24
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
Q351 VS2PD601AR/-1 J 2PD601AR AB
Q401 VS2PD601AR/-1 J 2PD601AR AB
Q403 VS2PD601AR/-1 J 2PD601AR AB
Q404 VS2PB709AR/-1 J 2PB709AR AB
Q451 VS2PB709AR/-1 J 2PB709AR AB
Q501 VS2PD601AR/-1 J 2PD601AR AB
Q601 VS2SC2655Y/-1 J 2SC2655Y AE
å Q602 VS2SD2586//1E J 2SD2586 AM
Q603 VS2SC945AQ/-1 J 2SC945A(Q) AB
or
VS2SC1815YW-1
or
VS2SC3198-Y-1
Q752 VS2SC945AQ/-1 J 2SC945A(Q) AB
or
VS2SC1815YW-1
or
VS2SC3198-Y-1
Q753 VS2SA1013//1E J 2SA1013 AD
Q2001 VS2PD601AR/-1 J 2PD601AR AB
Q2002 VS2PD601AR/-1 J 2PD601AR AB
Q2060 VS2PD601AR/-1 J 2PD601AR AB
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D53 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D502 RH-DX0131CEZZ J Diode AC
D601 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D603 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D610 RH-DX0131CEZZ J Diode AC
D631 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D641 RH-EX0630GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
or
RH-EX0660GEZZ
or
RH-EX1311CEZZ
å D661 RH-DX0444CEZZ J Diode AH
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
D753 VHD1SS119//-1 J Diode AB
D754 VHD1SS119//-1 J Diode AB
D755 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D756 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D757 VHD1SS119//-1 J Diode AB
å D758 RH-DX0131CEZZ J Diode AC
å D760 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D761 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D762 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D763 VHD1SS119//-1 J Diode AB
D901 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D902 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D2001 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUITS
å PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0205CEZZ R Crystal AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0403CEZZ J Ceramic Filter AE
or
RFiLC0029TAZZ
CF401 RFiLC0013CEZZ J Ceramic Filter AE
or
RFiLC0004PEZZ
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0612CEZZ J IF Coil AE
or
RCiLi0588CEZZ
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J VCO Coil AE
L401 VP-XF120K0000 J Peaking 12µH AB
L402 VP-XF100K0000 J Peaking 10µH AB
L406 VP-XF680K0000 J Peaking 68µH AB
L408 VP-XF100K0000 J Peaking 10µH AB
å L701 RCiLF0029PEZZ R Coil AH
or
RCiLF0087CEZZ
or
RCiLF0235CEZZ
L2040 RCiLB0159CEZZ J Oscillation Coil AE
TRANSFORMERS
å T601 RTRNZ0168CEZZ J Transformer AH
çå T602 RTRNF0148PEZZ R H-Volt Transformer BD
or
RTRNF0151PEZZ
or
RTRNF0156PEZZ
å T701 RTRNP0527CEZZ J Power Transformer AM
or
RTRNP0518CEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V Tantalum AD
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW475M J 4.7 50V EL. AB
C55 VCEA0A1CW477M J 470 16V EL. AC
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW227M J 220 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C302 VCCCCY1HH330J J 33p 50V Ceramic AA
C303 VCKYCY1HB472K J 4700p 50V Ceramic AA
C304 VCEA0A1HW225M J 2.2 50V EL. AB
PWB-A : DUNTK9529WEW1(13L-M100/150)
PWB-A : DUNTK9529WEW3(CL13M10/15)
MAIN UNIT (Continued)
