Sharp ER-A220 Service Manual

5 Main PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
LX-BZ6644BHZZ AA
C Screw (M3.5´8S) [Q10]
2
PRDAF2374BHZZ AM
N C Heat sink (for KTD998)[Q10]
3
PRDAF6656BHZZ AK
C Heat sink [Q7,8]
4
QCNCM1060AC03 AB
C Connector (Short Pin 3P) [SP1,2]
5
QCNCM1101CCZZ AB
C Connector (2pin)(QCNCM1101BHZZ) [CN7]
6
QCNCM5278NCZZ AC
C Connector (3pin)(5046-03A) [CN6]
7
QCNCM6865RC0B AA
C Connector (2pin)(5267-02A)(QCNCM6865BH0B) [CN3]
8
QCNCM7125BH0I AN
C Connector ((9P) MLX 87023-6066)) [CN8]
9
QCNCW1057ACZZ AB
C Connector (Short socket) [SP1,2]
10
QCNCW2822BH2F AH
C Connector (52045-2645) [CN4]
11
QCNCW2822BH3D AK
C Connector (K/B)(52045-3445) [CN2]
12
QCNCW7081BHZZ AB
C Connector (2P)(5267-02A)(Blue) [CN1]
13
! QFS-C4301CCZZ AE
A Fuse (T800mA/250V) [F2]
14
! QFS-C1025CCZZ AF
A Fuse (3.15A/250V) [F1,3]
15
QFSHD2109AFZZ AC
C Fuse holder [F1,2,3]
16
QSOCZ2042SC32 AE
C IC socket (32pin) [IC2]
17
RALMB6646BHZZ AQ
B Buzzer [BZ1]
18
RC-EZ106ARC1A AD
C Capacitor (10WV 10mF) [C15]
19
RC-EZ3381QCZZ AR
N C Capacitor (3300mF/50V) [C43,45]
20
RCILC2417BHZZ AK
N C Coil (220mH/2A) [L1]
21
RCILC6653BHZZ AS
C Choke coil (180mH) [L2,3]
22
RCILZ1003BHZZ AF
C Dip coil (BFW7550R2) [FB1,2]
23
RCORF7002BHZZ AE
C Chip core (EFCB322513TS) [FB101,102,103,104,105,106,107]
RCORF7002BHZZ AE
C Chip core (EFCB322513TS) [FB108]
24
RCRSP6676RCZZ AG
B Crystal (32.768KHz) [X1]
25
RCRSZ2401RCZZ AL
N B X-TAL (MA-406/12MHz) [X3]
26
VCCCTV1HH101J AA
C Capacitor (50WV 100PF) [C1,2,3,4]
VCCCTV1HH101J AA
C Capacitor (50WV 100PF) [C101,102,103,115,116,117,118,119]
VCCCTV1HH101J AA
C Capacitor (50WV 100PF) [C139,141]
27
VCCCTV1HH151J AA
C Capacitor (50WV 150pF) [C104,105,107,108,109,110,111,113]
VCCCTV1HH151J AA
C Capacitor (50WV 150pF) [C114,120,121,122,123,124,125,126]
VCCCTV1HH151J AA
C Capacitor (50WV 150pF) [C12]
VCCCTV1HH151J AA
C Capacitor (50WV 150pF) [C164,165]
28
VCCCTV1HH180J AA
C Capacitor (50WV 18PF) [C134]
29
VCCCTV1HH221J AA
C Capacitor (50WV 220PF) [C146]
30
VCCCTV1HH270J AC
C Capacitor (50WV 27pF) [C135]
31
VCCCTV1HH300J AA
C Capacitor (50WV 30PF) [C128]
32
VCCCTV1HH6R0C AB
C Capacitor (50WV 6.0PF) [C132,133]
33
VCCSTV1HL181J AD
C Capacitor (50WV 180pF) [C153]
