Sharp CD-SW330 - Page 118

CD-SW330
13
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
CNP501 QCNCWXC18AFZZ AF Socket,18 Pin ( Use in XM Ready PWB-E )
CNP502 QCNCM705BAFZZ AA Plug,2Pin
CNP603 92LCONE5P53253 AB Plug,5Pin
CNP701 QCNCWYP28AWZZ AE Socket,28 Pin
CNP701A QCNCWYH28AWZZ Socket,28 Pin
CNP702 QCNCWZY10AWZZ AC Socket,10 Pin ( Use in Main PWB-B1 )
CNP702 QCNCWYP18AWZZ Socket,18 Pin ( Use in Main PWB-A1 )
CNP704 QCNCWZY07AWZZ AC Socket,7 Pin
CNP705 QCNCWZY12AWZZ AC Socket,12 Pin
CNP707 QCNCM704BAFZZ AA Plug,2Pin
CNP801 QCNCM035KAWZZ AG Plug,9Pin
CNP802 92LCONE6P53253 AC Plug,6Pin
!
CNP805 QCNCM049BAWZZ AC Plug,2Pin
CNP901 QCNCW012EAWZZ AC Socket,5Pin
CNP971 92LCONE2P53253 AB Plug,2Pin
CNS01 QCNCM704BAFZZ AA Plug,2Pin
CNS02 QCNCM704BAFZZ AA Plug,2Pin
CNS2A/B QCNWNA750AWPZ AG Connector Assy,4 / 4 Pin
CNS503A/B QCNWNA252AWZZ AG SUB WOOFER LED WIRE
CNS971 QCNWNA080AWPZ AC Connector Ass'y,2Pin
!
F801 QFS-D502BSJNI AE Fuse,5A/125V
!
F802 QFS-D502BSJNI AE Fuse,5A/125V
!
F803 QFS-D202BSJNI AB Fuse,2A/125V
!
F804 QFS-D202BSJNI AB Fuse,2A/125V
!
F805 QFS-D802BSJNI AC Fuse,8A/125V
FFC1 QCNWN2700AWPZ AE Flat Cable,16 Pin
FFC4 QCNWN2701AWPZ AD Flat Cable,11 Pin
FFC303 QCNWNA2525AWZZ AC Flat Cable,11 Pin
FFC701 QCNWNA808AWPZ Flat Cable,28 Pin
FFC702 QCNWNA810AWPZ Flat Cable,10 Pin ( Use in Main PWB-B1 )
FFC702 QCNWNA811AWPZ Flat Cable,18 Pin ( Use in Main PWB-A1 )
FFC704 QCNWN2495AWZZ AD Flat Cable,7 Pin
FFC705 QCNWNA809AWPZ Flat Cable,12 Pin
!
FH801~FH810 92LFSH0LD1652T AB Fuse Holder
FL701 VVKNA12MM59-1 FL Display
FW901 QCNWN2711AWPZ AD Flat Wire,5Pin
JK690 QSOCJ0313AWZZ AF Jack,Game Input
JK691 QSOCJ0120AWZZ AD Jack,Video Out
JK692 QJAKM0004AWZZ AK Jack,Headphones
JU501 QSOCZA009AWZZ Socket,4 Pin
LG1 QLUGPA001AWZZ AC Lug
LG2 QLUGPA001AWZZ AC Lug
LG3 QLUGPA001AWZZ AC Lug
LG4 QLUGPA001AWZZ AC Lug
LUG3 QLUGP0002AWZZ AB Lug
LUGWIRE QCNWNA139AWPZ AC Lug Wire
!
RL841 RRLYDA002AWZZ AF Relay
RL901 RRLYD0016AWZZ AH Relay
RL902 RRLYD0016AWZZ AH Relay
RX701 VHLK2013TH2E1 AG Remote Sensor
SO901 QTANA0424AWZZ AE Terminal,Speaker
SO902 QTANAA005AWZZ AD Terminal,Subwoofer
SW701 92LSWICH1401AT AC Switch,Key Type [Power On/Stand-by]
SW702 92LSWICH1401AT AC Switch,Key Type [Clock/Timer]
SW703 92LSWICH1401AT AC Switch,Key Type [Tuning Up]
SW704 92LSWICH1401AT AC Switch,Key Type [Tuning Down]
SW705 92LSWICH1401AT AC Switch,Key Type [Fast Rewind/Preset Down]
SW707 92LSWICH1401AT AC Switch,Key Type [Equalizer]
SW708 92LSWICH1401AT AC Switch,Key Type [Fast Forward/Preset Up]
SW709 92LSWICH1401AT AC Switch,Key Type [Tuner (Band)]
SW710 92LSWICH1401AT AC Switch,Key Type [CD]
SW711 92LSWICH1401AT AC Switch,Key Type [Tape]
SW712 92LSWICH1401AT AC Switch,Key Type [Game/Video]
SW713 92LSWICH1401AT AC Switch,Key Type [X-Bass/Demo]
SW714 92LSWICH1401AT AC Switch,Key Type [Play]
SW715 92LSWICH1401AT AC Switch,Key Type [Stop]
SW716 92LSWICH1401AT AC Switch,Key Type [Rec./Pause]
TP1 RTUNSA007AWZZ BA Tuner Pack
VR701 QSW-ZA001AWZZ AE Switch,Jog Type [Volume]
WIRE_B QCNWN2593AWZZ AB Single Wire,80 mm ( White )
WTM901 QCNCW019EAWZZ AB Socket,5Pin
[9] OTHER CIRCUITRY PARTS
