COMMUNICATIONS
Specifications subject to change without notice: Revision date 10/07 Page 191 of 266
Quick Steps – Communications
To quickly setup the ER-A520 and ER-A530 to interface with the Communications software
(example: SDW or some other software), please refer to the related procedures below:
No. Description Comments/Procedure
Step–1 Connect SDW CH–1 or CH–2
Step–2
PGM Job#2690
2690 Æ [.] Æ [@] Æ 1 Æ @ Æ 1000 [SBTL] Æ [CA/AT] for CH–1)
or
2690 Æ [.] Æ [@] Æ 1 Æ @ Æ 2000 [SBTL] Æ [CA/AT] for CH–2)
Note: Must match the physical connection
Step–3
Program Reset
• Place the SRV-Key counter-clockwise to 6 o’clock position (SRV’ position)
• Count 5 seconds
• Turn SRV-Key clockwise to 7o’clock position (SRV position)
• Verify”***PROGRAM RESET has printed on the journal-side tape.
Step-4 PGM Job#6110 6110 Æ[.] Æ[@]Æ 000001 Æ[CASH]
(Online Terminal No.)
Note: Leave at MRS defaults (Terminal = 000001)
Step-5
PGM Job #6111
6111 Æ[.] Æ[@] AB Æ[CASH]
(RS232 Transmission)
Note: Leave at MRS defaults (AB = 00)
Step-6
PGM Job#6112
6112 Æ[.] Æ[@]Æ AB Æ[CASH]
(RS232 Functions)
A: RS232 Baud Rate 38400/19200/9600/4800 bps = 7/6/5/4
Note: MRS defaults is 19200 bps (or 6)
Step-7 PGM Job #6113 6113 Æ[.] Æ[@]Æ xxxyyy Æ[CASH]
(Start & End Code)
Note: Leave at MRS defaults (or 002013)
Step-8 PGM Job #6115 6115 Æ[.] Æ[@]Æ xxx Æ[CASH]
(Time Out) 1
st
Response Wait
Note: Leave at MRS defaults (or 007)
Step-9 PGM Job#6220 6220 Æ[.] Æ[@]Æ ABCÆ[CASH]
(Print Data Sending)
A: Sensing of DTR No/Yes = 1/0
B: Sensing of CS No/Yes = 1/0
C: Sending of Print All Data Yes/No = 1/0
Note: PGM Job #6112-A must be = 1
To Next Page
