Sharp ER-A220 Service Manual

1Exteriors
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
GCOVB2488BHZZ AU
N D Printer cover
2
GCABB2532BHZZ AX
D Top cabinet
3
XEBSD30P10000 AA
CScrew (3´10)
4
HDECP2366BHSA AN
N D Deco panel
5
PGIDH2399BHZZ AH
N C Paper guide
6
GCABB2535BHZZ AN
N D Pop up cabinet
7
PFILW2431BHZZ AP
N D Pop up filter
8
CPWBF7504BH01 BC
E Pop up LED PWB unit(NORMAL)
9
QCNW-3063BHZZ AL
N C Pop up flat cable (15P)
10
CPWBF2838BH04 BN
N E Key i/f PWB unit
11
XEBSD30P08000 AA
CScrew (3´8)
12
XHBSD40P06000 AA
CScrew (4´6) [for Trans]
13
! RTRNP2409BHZZ BK
N B Power transformer (220V) [TQ,TS]
! RTRNP2410BHZZ BK
N B Power transformer (240V) [KA,KB]
14
GCOVH2489BHZZ AT
N D Trans holder
15
! DUNT-3983BHZZ AX
N B AC cord unit [TQ,TS]
! DUNT-3984BHZZ AX
N B AC cord unit [KA]
! DUNT-3985BHZZ BE
N B AC cord unit [KB]
16
XHBSD30P10000 AA
CScrew (3´10) [for RS232C angle]
17
CPWBN2846BH01 CC
N E Main PWB unit
18
QCNW-3044BHZZ AE
C Battery cable (NI-MH)
19
UBATZ6661BHZZ BA
B Battery
20
QCNW-3041BHZZ AP
C Flat cable (26P)
21
QCNW-3042BHZZ AQ
C Flat cable (34P)
22
GFTAB6775BHSD AE
D Pattery cover
23
GDAI-2344BHZA AM
N D Paper dai
25
LX-BZ6788BHZZ AD
C Screw [for PR sheet,Paper cutter]
26
PSHEP2885BHZZ AK
C PR PWB sheet
27
XJSSD26P08000 AA
C Screw (2.6´8)
28
PSHEP2901BHZZ AK
N C PR sheet L
29
KI-OB2365RCZZ BM
E Printer unit (LTP1245)
30
CPWBN2842BH01 BH
N E PR i/f PWB unit
31
PGUMM6702BHZA AC
C Motor gum
32
XBPSD26P06000 AA
C Screw (2.6´6) [for Motor]
33
LHLDZ2376BHZA AS
N C Printer holder
34
LANGQ2851BHZZ AF
C Earth plate
35
RMOTM6633BHZZ AY
B DC motor
36
QCNW-3043BHZZ AE
C Motor cable
38
GCABA2531BHZA BD
N D Bottom cabinet
39
LCHSM2375BHZA AW
N C Main chassis
41
XUBSD40P10000 AA
CScrew (4´10)
45
GCOVH2484BHZZ AF
D RS232C cover
46
LANGT2849BHZZ AF
C RS232C angle
48
PFILW2432BHZZ AV
N D Front filter
49
RCORF2031SCZZ AN
C Core (SSC-50-12-F)
50
QCNW-7904BHZZ AE
C Eaerth wire
51
XEBSD30P06000 AA
CScrew (M3´6)
53
PCUT-2326BHZZ AF
C Paper cutter
54
XHBSD30P06000 AA
CScrew (3´6) [for Earth GND]
55
RCORF6699BHZZ AU
C Core (BNF28)
57
RCORF5010BCZZ AD
C Ferrite core
58
PSHEP2892BHZZ AP
N C Waterproof sheet
ER-A220V
– 1 –
