Sharp CL13M10/15 User Manual

29
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
C662 VCEA0A1CW477M J 470 16V EL. AC
å C701 RC-FZ027SCEZZ J 0.047 AC125V Plastic
or
RC-FZ002SCEZZ
or
RC-FZ004SGEZZ
or
RC-FZ027CUMZZ
or
RC-FZ019SCEZZ
or
RC-FZ059SCEZZ
C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C704 VCKYPB2HE103P J 0.01 500V Ceramic AB
å C705 RC-EZ0422CEZZ J 470 200V EL.
or
RC-EZ0522CEZZ
å C706 RC-KZ0092GEZZ J 0.0033 AC125V Ceramic AC
or
RC-KZ0311CEZZ
C707 VCEAGA2CW226M J 22 160V EL. AD
å C712 RC-EZ0638CEZZ J 33 160V EL. AG
or
RC-EZ0658CEZZ
C751 VCEA0A1VW477M J 470 35V EL. AB
C754 VCEA0A1CW337M J 330 16V EL. AC
C755 VCEA0A1CW107M J 100 16V EL. AC
C756 VCEAGA1CW108M J 1000 16V EL. AD
C757 RC-QZA104TAYK J 0.1 50V Mylar AB
å C758 VCEAGA2EW106M J 10 250V EL. AC
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEAGA1CW108M J 1000 16V EL. AD
C801 RC-QZA223TAYK J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1.0 50V EL. AB
C2051 VCCCCY1HH101J J 100p 50V Ceramic AA
C2060 RC-QZA104TAYK J 0.1 50V Mylar AB
C2061 VCKYD41HB101K J 100p 50V Ceramic AA
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2402 VCCCCY1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1HW475M J 4.7 50V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
RESISTORS
[M-Ox.··· Metal Oxide, M-Film ··· Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ5 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ9 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ23 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ24 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ26 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ31 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ35 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ40 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ49 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ52 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ54 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ55 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ57 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ59 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ62 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ63 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ66 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ67 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ68 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ69 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ71 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ75 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ77 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ78 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ79 VRS-CY1JF000J J 0 1/16W M-Ox. AA
å R51 VRS-VV3DB151J J 150 2W M-Ox. AA
å R52 VRN-VV3DB1R0J J 1.0 2W M-Film AB
å R53 VRS-VV3LB223J J 22k 3.0W M-Ox. AB
R54 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R55 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRD-RA2BE391J J 390 1/8W Carbon AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R208 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R301 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R302 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R303 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R307 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R352 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R353 VRS-CY1JF4R7J J 4.7 1/16W M-Ox. AA
R354 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R361 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R364 VRS-CY1JF473J J 47k 1/16W M-Ox. AA
R401 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R403 VRD-RA2BE331J J 330 1/8W Carbon AA
R404 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R407 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R409 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R410 VRD-RA2BE563J J 56k 1/8W Carbon AA
R411 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R412 VRD-RA2EE561J J 560 1/4W Carbon AA
R413 VRD-RA2BE470J J 47 1/8W Carbon AA
R414 VRD-RA2BE470J J 47 1/8W Carbon AA
R415 VRD-RA2BE470J J 47 1/8W Carbon AA
R416 VRS-CY1JF102J J 1.0k 1/16W M-Ox. AA
R417 VRD-RA2BE101J J 100 1/8W Carbon AB
R418 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R419 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R423 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R426 VRS-CY1JF271J J 270 1/16W M-Ox. AA
R440 VRS-CY1JF821J J 820 1/16W M-Ox. AA
å R451 VRS-SV2HC103J J 10k 1/2W M-Ox. AA
R452 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R454 VRD-RA2BE334J J 330k 1/8W Carbon AA
R455 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R456 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R457 VRD-RA2BE102J J 1.0k 1/8W Carbon AA
R458 VRD-RA2BE564J J 560k 1/8W Carbon AA
PWB-A : DUNTK9529WEW5(14ML10)
MAIN UNIT (Continued)
