Sharp CD-SW200 Service Manual

CD-SW200
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
[5] TRANSFORMERS
!
PT801 RTRNPA020AWZZ BM Power
!
PT890 RTRNP0483AWZZ AL Power (Sub)
T301 RCILBA001AWZZ AC OSC
T302 RCILI0017AWZZ AB FM IF
T303 RCILA0052AWZZ AE AM Antenna
T306 RCILB0067AWZZ AD AM OSC
T351 RCILI0019AWZZ AD AM IF
[6] COILS
FB1 RBLN-0061TAZZ AB Ferrite Beads,BLM18AG121SN1D
FB2 RBLN-0061TAZZ AB Ferrite Beads,BLM18AG121SN1D
L103 VP-MK331K0000 AB 330 µ H,Choke
L312 RCILR0056AWZZ AB FM RF
L351 VP-DH101K0000 AB 100 µ H,Choke
L352 VP-DH101K0000 AB 100 µ H,Choke
L701 VP-DH101K0000 AB 100 µ H,Choke
L901 RCILZ0024AWZZ AC 3 µ H,Choke
L902 RCILZ0024AWZZ AC 3 µ H,Choke
L903 RCILZ0024AWZZ AC 3 µ H,Choke
L904 RCILZ0024AWZZ AC 3 µ H,Choke
[7] VARIABLE CAPACITORS
VD301 VHCSVC347S/-1 AG Variable Capacitance,SVC347S
VD302 VHCSVC230C/-1 AD Variable Capacitance,SVC230C
VD303 VHCSVC230C/-1 AD Variable Capacitance,SVC230C
[8] VIBRATORS
X351 92LCRSTL1425A AF Crystal,456 kHz
X352 RCRSP0019AWZZ AF Crystal,4.5 MHz
XL1 RCRM-0047AWZZ AE Ceramic,16.9344 MHz
XL701 RCRSP0029AWZZ AF Crystal,
[9] CAPACITORS
C1 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C2A VCKYTV1HB102K AA 0.001 µ F,50V
C3 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C4 VCKYPA1HB103K AA 0.01 µ F,50V
C5 VCEAZA1EW476M AB 47 µ F,25V,Electrolytic
C6 RC-EZ0004AWZZ AD 3.3 µ F,16V,Electrolytic
C7 VCKYPA1HB102K AA 0.001 µ F,50V
C8 VCEAZA1AW476M AB 47 µ F,10V,Electrolytic
C9 VCKYCY1HB103K AA 0.01 µ F,50V
C10 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C11 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C12 VCKYCY1HB272K AA 0.0027 µ F,50V
C13 VCKYCY1HB103K AA 0.01 µ F,50V
C14 VCKYCY1EF473Z AB 0.047 µ F,25V
C15 VCKYCY1CB563K AB 0.056 µ F,16V
C16 VCKYCY1HB103K AA 0.01 µ F,50V
C17 VCKYCY1CB563K AB 0.056 µ F,16V
C18 VCKYCY1HB103K AA 0.01 µ F,50V
C19 VCKYCY1CB104K AB 0.1 µ F,16V
C20 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C21 VCKYCY1CB104K AB 0.1 µ F,16V
C22 VCEAZA1AW477M AC 470 µ F,10V,Electrolytic
C23 VCKYCY1CB104K AB 0.1 µ F,16V
C24 VCKYCY1CB104K AB 0.1 µ F,16V
C25 VCEAZA1HW105M AB 1 µ F,50V,Electrolytic
C26 VCKYCY1EF473Z AB
0.047 µ F,25V
C27 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C28 VCKYCY1CB104K AB 0.1 µ F,16V
C29 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C30 VCKYCY1CB104K AB 0.1 µ F,16V
C31 VCKYCY1CB104K AB 0.1 µ F,16V
C32 VCKYCY1CB104K AB 0.1 µ F,16V
C33 VCKYCY1CB104K AB 0.1 µ F,16V
C34 VCKYCY1CB104K AB 0.1 µ F,16V
C35 VCEAZA1HW105M AB 1 µ F,50V,Electrolytic
C36 VCEAZA1AW107M AB 100 µ F,10V,Electrolytic
C37 VCKYCY1CB104K AB 0.1 µ F,16V
C40 VCKYCY1CB104K AB 0.1 µ F,16V
C41 VCEAZA1HW106M AB 10 µ F,50V,Electrolytic
C42 VCEAZA1HW106M AB 10 µ F,50V,Electrolytic
C43 VCKYPA1HB152K AA 0.0015 µ F,50V
C44 VCKYPA1HB152K AA 0.0015 µ F,50V
C45 VCKYCY1CB104K AB 0.1 µ F,16V
C46 VCEAZA1AW477M AC 470 µ F,10V,Electrolytic
C47 VCKYCY1EF473Z AB 0.047 µ F,25V
C48 VCKYCY1HB103K AA 0.01 µ F,50V
C49 VCKYCY1EF223Z AB 0.022 µ F,25V
C50 VCCCCY1HH101J AA 100 pF (CH),50V
C51 VCCCCY1HH101J AA 100 pF (CH),50V
C52 VCCCCY1HH101J AA 100 pF (CH),50V
C53 VCCCCY1HH101J AA 100 pF (CH),50V
