Sharp CD-SW200 Service Manual

CD-SW200
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[3] DIODES
D1 VHDKDS184//-1 AB Silicon,KDS184
D301 VHD1N4148H/-1 AA Silicon,1N4148H
D302 VHD1N4148H/-1 AA Silicon,1N4148H
D305 VHD1N4148H/-1 AA Silicon,1N4148H
D501 VHD1N4148H/-1 AA Silicon,1N4148H
D503 VHD1N4148H/-1 AA Silicon,1N4148H
D504 VHD1N4148H/-1 AA Silicon,1N4148H
D505 VHD1N4148H/-1 AA Silicon,1N4148H
D506 VHD1N4148H/-1 AA Silicon,1N4148H
D508 VHD1N4148H/-1 AA Silicon,1N4148H
D690 VHD1N4148H/-1 AA Silicon,1N4148H
D691 VHD1N4148H/-1 AA Silicon,1N4148H
D701 VHD1N4148H/-1 AA Silicon,1N4148H
D704 VHD1N4148H/-1 AA Silicon,1N4148H
D706 VHD1N4148H/-1 AA Silicon,1N4148H
D707 VHD1N4148H/-1 AA Silicon,1N4148H
D708 VHD1N4148H/-1 AA Silicon,1N4148H
D709 VHD1N4148H/-1 AA Silicon,1N4148H
D710 VHD1N4148H/-1 AA Silicon,1N4148H
D711 VHD1N4148H/-1 AA Silicon,1N4148H
D712 VHD1N4148H/-1 AA Silicon,1N4148H
D713 VHD1N4148H/-1 AA Silicon,1N4148H
D801 VHDD20XB60F-1 AP Silicon,D20XB60F
D802 VHDD10XB60F-1 AL Silicon,D10XB60F
D803 VHDRL204F//-1 AC Silicon,RL204F
D804 VHDRL204F//-1 AC Silicon,RL204F
D805 VHDDS1N404S-1 AB Silicon,DS1N404S
D806 VHDDS1N404S-1 AB Silicon,DS1N404S
D808 VHD1N4148H/-1 AA Silicon,1N4148H
D811 VHD1N4148H/-1 AA Silicon,1N4148H
D813 VHD1N4148H/-1 AA Silicon,1N4148H
D814 VHD1N4148H/-1 AA Silicon,1N4148H
D815 VHD1N4148H/-1 AA Silicon,1N4148H
D816 VHD1N4148H/-1 AA Silicon,1N4148H
D817 VHD1N4148H/-1 AA Silicon,1N4148H
D818 VHDDS1N404S-1 AB Silicon,DS1N404S
D819 VHDDS1N404S-1 AB Silicon,DS1N404S
D821 VHD1N4148H/-1 AA Silicon,1N4148H
D853 VHDDS1N404S-1 AB Silicon,DS1N404S
D890 VHDDS1N404S-1 AB Silicon,DS1N404S
D891 VHDDS1N404S-1 AB Silicon,DS1N404S
D892 VHDDS1N404S-1 AB Silicon,DS1N404S
D893 VHDDS1N404S-1 AB Silicon,DS1N404S
D894 VHD1N4148H/-1 AA Silicon,1N4148H
D901 VHD1N4148H/-1 AA Silicon,1N4148H
D902 VHD1N4148H/-1 AA Silicon,1N4148H
D903 VHD1N4148H/-1 AA Silicon,1N4148H
D904 VHD1N4148H/-1 AA Silicon,1N4148H
D905 VHD1N4148H/-1 AA Silicon,1N4148H
D906 VHD1N4148H/-1 AA Silicon,1N4148H
D907 VHD1N4148H/-1 AA
Silicon,1N4148H
D908 VHD1N4148H/-1 AA Silicon,1N4148H
D909 VHD1N4148H/-1 AA Silicon,1N4148H
D910 VHD1N4148H/-1 AA Silicon,1N4148H
D911 VHDDS1N404S-1 AB Silicon,DS1N404S
D912 VHDDS1N404S-1 AB Silicon,DS1N404S
D913 VHDDS1N404S-1 AB Silicon,DS1N404S
D914 VHDDS1N404S-1 AB Silicon,DS1N404S
LED503 VHPSDPB40F2A- AK LED,Blue,SDPB40F2A
LED505 VHPSDPB40F2A- AK LED,Blue,SDPB40F2A
LED701 VHPSDPB50CD-1 AK LED,Blue,SDPB50CD
LED702 VHPSLR342VCB1 AC LED,Red,SLR342VCB1
ZD351 VHEDZ5R1BSB-1 AC Zener,5.1V,DZ5.1BSB
ZD801 VHEDZ7R5BSB-1 AB Zener,7.5V,DZ7.5BSB
ZD802 VHEDZ300BSB-1 AB Zener,30V,DZ30BSB
ZD803 VHEDZ6R2BSA-1 AB Zener,6.2V,DZ6.2BSA
ZD806 VHEDZ8R2BSB-1 AB Zener,8.2V,DZ8.2BSB
ZD901 VHEDZ150BSB-1 AB Zener,15V,DZ15BSB
ZD902 VHEDZ150BSB-1 AB Zener,15V,DZ15BSB
ZD903 VHEDZ150BSB-1 AB Zener,15V,DZ15BSB
ZD904 VHEDZ150BSB-1 AB Zener,15V,DZ15BSB
[4] FILTERS
BF301 RFILR0008AWZZ AE Band Pass Filter
CF303 RFILF0124AFZZ AD FM IF,10.7 MHz
CF351 RFILF0003AWZZ AK FM IF
CF352 RFILA0009AWZZ AE AM IF
