AFTER ASSEMBLY GEAR UP/DOWN BOARD
APPLY GREASE SC141 AT INNER & OUTER GEAR SLIDING PORTION
WHEN FIX GEAR UP/
DOWN BOARD THE
TWO LEVER MUST AT
PARALLEL LINE AND
POSITIONED AT TOP
MAX SIDE
111
23
GEAR UP/DOWN BOARD
