NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
Q910 VSKTC3203Y/-1 AC Silicon,NPN,KTC3203 Y
Q914 VSKTC3875GR-1 AB Silicon,NPN,KTC3875 GR
Q915 VSKTA1504GR-1 AB Silicon,PNP,KTA1504 GR
Q916 VSKRC104S//-1 AC Digital,NPN,KRC104 S
QX503 VSKRC107S//-1 AB Digital,NPN,KRC107 S
QX504 VSMMSS8550H-1 Silicon,MSS8550H
[3] DIODES
D1 VHDKDS184//-1 AB Silicon,KDS184
D501 VHDHSS4148+-1 AA Silicon,HSS4148
D503 VHDHSS4148+-1 AA Silicon,HSS4148
D504 VHDHSS4148+-1 AA Silicon,HSS4148
D505 VHDHSS4148+-1 AA Silicon,HSS4148
D506 VHDHSS4148+-1 AA Silicon,HSS4148
D508 VHDHSS4148+-1 AA Silicon,HSS4148
D510 VHDHSS4148+-1 AA Silicon,HSS4148
D511 VHDHSS4148+-1 AA Silicon,HSS4148
D512 VHDHSS4148+-1 AA Silicon,HSS4148
D603 VHD1N4004S/-1 AB Silicon,1N4004S
D604 VHD1N4004S/-1 AB Silicon,1N4004S
D605 VHD1N4004S/-1 AB Silicon,1N4004S
D607 VHDMA111///-1 AC Silicon,MA111
D611 VHDMA111///-1 AC Silicon,MA111
D612 VHDMA111///-1 AC Silicon,MA111
D613 VHDMA111///-1 AC Silicon,MA111
D614 VHDMA111///-1 AC Silicon,MA111
D701 VHDMA111///-1 AC Silicon,MA111
D702 VHDHSS4148+-1 AA Silicon,HSS4148
D705 VHD1N4004S/-1 AB Silicon,1N4004S
D706 VHDHSS4148+-1 AA Silicon,HSS4148
D707 VHDMA111///-1 AC Silicon,MA111
D708 VHDMA111///-1 AC Silicon,MA111
D712 VHDMA111///-1 AC Silicon,MA111
D714 VHD1N4004S/-1 AB Silicon,1N4004S
D715 VHDMA111///-1 AC Silicon,MA111
D720 VHDMA111///-1 AC Silicon,MA111
D721 VHDMA111///-1 AC Silicon,MA111
D722 VHDMA111///-1 AC Silicon,MA111
D801 VHDTS20P05G-1 AL Silicon,DTS20P05
D802 VHDD10XB60F-1 AL Rectifier,10XB60F
D803 VHDRL204F//-1 AC Silicon,DRL204F
D804 VHDRL204F//-1 AC Silicon,DRL204F
D805 VHD1N4004S/-1 AB Silicon,1N4004S
D806 VHD1N4004S/-1 AB Silicon,1N4004S
D817 VHDHSS4148+-1 AA Silicon,HSS4148
D818 VHD1N4004S/-1 AB Silicon,1N4004S
D819 VHD1N4004S/-1 AB Silicon,1N4004S
D842~D846 VHD1N4004S/-1 AB Silicon,1N4004S
D856 VHDHSS4148+-1 AA Silicon,HSS4148
D901 - D910 VHDHSS4148+-1 AA Silicon,HSS4148
D911 VHD1N4004S/-1 AB Silicon,1N4004S
D912 VHD1N4004S/-1 AB Silicon,1N4004S
D913 VHD1N4004S/-1 AB Silicon,1N4004S
D914 VHD1N4004S/-1 AB Silicon,1N4004S
D918 VHDHSS4148+-1 AA Silicon,HSS4148
D960 VHDHSS4148+-1 AA Silicon,HSS4148
D961 VHDHSS4148+-1 AA Silicon,HSS4148
D962 VHDHSS4148+-1 AA Silicon,HSS4148
D963 VHDHSS4148+-1 AA Silicon,HSS4148
DX505 VHDKDS226//-1 AB Silicon,KDS226
DX506 VHDKDS226//-1 AB Silicon,KDS226
LED503 VHPA343BD2S2Z AG LED,Blue,A343BD2S2Z ( SUB WOOFER LED PWB-H )
LED505 VHPA343BD2S2Z AG LED,Blue,A343BD2S2Z ( SUB WOOFER LED PWB-H )
LED701 VHPSLR342VCB1 AC LED,Red,SLR342VCB1 ( DISPLAY PWB-B1 )
LED702 VHPSDPB40F2AC AH LED,Blue,SDPB40F2A (FRONT SPEAKER LED PWB)
LED707 VHP503BC2E30Z AG LED,Blue,5mm,503BC2E30
ZD801 RH-EX0617GEZZ AB Zener,6.2V,DZ6.2
ZD802 RH-EX0624GEZZ AB Zener,7.5V,DZ7.5
ZD803 RH-EX0671GEZZ AB Zener,30V,DZ30
ZD901 RH-EX0640GEZZ AB Zener,12V,DZ12
ZD902 RH-EX0640GEZZ AB Zener,12V,DZ12
ZD903 RH-EX0640GEZZ AB Zener,12V,DZ12
ZD904 RH-EX0640GEZZ AB Zener,12V,DZ12
ZD905 RH-EX0637GEZZ AB Zener,11V,DZ11
ZD906 RH-EX0646GEZZ AB Zener,30V,DZ30
[4] TRANSFORMERS
!
PT801 RTRNPA041AWZZ BP Power (Main)
!
PT841 RTRNP0483AWZZ AL Power (Sub)
[5] COILS
FB1 RBLN-0061TAZZ AB Ferrite Beads,BLM18AG121SN1D
FB2 RBLN-0061TAZZ AB Ferrite Beads,BLM18AG121SN1D
FB504 RBLN-0210TAZZ Ferrite Bead
L103 VP-MK331K0000 AB 330 μ H,Choke
L505 VP-NM2R2M0000 2.2µ H,Peaking
L506 VP-NM2R2M0000 2.2µ H,Peaking
[2] TRANSISTORS
