CD-SW200

NO. PARTS CODE

PRICE

RANK

NEW

MARK

PART

RANK

DESCRIPTION

[1] INTEGRATED CIRCUITS

IC1 VHILC78690E-1 BE CD Servo,LC78690E

IC2 VHILA6261//-1 AN Focus/Tracking/Spin/Sled Driver,LA6261

IC101 VHIAN7345K/-1 AM Playback and Record/Playback Amp.,AN7345K

IC301 VHITA7358AP-1 AG FM Front End,TA7358AP

IC302 VHILC72131/-1 AP PLL (Tuner),LC72131

IC303 VHILA1832S/-1 AN FM IF Det./FM Mpx./AM IF,LA1832S

IC503 VHIKIA4558F-1 AF Pre Amp.,KIA4558F

IC601 VHILC75341/-1 AM Audio Processor,LC75341

IC603 RH-IXA043AWZZ AR Sound IC,IXA043AW

IC701 RH-IXA056AWZZ AY System Microcomputer,IXA056AW

IC802 VHIKIA78L05-1 AF Voltage Regulator,KIA78L05

IC805 VHIKIA7805AP1 AF Voltage Regulator,KIA7805AP

IC806 VHIKIA7810AP1 AF Voltage Regulator,KIA7810AP

IC807 VHIKIA7812AP1 AF Voltage Regulator,KIA7812AP

IC808 VSKTC2026//-1 AF Silicon,NPN,KTC2026

IC901 VHISTK41241-1 BA Power Amp.,STK41241

IC902 VHISTK41241-1 BA Power Amp.,STK41241

[2] TRANSISTORS

Q1 VSKTA1504Y/-1 AB Silicon,PNP,KTA1504 Y

Q2 VSKTA1271Y/-1 AC Silicon,PNP,KTA1271 Y

Q3 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q4 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q101 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q102 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q103 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q104 VSKTC3200GR-1 AC Silicon,NPN,KTC3200 GR

Q105 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q106 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q107 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q108 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q109 VSKTA1504Y/-1 AB Silicon,PNP,KTA1504 Y

Q110 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q111 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q112 VSKTA1266GR-1 AB Silicon,PNP,KTA1266 GR

Q113 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q114 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q302 VSKTC3194Y/-1 AD Silicon,NPN,KTC3194 Y

Q360 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR

Q502 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q503 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q505 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q506 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q601 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q602 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q603 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q604 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q605 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q606 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q607 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q608 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q612 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q663 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q664 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q665 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q702 VSKRC102S//-1 AB Digital,NPN,KRC102 S

Q703 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q704 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q705 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q706 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q707 VSKRA107S//-1 AB Digital,NPN,KRA107 S

Q708 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q709 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q710 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q711 VSKTA1273Y/-1 AE Silicon,PNP,KTA1273 Y

Q712 VSKRC102S//-1 AB Digital,NPN,KRC102 S

Q713 VSKRC104S//-1 AC Digital,NPN,KRC104 S

Q801 VSKTA1274Y/-1 AE Silicon,PNP,KTA1274 Y

Q804 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q805 VSKTC3875GR-1 AB

Silicon,NPN,KTC3875 GR

Q890 VSKTC3199GR-1 AB Silicon,NPN,KTC3199 GR

Q901 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q902 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q903 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q904 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q905 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q906 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q907 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q908 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR

Q909 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q910 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y

Q911 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
