13.
SHORT
PIN set
ting
The ER-A220 ha
s two SHORT PIN setting
s.
SHORT PIN No.
FUNCTION
DEFAULT
SP1
Switchi
ng between
Normal mod
e/IPL mode
Normal mode
SP2
Switc
hing R
S232C
No.9 p
in and C
l/+5V
Cl s
ignal
SP1 : Normal mode / IPL mode
VCC
SP1
Normal mode
IPL mode
SP2 : +5V / CI
VCC
/CI
+5V
CI
VCC
/CI
VCC
SP1
13
15
