Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
13L-M100/150
CL13M10/15
14ML10
R2045 VRN-MD2AL101J J 100 1/10W M-Film AA
R2047 VRN-MD2AL221J J 220 1/10W M-Film AA
R2048 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
R2049 VRN-MD2AL333J J 33k 1/10W M-Film AA
R2054 VRN-MD2AL222J J 2.2k 1/10W M-Film AA
R2055 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2060 VRN-MD2AL221J J 220 1/10W M-Film AA
R2061 VRN-MD2AL562J J 5.6k 1/10W M-Film AA
R2062 VRN-MD2AL183J J 18k 1/10W M-Film AA
R2063 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R2064 VRD-RA2BE332J J 3.3k 1/8W Carbon AA
R2066 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2067 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2068 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2070 VRN-MD2AL103J J 10k 1/10W M-Film AA
R2101 VRN-MD2AL101J J 100 1/10W M-Film AA
R2102 VRN-MD2AL101J J 100 1/10W M-Film AA
R2401 VRN-MD2AL101J J 100 1/10W M-Film AA
R2402 VRN-MD2AL101J J 100 1/10W M-Film AA
R2403 VRN-MD2AL101J J 100 1/10W M-Film AA
R2404 VRN-MD2AL101J J 100 1/10W M-Film AA
R2501 VRN-MD2AL123J J 12k 1/10W M-Film AA
R2503 VRN-MD2AL273J J 27k 1/10W M-Film AA
R2504 VRN-MD2AL123J J 12k 1/10W M-Film AA
R2505 VRN-MD2AL563J J 56k 1/10W M-Film AA
R2506 VRN-MD2AL563J J 56k 1/10W M-Film AA
R2507 VRN-MD2AL823J J 82k 1/10W M-Film AA
R2508 VRN-MD2AL153J J 15k 1/10W M-Film AA
R2509 VRN-MD2AL272J J 2.7k 1/10W M-Film AA
R2601 VRD-RA2BE331J J 330 1/8W Carbon AA
SWITCHES
S2501 QSW-K0079GEZZ J Power AB
S2502 QSW-K0079GEZZ J Vol-down AB
S2503 QSW-K0079GEZZ J Vol-up AB
S2504 QSW-K0079GEZZ J CH-down AB
S2505 QSW-K0079GEZZ J CH-up AB
MISCELLANEOUS PARTS
å RY701 RRLYU0036CEZZ J Relay AM
or
RRLYU0038CEZZ
or
RRLYU0077CEZZ
å F701 QFS-B4023CEZZ J Fuse, 4A(125V) AC
or
QFS-B4021GEZZ
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FH701 QFSHD1013CEZZ J Fuse Holder AC
FH702 QFSHD1014CEZZ J Fuse Holder AC
J903 QJAKE0159CEZZ J Jack, Audio IN AF
J905 QJAKE0158CEZZ J Jack, Video IN AF
P302 QPLGN0261CEZZ J Plug, 2-pin(S) AB
P401 QPLGN0561CEZZ J Plug, 5-pin(GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-pin(K) AB
P651 QPLGN0361CEZZ J Plug, 3-pin AB
P701 QPLGN0207CEZZ J Plug, 2-pin(M) AA
P751 QPLGN0461CEZZ J Plug, 4-pin(YBN) AB
P2001 QPLGN0561CEZZ J Plug, 5-pin AB
RMC2601 RRMCU0227CEZZ J R/C Receiver AK
or
RRMCU0222CEZZ
RDA501 PRDAR0218PEFW R Heat Sink, IC501 AD
RDA701 PRDAR0237PEFW R Heat Sink, IC701 AK
TP701 QLUGP0102PEZZ R Lug AA
PZETM0016CEZZ J Insulator AB
LX-BZ3049GEFD J Screw AA
LX-BZ3100CEFD J Screw AA
LX-TZ3004CEFD J Screw AA
PWB-A : DUNTK9529WEW5(14ML10)
MAIN UNIT
TUNER
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
å TU51 VTU115B8025AM M Tuner BA
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KA78S05P AD
or
VHiTA7805S/-1
çå IC201 RH-iX3253CEZZ J TA1268AN AV
IC351 VHiTDA7233/-1 J TDA7233 AF
å IC501 VHiTA8403K/-1 J TA8403K AL
çå IC701 VHiSTR301301E J STR30130 AP
å IC751 VHiKA7809Pi-1 J KA7809PI AE
or
VHiTA7809S/-1
å IC761 VHiKA7812Pi-1 J KA7812PI AE
or
VHiTA7812S/-1
IC2001 RH-iX3256CEZZ J TMPA8701CMF142 AX
IC2040 VHiPST994C/-1 J PST994C AD
IC2101 VHiM24C01B/-1 J M24C01-BN6 AF
TRANSISTORS
You can substitute "VS2SC2462-C-1" for "VS2SD601AR/-1".
Q201 VS2SC2735//1E J 2SC2735 AC
Q351 VS2SD601AR/-1 J 2SD601AR AC
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q404 VS2SB709AR/-1 J 2SB709AR AC
Q451 VS2SB709AR/-1 J 2SB709AR AC
Q501 VS2SD601AR/-1 J 2SD601AR AC
Q601 VS2SC2655Y/-1 J 2SC2655Y AE
çå Q602 VS2SD2586//1E J 2SD2586 AM
or
VS2SD2095//1E
Q603 VS2SC945AQ/-1 J 2SC945A(Q) AB
or
VS2SC1815YW-1
or
VS2SC3198-Y-1
Q752 VS2SC945AQ/-1 J 2SC945A(Q) AB
or
VS2SC1815YW-1
or
VS2SC3198-Y-1
Q753 VS2SA1013//1E J 2SA1013 AD
Q2001 VS2SD601AR/-1 J 2SD601AR AC
Q2002 VS2SD601AR/-1 J 2SD601AR AC
Q2060 VS2SD601AR/-1 J 2SD601AR AC
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
å D502 RH-DX0131CEZZ J Diode AC
D601 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D603 RH-DX0441CEZZ J Diode AC
or
RH-DX0110CEZZ
D610 RH-DX0131CEZZ J Diode AC
D631 RH-EX0630GEZZ J Zener Diode, 9.1V AA
PWB-A : DUNTK9529WEW1(13L-M100/150)
PWB-A : DUNTK9529WEW3(CL13M10/15)
MAIN UNIT (Continued)
