15min. HIGH operation Indicator Light
PART NAMES
MAIN UNIT DISPLAY
Filter Indicator Light
AUTO Operation Indicator Light
Pollen Mode Indicator Light
OFF Timer Display Indicator Lights
Odor Sensor
Remote Control Receiver
CLEAN-SIGN Light
Odor Sensor
Dust Sensor
POWER ON/OFF Button See Page E-8
MODE Button See Page E-8
Sensor Sensitivity Select Switch
Sensor sensitivity can be adjusted to “Normal ( )”
or “Sensitive ( )” by this switch.
Main Unit
Band See Page E-7
Filter Frame
HEPA Filter (white) See Page E-7,13
(with Microbial Control Filter (blue))
Washable Active Carbon Filter (black)
See Page E-7,12,13
Pre-Filter
Front Panel
Remote Control
See Page E-10
Tab
E-4
Fan Speed Indicator Lights
Plasmacluster
Indicator Light
BACK
INCLUDED
Remote Control (1 unit)
Battery (AA battery x 2 )
• Operation manual
Handle
Air Outlet
Date Label
Power Cord
Power Plug
(shape of plug depends on country)
To Next Page
