Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
RJ75 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ77 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ78 VRN-MD2AL000J J 0 1/10W M-Film AA
RJ79 VRN-MD2AL000J J 0 1/10W M-Film AA
å R51 VRS-VV3AB331J J 330 1W M-Ox. AA
å R52 VRS-VV3DB470J J 47 2W M-Ox. AA
å R53 VRS-VV3LB223J J 22k 3W M-Ox. AB
R54 VRN-MD2AL101J J 100 1/10W M-Film AA
R55 VRN-MD2AL101J J 100 1/10W M-Film AA
R56 VRN-MD2AL823J J 82k 1/10W M-Film AA
R57 VRN-MD2AL392J J 3.9k 1/10W M-Film AA
R201 VRN-MD2AL221J J 220 1/10W M-Film AA
R202 VRN-MD2AL122J J 1.2k 1/10W M-Film AA
R203 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R204 VRN-MD2AL270J J 27 1/10W M-Film AA
R205 VRD-RA2BE391J J 390 1/8W Carbon AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R208 VRN-MD2AL391J J 390 1/10W M-Film AA
R301 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R302 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R303 VRN-MD2AL153J J 15k 1/10W M-Film AA
R307 VRN-MD2AL333J J 33k 1/10W M-Film AA
R352 VRN-MD2AL332J J 3.3k 1/10W M-Film AA
R353 VRN-MD2AL4R7J J 4.7 1/10W M-Film AA
R354 VRN-MD2AL152J J 1.5k 1/10W M-Film AA
R361 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R364 VRN-MD2AL473J J 47k 1/10W M-Film AA
R401 VRN-MD2AL682J J 6.8k 1/10W M-Film AA
R403 VRD-RA2BE331J J 330 1/8W Carbon AA
R404 VRN-MD2AL391J J 390 1/10W M-Film AA
R407 VRN-MD2AL471J J 470 1/10W M-Film AA
R409 VRN-MD2AL471J J 470 1/10W M-Film AA
R410 VRD-RA2BE563J J 56k 1/8W Carbon AA
R411 VRN-MD2AL103J J 10k 1/10W M-Film AA
R412 VRD-RA2EE561J J 560 1/4W Carbon AA
R413 VRD-RA2BE470J J 47 1/8W Carbon AA
R414 VRD-RA2BE470J J 47 1/8W Carbon AA
R415 VRD-RA2BE470J J 47 1/8W Carbon AA
R416 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R417 VRD-RA2BE101J J 100 1/8W Carbon AB
R418 VRN-MD2AL152J J 1.5k 1/10W M-Film AA
R419 VRN-MD2AL472J J 4.7k 1/10W M-Film AA
R423 VRN-MD2AL222J J 2.2k 1/10W M-Film AA
R426 VRN-MD2AL271J J 270 1/10W M-Film AA
R440 VRN-MD2AL821J J 820 1/10W M-Film AA
å R451 VRS-SV2HC103J J 10k 1/2W M-Ox. AA
R452 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R454 VRD-RA2BE334J J 330k 1/8W Carbon AA
R455 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R456 VRN-MD2AL223J J 22k 1/10W M-Film AA
R457 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R458 VRD-RA2BE564J J 560k 1/8W Carbon AA
R459 VRD-RA2BE123J J 12k 1/8W Carbon AA
R504 VRD-RA2BE471J J 470 1/8W Carbon AA
R505 VRN-MD2AL101J J 100 1/10W M-Film AA
R506 VRD-RA2BE683G J 68k 1/8W Carbon AA
R507 VRD-RA2BE104G J 100k 1/8W Carbon AA
R508 VRD-RA2BE473J J 47k 1/8W Carbon AA
R510 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
å R511 VRN-SV2HB3R9J J 3.9 1/2W M-Film AB
R512 VRD-RM2HD681J J 680 1/2W Carbon AA
R516 VRD-RA2BE223G J 22k 1/8W Carbon AA
R517 VRD-RA2BE103G J 10k 1/8W Carbon AA
R518 VRD-RA2BE154J J 150k 1/8W Carbon AA
R524 VRN-MD2AL332J J 3.3k 1/10W M-Film AA
R525 VRD-RA2BE473J J 47k 1/8W Carbon AA
R552 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R553 VRN-MD2AL273J J 27k 1/10W M-Film AA
R554 VRN-MD2AL472J J 4.7k 1/10W M-Film AA
R555 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R556 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R602 VRD-RA2EE820J J 82 1/4W Carbon AA
