Sharp CL13M10/15 User Manual

31
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
J903 QJAKE0159CEZZ J Jack, Audio IN AF
J905 QJAKE0158CEZZ J Jack, Video IN AF
P302 QPLGN0261CEZZ J Plug, 2-pin(S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin(K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0207CEZZ J Plug, 2-pin(M) AA
P751 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
RMC2601 RRMCU0227CEZZ J R/C Receiver AK
or
RRMCU0222CEZZ
HM601 LX-GZ3002PEZZ R Screw AB
HM602 LX-GZ3002PEZZ R Screw AB
HM705 LX-GZ3001PEZZ R Screw AB
HM706 LX-GZ3001PEZZ R Screw AB
HM707 LX-GZ3001PEZZ R Screw AB
HM708 LX-GZ3001PEZZ R Screw AB
HM711 LX-GZ3001PEZZ R Screw AB
HM712 LX-GZ3001PEZZ R Screw AB
HM713 LX-GZ3001PEZZ R Screw AB
HM714 LX-GZ3001PEZZ R Screw AB
HM715 LX-GZ3001PEZZ R Screw AB
HM716 LX-GZ3001PEZZ R Screw AB
HM717 LX-GZ3001PEZZ R Screw AB
HM718 LX-GZ3001PEZZ R Screw AB
HM719 LX-GZ3001PEZZ R Screw AB
HM720 LX-GZ3001PEZZ R Screw AB
HM722 LX-GZ3002PEZZ R Screw AB
HM724 LX-GZ3002PEZZ R Screw AB
HM726 LX-GZ3002PEZZ R Screw AB
HM729 LX-GZ3001PEZZ R Screw AB
HM730 LX-GZ3001PEZZ R Screw AB
HM734 LX-GZ3002PEZZ R Screw AB
HM735 LX-GZ3002PEZZ R Screw AB
HM739 LX-GZ3002PEZZ R Screw AB
HM740 LX-GZ3002PEZZ R Screw AB
HM741 LX-GZ3002PEZZ R Screw AB
HM743 LX-GZ3002PEZZ R Screw AB
RDA501 PRDAR0103GJFW X Heat Sink, IC501
RDA701 PRDAR0237PEFW R Heat Sink, IC701 AK
TP701 QLUGP0102PEZZ R Lug AA
PZETM0016CEZZ J Insulator AB
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-A : DUNTK9529WEW5(14ML10)
MAIN UNIT (Continued)
TRANSISTORS
Q852 VS2SC2229O/1E J 2SC2229(O) AD
Q854 VS2SC2229O/1E J 2SC2229(O) AD
Q856 VS2SC2229O/1E J 2SC2229(O) AD
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
or
VS2SA1015-Y-1
DIODES
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D885 VHD1SS119//-1 J Diode AB
COIL
L851 VP-DF151K0000 J Peaking 150µH AB
CAPACITORS
[EL.··· Electrolytic]
C851 VCCCCY1HH271J J 270p 50V Ceramic AA
C852 VCCCCY1HH271J J 270p 50V Ceramic AA
C853 VCCCCY1HH271J J 270p 50V Ceramic AA
C854 RC-KZ0029CEZZ J 0.01 1.4kV Ceramic AC
C881 VCEA0A1CW106M J 10 16V EL. AB
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
R851 VRN-MD2AL470J J 47 1/10W M-Film AA
R852 VRD-RA2BE271J J 270 1/8W Carbon AA
R853 VRN-MD2AL121J J 120 1/10W M-Film AA
å R857 VRS-VV3AB123J J 12k 1W M-Ox. AA
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRN-MD2AL470J J 47 1/10W M-Film AA
R860 VRD-RA2BE271J J 270 1/8W Carbon AA
R861 VRN-MD2AL121J J 120 1/10W M-Film AA
å R865 VRS-VV3AB123J J 12k 1W M-Ox. AA
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
R868 VRN-MD2AL271J J 270 1/10W M-Film AA
R869 VRN-MD2AL121J J 120 1/10W M-Film AA
å R873 VRS-VV3AB123J J 12k 1W M-Ox. AA
R874 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R881 VRN-MD2AL561J J 560 1/10W M-Film AA
R882 VRN-MD2AL391J J 390 1/10W M-Film AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRN-MD2AL152J J 1.5k 1/10W M-Film AA
R886 VRN-MD2AL431J J 430 1/10W M-Film AA
R887 VRN-MD2AL470J J 47 1/10W M-Film AA
MISCELLANEOUS PARTS
P851 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P852 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
SC851 QSOCV0842CEZZ J CRT Socket AH
PWB-B : DUNTK9530WEW1
(13L-M100/150, CL13M10/15)
CRT UNIT