34
VCEA2U1HW228M AH
C Capacitor (50WV 2200mF) [C46]
35
VCEAGA1CW337M AB
C Capacitor (16WV 330mF) [C24,31]
36
VCEAGA1HW104M AB
C Capacitor (50WV 0.1mF) [C29]
37
VCEAGA1HW106M AA
C Capacitor (50WV 10mF) [C7,8,13,14,18,25,26,30]
38
VCEAGA1HW107M AA
C Capacitor (50WV 100mF) [C39,40,41]
39
VCEAGA1HW225M AA
C Capacitor (50WV 2.2mF) [C38]
40
VCEAGD1CW108M AE
C Capacitor (16WV 1000mF) [C34]
41
VCEAGD1CW478M AP
C Capacitor (4700mF/16V) [C35,36,42]
42
VCKYTV1HB102K AA
C Capacitor (50WV 1000PF) [C136,142,143,144,145,148]
43
VCKYTV1HB103K AB
C Capacitor (50WV 0.01mF)(NC60) [C149,150,151]
VCKYTV1HB103K AB
C Capacitor (50WV 0.01mF)(NC60) [C27]
44
VCKYTV1HF104Z AA
C Capacitor (50WV 0.10mF) [C127,131,140,147,152,156,157]
VCKYTV1HF104Z AA
C Capacitor (50WV 0.10mF) [C158,159,161,162,163]
VCKYTV1HF104Z AA
C Capacitor (50WV 0.10mF) [C5,9,16,17,19,20,22,23,28,32,33]
45
VCQYNA1HM333K AA
C Capacitor (50WV 0.033mF) [C44]
46
VHD1SR1544001 AB
B Diode (1SR1544001) [D103,113,115]
47
VHD1SR159//-1 AF
N B Diode (1SR159-200) [D108,109]
48
VHD1SS353//-1 AB
B Diode (1SS353) [D1,3,6,7]
VHD1SS353//-1 AB
B Diode (1SS353) [D104,105,106,110,111]
49
VHDCP301///-1 AL
B Diode (CP301) [D5]
50
VHDFMB-G24H/1 AH
B Diode (FMG-G24H) [D4]
51
VHDRB060L//-1 AK
B Diode (RB060L40) [D102]
52
VHEPTZ6.2A/-1 AH
B Zener diode (PTZ6.2A) [ZD102]
53
VHEPTZ9.1B+-1 AG
N B Zener diode (PTZ9.1B) [ZD101]
54
VHEUDZ5.1B/-1 AC
B Zener diode (UDZ5.1B) [ZD103]
55
VHI30624FG001 BD
N B CPU (M30624FGFP) [IC8]
56
VHI74F139SJ-1 AG
N B IC (74F139) [IC5]
57
VHIBA10393F-1 AC
B IC (BA10393F) [IC10]
58
VHIHM128F12SL BN
B IC (HM128F12SL) [IC3B]
59
VHIKIA431F/-1 AK
B IC (KIA431F) [IC15]
60
VHILB1843V/-1 AM
B IC (LB1843V) [IC12,13]
61
VHILM2574-ADJ AU
B IC (LM2574HVN-ADJ) [IC18]
62
VHIMAX211CAI1 AW
B IC (MAX211)(VHIMAX211CAI-) [IC11]
63
VHIMC34063AM1 AG
B IC (MC34063AM1) [IC16,17]
64
VHIMC74HC123F AM
B IC (74HC123)(VHISN74HC123D) [IC14]
65
VHISN74HC32DR AG
B IC (SN74HC32D) [IC7]
66
VHISN74HC374D AL
B IC (SN74HC374D) [IC4]
67
VHIW42C3103G/ AU
B IC (W42C3103G) [IC9]
68
VHVICPS0.5/-1 AF
B IC-protector (ICPS0.5) [ICP1]
69
VHVICPS1.0/-1 AF
B IC protector (ICPS1.0) [ICP103]
70
VRS-FC3LG470J AF
N C Resistor (3W 47W±5%) [R58]
ER-A220V
– 7 –
