FO-4450U/FO-CS1
4. Soft switch description
• Soft switch
SW
NO.
DATA
NO.
ITEM
Switch setting and function
Remarks
Initial
setting
10
1 Recall interval Binary input 8 4 2 1 0 OPTION
2 No. = 1 2 3 4 (Data No.) 1 Set to 1~15
3 EX 0101 0
SW1
4 eg. Recall interval is set to 5 min. 1
5 Recall times Binary input 8 4 2 1 0 OPTION
6 No. = 5 6 7 8 (Data No.) 0 Set to 0~14
7 EX 0010 1
8 eg. Recall times is set to 2 times. 0
1 Dial mode PULSE TONE 0
2 Receive mode AUTO MANUAL 1
3 ECM mode Off On 0 OPTION
SW2
4 Reserved 0
5 Polling security On Off 1 OPTION
6 Auto cover sheet No Yes 1 OPTION
7 JUNK-FAX function in manual reception Yes No 0
8 JUNK-FAX function Yes No 0 OPTION
1 Number of rings for auto-receive Binary input 8 4 2 1 0 OPTION
2 (0: No ring receive) No. = 1 2 3 4 (Data No.) 0 Set to 0~9
3 EX 0001 0
SW3
4 eg. Number of rings for auto receive is set to 1 time. 1
5 Switch to auto-receive from manual receive Binary input 8 4 2 1 0 OPTION
6 (0: No switch) No. = 5 6 7 8 (Data No.) 0 Set to 0~9
7 EX 0000 0
8 eg. Switch to auto receive is set to disable. 0
Communication results printout Printed at Printed at Printed at
Not printed
Printed OPTION
error only
error/timer/
transmis- every time
memory sion mode
only only
1 No. 1 0 0 0 1 1 0
2 No. 2 0 0 1 0 1 0
SW4 3 No. 3 1 0 0 0 0 1
4 Image addition function to the communication On Off 1 OPTION
result table (for memory transmission only)
5 Reserved 0
6 TEL billing code function On Off 0 OPTION
7 Billing code position Before After 1 OPTION
8 Multi-TTI feature On Off 0 OPTION
1 Time display format 24 hours 12 hours-AM/PM 0
2 Date display format Month-Day-Year Day-Month-Year 1
3 Header print Off On 0
SW5
4 Footer print On Off 0
5 Reserved 0
6 Substitute reception Off On 0
7 Substitute reception conditions Reception disable without TSI Reception enable without TSI 0
8 CSI transmission Off On 0
2 – 10
