28
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
D641 RH-EX0630GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
å D661 RH-DX0444CEZZ J Diode AH
å D701 RH-DX0154CEZZ J Diode AC
å D702 RH-DX0154CEZZ J Diode AC
å D703 RH-DX0154CEZZ J Diode AC
å D704 RH-DX0154CEZZ J Diode AC
D753 VHD1SS119//-1 J Diode AB
D754 VHD1SS119//-1 J Diode AB
D755 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D756 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D757 VHD1SS119//-1 J Diode AB
å D758 RH-DX0131CEZZ J Diode AC
or
RH-DX0110CEZZ
å D760 RH-DX0441CEZZ J Diode AC
å D761 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D762 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D763 VHD1SS119//-1 J Diode AB
D901 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D902 RH-EX0630GEZZ J Zener Diode, 9.1V AA
D2001 VHD1SS119//-1 J Diode AB
PACKAGED CIRCUITS
å PR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0205CEZZ J Crystal AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0403CEZZ J Ceramic Filter AE
CF401 RFiLC0013CEZZ J Ceramic Filter AE
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
SF201 RFiLC0405CEZZ J SAW Filter AH
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0612CEZZ J IF Coil AE
or
RCiLi0588CEZZ
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J VCO Coil AE
L401 VP-XF120K0000 J Peaking 12µH AB
L402 VP-XF100K0000 J Peaking 10µH AB
L406 VP-XF680K0000 J Peaking 68µH AB
L408 VP-XF100K0000 J Peaking 10µH AB
å L701 RCiLF0029PEZZ R Coil AH
or
RCiLF0087CEZZ
or
RCiLF0235CEZZ
L2040 RCiLB0159CEZZ J Oscillation Coil AE
TRANSFORMERS
å T601 RTRNZ0168CEZZ J Transformer AH
çå T602 RTRNF0148PEZZ R H-Volt Transformer BD
or
RTRNF0151PEZZ
å T701 RTRNP0527CEZZ J Power Transformer AM
or
RTRNP0518CEZZ
CAPACITORS
[EL.··· Electrolytic, M-Poly.··· Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V Tantalum AD
C53 VCEA0A1HW105M J 1.0 50V EL. AB
C54 VCEA0A1HW225M J 2.2 50V EL. AB
C55 VCEAGA1CW108M J 1000 16V EL. AD
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW227M J 220 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C302 VCCCCY1HH330J J 33p 50V Ceramic AA
C303 VCKYCY1HB472K J 4700p 50V Ceramic AA
C304 VCEA0A1HW225M J 2.2 50V EL. AB
C305 VCKYPA1HB151K J 150p 50V Ceramic AA
C306 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW227M J 220 16V EL. AC
C312 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C314 VCEA0A1HW225M J 2.2 50V EL. AB
C351 VCKYCY1HB562K J 5600p 50V Ceramic AA
C352 VCEA0A1CW107M J 100 16V EL. AC
C353 VCEA0A1CW337M J 330 16V EL. AC
C354 RC-QZA104TAYK J 0.1 50V Mylar AB
C355 VCEA0A1CW226M J 22 16V EL. AB
C361 VCEA0A1CW477M J 470 16V EL. AC
C362 VCEA0A1CW476M J 47 16V EL. AB
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C404 VCCCCY1HH680J J 68p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C407 RC-QZA104TAYK J 0.1 50V Mylar AB
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1.0 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA
C420 VCCCCY1HH471J J 470p 50V Ceramic AA
C451 RC-QZA563TAYK J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
C507 VCKYPA1HB102K J 1000p 50V Ceramic AA
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C513 VCEACA1HC225M J 2.2 50V EL. AC
C514 VCEACA1HC335J J 3.3 50V EL. AC
C517 VCKYCY1HB102K J 1000p 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C604 VCEA0A1CW227M J 220 16V EL. AC
çå C608 VCFPPD3CA522H J 5200p 1.6kV M-Poly. AE
C609 RC-QZA223TAYK J 0.022 50V Mylar AB
C612 VCFPPB2EB334J J 0.33 250V M-Poly. AF
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C633 VCEA0A1HW105M J 1.0 50V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
PWB-A : DUNTK9529WEW5(14ML10)
MAIN UNIT (Continued)
