Sharp FP-F30Y

E-4
PART NAMES
13
14
16
2
1
1
Main Unit
9
HEPA Filter
2
Air Outlet
10
Upper Tabs
3
Fan Speed Indicator Lights(green)
11
Back Panel (Pre-Filter)
4
MODE Button / LIGHT ON/OFF Button
(Press 3 sec.)
12
Bottom Tabs
5
Plasmacluster Ion Indicator Light(blue)
13
Handle
6
Plasmacluster Ion ON/OFF Button
14
Date Label
7
POWER ON/OFF Button
15
Power Cord
8
ANTI DUST Button / ANTI DUST indicator
Light(green)
16
Plug (Shape of plug depends on country.)
FRONT
BACK
4
6
7
8
3
15
9
10
11
12
5
