ER-A520U/ER-A530U HARDWARE DESCRIPTION
– 8 –
3. CPU PIN TABLE
M16C/80 PORT USED IN PROCESSOR MODE: MICROPROCESSOR MODE (SEPARATE BUS 8bit WIDTH)
PORT
PIN
No.
Pin
name
Signal
name
I/O
Initial
value
After
POFF
Function
P00 122 D0 D0 I/O − In DATA BUS D0
P01 121 D1 D1 I/
O − In DATA BUS D1
P02 120 D2 D2 I/O − In DATA BUS D2
P03 119 D3 D3 I/O − In DATA BUS D3
P04 113 D4 D4 I/O − In DATA BUS D4
P05 112 D5 D5 I/O − In DATA BUS D5
P06 111 D6 D6 I/O − In DATA BUS D6
P07 110 D7 D7 I/O − In DATA BUS D7
P10 109 P10 RAS O L Out L RECEIPT
PAPER FEED A
P11 108 P11 RBS O L Out L RECEIPT
PAPER FEED B
P12 107 P12 RCS O L Out L RECEIPT
PAPER FEED C
P13 106 P13 RDS O L Out L RECEIPT
PAPER FEED D
P14 105 P14 JAS O L Out L JOURNAL
PAPER FEED A
P15 104 P15
/INT3#
JBS O L Out L JOURNAL
PAPER FEED B
P16 103 P16
/INT4#
JCS O L Out L JOURNAL
PAPER FEED C
P17 102 P17
/INT5#
JDS O L Out L JOURNAL
PAPER FEED D
P20 101 A0 A0 O − Out L Address Bus A0
P21 100 A1 A1 O − Out L Address Bus A1
P22 99 A2 A2 O − Out L Address Bus A2
P23 98 A3 A3 O − Out L Address Bus A3
P24 97 A4 A4 O − Out L Address Bus A4
P25 96 A5 A5 O − Out L Address Bus A5
P26 95 A6 A6 O − Out L Address Bus A6
P27 94 A7 A7 O − Out L Address Bus A7
P30 92 A8 A8 O − Out L Address Bus A8
P31 85 A9 A9 O − Out L Address Bus A9
P32 84 A10 A10 O − Out L Address Bus A10
P33 83 A11 A11 O − Out L Address Bus A11
P34 82 A12 A12 O − Out L Address Bus A12
P35 81 A13 A13 O − Out L Address Bus A13
P36 80 A14 A14 O − Out L Address Bus A14
P37 79 A15 A15 O − Out L Address Bus A15
P40 78 A16 A16 O − Out L Address Bus A16
P41 77 A17 A17 O − Out L Address Bus A17
P42 75 A18 A18 O − Out L Address Bus A18
P43 73 A19 A19 O − Out L Address Bus A19
P44 72 A20
/CS3#
A20 O − Out L Address Bus A20
P45 71 A21
/CS2#
A21 O − Out L Address Bus A21
P46 70 A22
/CS1#
A22 O − Out L Address Bus A22
P47 69 A23#
/CS0#
A23# O − Out L Address Bus A23
P50 65 WR# WR# O − Out L WRITE STROBE
SIGNAL
P51 64 BHE# BHE# O − Out L NOT USED
P52 63 RD# RD# O − Out L READ STROBE
SIGNAL
P53 62 BCLK BCLK O − Out L BCLK CLOCK
P54 55 HLDA# HLDA# O − Out L NOT USED
P55 54 HOLD# HOLD# I − In NOT USED
P56 53 ALE ALE O − Out L NOT USED
P57 52 RDY# RDY# I − In NOT USED
P60 47 RTS0# RS2# O H In RS-232 RS2
P61 46 CLK0
CI2# I − In RS-232 CI2
P62 45 RxD0 RD2 I − In RS-232 RD2
P63 44 TxD0 TD2 O H In RS-232 TD2
P64 43 RTS1# RS1# O H In RS-232 RS1
P65 42 CLK1 CI1# I − In RS-232 CI1
P66 40 RxD1 RD1 I − In RS-232 RD1
P67 38 TxD1 TD1 O H In RS-232 TD1
P70 37 P70/
TA0out
KR0# I − In KEY RETURN
SIGNAL 0
P71 36 P71/
TA0in
KR1# I − In KEY RETURN
SIGNAL 1
P72 35 P72/
TA1out
KR2# I − In KEY RETURN
SIGNAL 2
P73 34 P73/
TA1in
KR3# I − In KEY RETURN
SIGNAL 3
P74 33 P74/
TA2out
KR4# I − In KEY RETURN
SIGNAL 4
P75 32 P75/
TA2in
KR5# I − In KEY RETURN
SIGNAL 5
P76 31 P76/
TA3out
KR6# I − In KEY RETURN
SIGNAL 6
P77 30 P77/
TA3in
KR7# I − In KEY RETURN
SIGNAL 7
P80 29 P80/
TA4out
BUZZER O L
In BUZZER SIG-
NAL
P81 28 P81/
TA4in
DSEN I − In DRAWER OPEN
SENSE SIGNAL
P82 27 P82/
INT0#
POFF# I − In P-OFF SIGNAL
P83 26 P83
/INT1#
SHEN# I − In
UP-P16DP
SHEN# SINGNAL
P84 25 P84
/INT2#
I − In NOT USED
P85 24 P85
/NMI#
NMI# I − In NMI (CON-
NECTED TO
VDD)
P86 18
P86/
Xcout
Xcout O − Out SUB CLOCK
(32.768kHz)
P87 17 P87/
Xin
Xcin I − In SUB CLOCK
(32.768kHz)
P90 7 P90/
CLK3
SCK O L Out L UP-P16DP
CLOCK SIGNAL
PORT
PIN
No.
Pin
name
Signal
name
I/O
Initial
value
After
POFF
Function
