Sharp FO-71 /51/11 - Page 42

FO-71TH/UX-61TH/GQ-56TH/FO-51TH
UX-41TH/GQ-31TH/UX-21TH/FO-11TH/GQ-11TH
Wire treatment
11
Fig. 11
3 – 13
Parts list (Fig. 11)
CIS
cable
CIS
cable
Front sensor
cable
Scanner
frame
Rib
Rib
Rib
6
5
CIS
cable
Front sensor
cable
Door
sensor
cable
Door sensor cable
Door sensor
cable
Door
sensor
cable
Head
cable
Control
PWB
Cutter cable
(FO-71/UX-61
GQ-56 ONLY)
Motor
cable
Cam
switch
cable
Rib
Rib
Rib
Rib
Panel
cable
Panel cable
Hopper cover
2
7
1
1
Operation
panel PWB
Operation
panel unit
Rib
Rib
Motor cable
Rib
Rib
Cutter cable
Cam
switch
cable
Drive unit
TEL/LIU PWB
Power
Supply PWB
1
1
The head cable and
head earth cable
pass to the core 3 times.
Speaker
Panel
cable
ass'y
Speaker
cable
Head
earth
cable
5
5
FO-71/UX-61/GQ-56
Motor cable
Rib
Cam
switch
cable
Drive unit
FO-51/UX-41/GQ-31/
UX-21/GQ-11/FO-11
The panel cable pass to the core
3 times.
The cam switch cable pass to the
core 1 time.
PWB
case, bottom
AC cord
earth cable
ARG
cable
TEL/LIU PWB
Power
supply
PWB
AC
cord
4
3
Speaker
Rib
Rib
Speaker
cable
5
6
CIS
cable
6
5
CIS
cable
Front
sensor
cable
Front
sensor cable
The CIS cable pass to the core
2 times.
5
5
1 Core (F2125) 2
2 Screw (3×6) 1
3 Screw (4×6) 1
4 Screw (3×6) 1
5 Band (100mm) 3
6 Core (F2123) 1
7 Screw (3×10) 1
No. Part name Q’ty
