Departments
Specifications subject to change without notice: Revision date 10/07 Page 99 of 266
Overview
The ER-A520 and ER-A530 generally consists of two types of programming that are managed by
the mode key.
1. PGM2-Mode Programming: PGM Jobs that are 2xxx
2. PGM1-Mode Programming: PGM Jobs that are 1xxx
Note: PGM1-Jobs (1xxx) may be performed in the PGM1 or PGM2 Mode, where the PGM-2 Jobs
(2xxx) may only be performed in PGM2 Mode.
The PGM2-Mode programming is primarily used when installing the ECR and for maintaining
select presets intended only for Managers/ Owners.
The PGM1-Mode Programming is intended for settings that change frequently.
1. Programming Sequence:
When installing the ER-A520 and ER-A530, it is recommended to follow the sequence outlined
below:
1) Department Settings: This should be structured towards the balancing procedures required
2) PLU/UPC (EAN) Settings
3) Keyboard Assignment
4) Cashier Settings
5) Tax Rate
6) All other settings
IMPORTANT NOTE:
When using SDW or installing peripherals such as the Slip printer, the sequence may vary.
The RS-232 settings for SDW and peripheral connections will be described in a separate section.
2. General Rule:
When making presets entries, the following rule will apply:
2) If an error occurs prior to completing the 1
st
valid entry, it is necessary to depress the [CL]
key and start the PGM Job # again from the beginning.
3) If an error occurs on the second and subsequent preset entries, then depress the [CL] key
and re-enter the desired values.