å R603 VRS-VV3LB270J J 27 3W M-Ox. AB
R605 VRN-MD2AL332J J 3.3k 1/10W M-Film AA
R606 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R608 VRD-RA2BE101J J 100 1/8W Carbon AB
R609 VRD-RA2BE331J J 330 1/8W Carbon AA
å R610 VRS-VV3DB391J J 390 2W M-Ox. AA
R620 VRD-RA2BE473J J 47k 1/8W Carbon AA
R621 VRN-MD2AL682J J 6.8k 1/10W M-Film AA
R631 VRN-MD2AL391J J 390 1/10W M-Film AA
R632 VRN-MD2AL152J J 1.5k 1/10W M-Film AA
R633 VRN-MD2AL472J J 4.7k 1/10W M-Film AA
R634 VRD-RM2HD121J J 120 1/2W Carbon AA
å R641 VRS-VV3AB682J J 6.8k 1W M-Ox. AA
R642 VRD-RA2BE821J J 820 1/8W Carbon AA
çå R651 VRD-RM2HD1R0J J 1.0 1/2W Carbon AA
çå R654 VRD-RA2BE154J J 150k 1/8W Carbon AA
çå R655 VRN-MD2AL104J J 100k 1/10W M-Film AA
çå R656 VRN-MD2AL333J J 33k 1/10W M-Film AA
å R659 VRN-VV3AB1R8J J 1.8 1W M-Film AA
å R661 VRN-VV3ABR47J J 0.47 1W M-Film AA
å R701 RR-HZ0046CEZZ J 2.7M 1/2W Solid AD
or
RR-DZ0047CEZZ
or
VRC-UB2HG275K
å R702 VRW-KP3HC1R8K J 1.8 5W Cement AC
å R703 VRS-KA3NG561J J 560 7W M-Ox. AF
R704 VRD-RM2HD123J J 12k 1/2W Carbon AA
R705 VRD-RA2EE334J J 330k 1/4W Carbon AA
R706 VRD-RM2HD470J J 47 1/2W Carbon AA
å R707 VRN-VV3DB1R5J J 1.5 2W M-Film AB
å R708 VRD-RM2HD824J J 820k 1/2W Carbon AA
å R709 VRS-KA3NG561J J 560 7W M-Ox. AF
å R717 VRS-KA3HG3R3K J 3.3 5W M-Ox. AD
å R730 VRS-VV3DB270J J 27 2W M-Ox. AA
å R750 VRS-VV3AB561J J 560 1W M-Ox. AA
R752 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R754 VRN-MD2AL471J J 470 1/10W M-Film AA
å R755 VRS-VV3DB470J J 47 2W M-Ox. AA
R757 VRN-MD2AL472J J 4.7k 1/10W M-Film AA
å R758 VRS-SV2HC150J J 15 1/2W M-Ox. AA
R801 VRN-MD2AL332J J 3.3k 1/10W M-Film AA
R802 VRN-MD2AL332J J 3.3k 1/10W M-Film AA
R803 VRN-MD2AL182J J 1.8k 1/10W M-Film AA
R804 VRN-MD2AL182J J 1.8k 1/10W M-Film AA
R805 VRN-MD2AL182J J 1.8k 1/10W M-Film AA
R806 VRN-MD2AL333J J 33k 1/10W M-Film AA
R902 VRN-MD2AL750J J 75 1/10W M-Film AA
R906 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R925 VRN-MD2AL104J J 100k 1/10W M-Film AA
R961 VRN-MD2AL101J J 100 1/10W M-Film AA
R962 VRN-MD2AL101J J 100 1/10W M-Film AA
R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2002 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2006 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2007 VRD-RA2BE223J J 22k 1/8W Carbon AA
R2008 VRD-RA2BE224J J 220k 1/8W Carbon AA
R2009 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R2010 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R2011 VRN-MD2AL821J J 820 1/10W M-Film AA
R2012 VRN-MD2AL471J J 470 1/10W M-Film AA
R2020 VRD-RM2HD223J J 22k 1/2W Carbon AA
R2022 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2024 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2028 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2029 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R2032 VRN-MD2AL471J J 470 1/10W M-Film AA
R2033 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2040 VRN-MD2AL102J J 1.0k 1/10W M-Film AA
R2041 VRN-MD2AL333J J 33k 1/10W M-Film AA
R2042 VRN-MD2AL101J J 100 1/10W M-Film AA
R2043 VRN-MD2AL101J J 100 1/10W M-Film AA
R2044 VRN-MD2AL683J J 68k 1/10W M-Film AA
PWB-A : DUNTK9529WEW1(13L-M100/150)
PWB-A : DUNTK9529WEW3(CL13M10/15)
MAIN UNIT (Continued)
