1/16W
RD23 VRD-ST2CD821J AA 820 ohms,1/6W
RD24 VRD-ST2CD102J AA 1 kohm,1/6W
RD25 VRD-ST2CD152J AA 1.5 kohms,1/6W
RD26 VRS-CY1JB222J AA 2.2 kohms,1/16W
RD27 VRS-CY1JB272J AA 2.7 kohms,1/16W
RD28 VRS-CY1JB392J AA 3.9 kohms,1/16W
RD29 VRS-CY1JB562J AA 5.6 kohms,1/16W
RD30 VRS-CY1JB103J AA 10 kohm,1/16W
RD31 VRS-CY1JB153J AA 15 kohms,1/16W
[11] OTHER CIRCUITRY PARTS
BI601 QCNWNA261AWPZ AG Connector Ass'y,8/7Pin with CNS601
BI603 QCNWN2714AWPZ AK Connector Ass'y,6/5Pin with CNS603
BI701 QCNWNA264AWPZ AF Connector Ass'y,5/4Pin with CNS701
BI701 92LCONE7P53253 AC Plug,7Pin
BI705 QCNWNA267AWPZ AF Connector Ass'y,7/6Pin with CNS705
BI801 QCNWN2713AWPZ AH Connector Ass'y,11/10Pin
CNP1 QCNCWYP16AWZZ AD Socket,16Pin
CNP2 92LCONE6P53253 AC Plug,6Pin
CNP2A 92LCONE6P53254 AC Plug,6Pin
CNP3 92LCONE7P53254 AB Plug,7Pin
CNP4 QCNCWZX11AWZZ AC Socket,11Pin
CNP4A QCNCWZO11AWZZ AC Socket,11Pin
CNP5 92LCONE4P53254 AC Plug,4Pin
CNP6 QCNCM704GAFZZ AC Plug,7Pin
CNP7 QCNCWZY14AWZZ AD Socket,14Pin
CNP101 QCNCM705CAFZZ AA Plug,3Pin
CNP102 QCNCM705GAFZZ AB Plug,7Pin
CNP301 92LCONE2P5268 AB Plug,2Pin
CNP303 QCNCM010PAWZZ AD Plug,14Pin
CNP501 QCNCM704BAFZZ AA Plug,2Pin
CNP502 QCNCM705BAFZZ AA Plug,2Pin
CNP603 92LCONE5P53253 AB Plug,5Pin
CNP701
A
QCNCWZY20AWZZ AG Socket,20Pin
CNP701
B
QCNCWZX20AWZZ AG Socket,20Pin
CNP702 QCNCWZY07AWZZ AC Socket,7Pin
CNP704 QCNCWZY14AWZZ AD Socket,14Pin
CNP801 92LCONEAP5267 AC Plug,10Pin
CNP802 92LCONE6P53253 AC Plug,6Pin
CNP901 QCNCW012EAWZZ AC Socket,5Pin
CNP971 92LCONE2P53253 AB Plug,2Pin
CNS2A/
B
QCNWN2699AWPZ AF Connector Ass'y,6/6Pin
CNS303 QCNCW010PAWZZ AE Socket,14Pin
CNS971 QCNWNA080AWPZ AC Connector Ass'y,2Pin
!
F801 QFS-D502BSJNI AE Fuse,5A/125V
[10] RESISTORS
