Sharp CL13M10/15 User Manual

25
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
C305 VCKYPA1HB151K J 150p 50V Ceramic AA
C306 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW227M J 220 16V EL. AC
C312 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C314 VCEA0A1HW225M J 2.2 50V EL. AB
C351 VCKYCY1HB562K J 5600p 50V Ceramic AA
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 VCQYTA1HM104K J 0.1 50V Mylar AC
C355 VCEA0A1CW226M J 22 16V EL. AB
C361 VCEA0A1CW477M J 470 16V EL. AC
C362 VCEA0A1CW476M J 47 16V EL. AB
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C404 VCCCCY1HH680J J 68p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C407 VCQYTA1HM104K J 0.1 50V Mylar AC
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1.0 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA
C420 VCCCCY1HH471J J 470p 50V Ceramic AA
C451 VCQYTA1HM563K J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
C507 VCKYPA1HB102K J 1000p 50V Ceramic AA
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C513 VCEACA1HC225M J 2.2 50V EL. AC
C514 VCEACA1HC335J J 3.3 50V EL. AC
C517 VCKYCY1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum. AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C604 VCEA0A1CW227M J 220 16V EL. AC
çå C608 VCFPPD3CA522H J 5200p 1.6kV M-Poly. AE
C609 VCQYTA1HM223K J 0.022 50V Mylar AB
C612 VCFPPB2EB334J J 0.33 250V M-Poly. AF
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C633 VCEA0A1HW105M J 1.0 50V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ015SCEZZ J 0.047 AC125V Plastic AE
or
RC-FZ002SCEZZ
or
RC-FZ004SGEZZ
or
RC-FZ027CUMZZ
or
RC-FZ027SCEZZ
or
RC-FZ019SCEZZ
or
RC-FZ059SCEZZ
C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C704 VCKYPB2HE103P J 0.01 500V Ceramic AB
å C705 RC-EZ0422CEZZ J 470 200V EL. AN
or
RC-EZ0522CEZZ
å C706 RC-KZ0092GEZZ J 0.0033 AC125V Ceramic AC
or
RC-KZ0311CEZZ
C707 VCEAGA2CW226M J 22 160V EL. AD
å C712 RC-EZ0638CEZZ J 33 160V EL. AG
C751 VCEA0A1VW477M J 470 35V EL. AB
C754 VCEA0A1CW337M J 330 16V EL. AC
C755 VCEA0A1CW107M J 100 16V EL. AC
C756 VCEAGA1CW108M J 1000 16V EL. AD
C757 VCQYTA1HM104K J 0.1 50V Mylar AC
å C758 VCEAGA2EW106M J 10 250V EL. AC
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEAGA1CW108M J 1000 16V EL. AD
C801 VCQYTA1HM223K J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2051 VCCCCY1HH101J J 100p 50V Ceramic AA
C2060 VCQYTA1HM104K J 0.1 50V Mylar AC
C2061 VCKYD41HB101K J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2402 VCCCCY1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1HW475M J 4.7 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ3 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ5 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ6 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ7 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ9 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ10 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ15 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ17 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ18 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ19 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ20 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ21 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ23 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ24 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ26 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ31 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ32 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ35 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ39 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ40 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ46 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ49 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ52 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ54 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ55 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ57 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ59 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ62 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ63 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ66 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ67 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ68 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ69 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ71 VRN-MD2AL000J J 0 1/10W M-Film AA
PWB-A : DUNTK9529WEW1(13L-M100/150)
PWB-A : DUNTK9529WEW3(CL13M10/15)
MAIN UNIT (Continued)
