Sharp CL13M10/15 User Manual

30
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
R459 VRD-RA2BE123J J 12k 1/8W Carbon AA
R504 VRD-RA2BE471J J 470 1/8W Carbon AA
R505 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R506 VRD-RA2BE683G J 68k 1/8W Carbon AA
R507 VRD-RA2BE104G J 100k 1/8W Carbon AA
R508 VRD-RA2BE473J J 47k 1/8W Carbon AA
R510 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
å R511 VRN-SV2HB3R9J J 3.9 1/2W M-Film AB
R512 VRD-RM2HD681J J 680 1/2W Carbon AA
R516 VRD-RA2BE223G J 22k 1/8W Carbon AA
R517 VRD-RA2BE103G J 10k 1/8W Carbon AA
R518 VRD-RA2BE154J J 150k 1/8W Carbon AA
R524 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R525 VRD-RA2BE473J J 47k 1/8W Carbon AA
R552 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R553 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R554 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R555 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R556 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R602 VRD-RA2EE820J J 82 1/4W Carbon AA
å R603 VRS-VV3LB270J J 27 3.0W M-Ox. AB
R605 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R606 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R608 VRD-RA2BE101J J 100 1/8W Carbon AB
R609 VRD-RA2BE331J J 330 1/8W Carbon AA
å R610 VRS-VV3DB391J J 390 2W M-Ox. AA
R620 VRD-RA2BE473J J 47k 1/8W Carbon AA
R621 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R631 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R632 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R633 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R634 VRD-RM2HD121J J 120 1/2W Carbon AA
å R641 VRS-VV3AB682J J 6.8k 1W M-Ox. AA
R642 VRD-RA2BE821J J 820 1/8W Carbon AA
çå R651 VRD-RM2HD1R0J J 1.0 1/2W Carbon AA
çå R654 VRD-RA2BE154J J 150k 1/8W Carbon AA
çå R655 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
çå R656 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
å R659 VRN-VV3AB1R8J J 1.8 1W M-Film AA
å R661 VRN-VV3ABR47J J 0.47 1W Metal Film AA
å R701 RR-HZ0046CEZZ J 2.7M 1/2W Solid AD
or
RR-DZ0047CEZZ
or
VRC-UB2HG275K
å R702 VRW-KP3HC1R8K J 1.8 5W Cement AC
å R703 VRS-KA3NG561J J 560 7.0W M-Ox. AF
R704 VRD-RM2HD123J J 12k 1/2W Carbon AA
R705 VRD-RA2EE334J J 330k 1/4W Carbon AA
R706 VRD-RM2HD470J J 47 1/2W Carbon AA
å R707 VRN-VV3DB1R5J J 1.5 2W Metal Film AB
å R708 VRD-RM2HD824J J 820k 1/2W Carbon AA
å R709 VRS-KA3NG561J J 560 7.0W M-Ox. AF
å R717 VRS-KA3HG3R3K J 3.3 5W M-Ox. AD
å R730 VRS-VV3DB270J J 27 2W M-Ox. AA
å R750 VRS-VV3AB561J J 560 1W M-Ox. AA
R752 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R754 VRS-CY1JF471J J 470 1/16W M-Ox. AA
å R755 VRS-VV3DB470J J 47 2W M-Ox. AA
R757 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
å R758 VRS-SV2HC150J J 15 1/2W M-Ox. AA
R801 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R802 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R803 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R804 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R805 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
R806 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R902 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R906 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R925 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R961 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R962 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2001 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2002 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2006 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2007 VRD-RA2BE223J J 22k 1/8W Carbon AA
R2008 VRD-RA2BE224J J 220k 1/8W Carbon AA
R2009 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2010 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2011 VRS-CY1JF821J J 820 1/16W M-Ox. AA
R2012 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R2020 VRD-RM2HD223J J 22k 1/2W Carbon AA
R2022 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2024 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2028 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R2029 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2032 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R2033 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2040 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R2041 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2042 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2043 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2044 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R2045 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2048 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R2049 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2054 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2055 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2060 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2061 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2063 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2066 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2401 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2402 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2403 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2404 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-down AB
S2503 QSW-K0079GEZZ J Vol-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0038CEZZ
or
RRLYU0077CEZZ
å F701 QFS-B4023CEZZ J Fuse, 4A(125V) AC
or
QFS-B4021GEZZ
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
PWB-A : DUNTK9529WEW5(14ML10)
MAIN UNIT (Continued)
