Sharp GX-M10 Service Manual

GX-M10
1
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
[1] INTEGRATED CIRCUITS
iC1 VHiMN7992AB-1 AZ CD/USB/iPod DSP
iC2 VHiSA5888TR-1 AG CD Motor Driver, SA5888, 28 Pin
iC3 VHi337S3959-1 AM Apple Authentication IC
iC4 VHiTS3USB++-1 AG USB Switch
iC5 VHiTPS2561D-1 AH Current Limiter Power Switch
iC6 VHiEM638165-1 AR 16 Bit, SDRAM
iC7 RH-iXA347AW00 AL CD DSP Flash Memory IC
iC401 VHiUTC4580E-1 AC Dual Operational Amplifier
iC431 VHiUTC4580E-1 AC Dual Operational Amplifier
iC451 VHiUTC4580E-1 AC Dual Operational Amplifier
iC461 VHiUTC4580E-1 AC Dual Operational Amplifier
iC500 VHiTAS5504A-1 AR Digital Audio PWM
iC550 VHiUTC4580E-1 AC Dual Operational Amplifier
iC580 VHiPCM1808P-1 AH Single Ended Analog
iC590 VHiCD4052BM-1 AE Analog Multiplexer, CD4052
iC600 CH-IXA369AWA5 AV System Microcomputer Ass'y, iXA369AW
iC681 VHiPST8227U-1 AC Reset IC, 2.7V
iC701 VHiPT6533LQ-1 AK LCD Drvier
iC801 VHiBA00BWFP-1 AG Voltage Regulator
iC802 VHiMP2303A+-1 AF DC-DC IC 3A 28V 360Khz
iC803 VHiMC33063A-1 AE DC- DC IC 18V
iC804 VHiMP2303A+-1 AF DC-DC IC 3A 28V 360Khz
iC805 VHi3464A33N-1 AC Voltage Regulator, 3.3V
iC900 VHiTAS5342L-1 AR Digital Amplifier
[2] TRANSISTORS
Q3 VSKTA1271Y/-1 AC Silicon, PNP, KTA1271 Y
Q4 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q5 VS2SK3018//-1 AC N Channel SK3018
Q401 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q402 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q431 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q432 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q461 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q462 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q491 VSKTC3205Y/-1 AD Silicon, NPN, KTC3205 Y
Q492 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q493 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q494 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q551 VSKTC2875B/-1 AC Silicon, NPN, KTC2875 B
Q552 VSKTC2875B/-1 AC Silicon, NPN, KTC2875 B
Q553 VSKRA102S//-1 AB Digital, NPN, KRA102S
Q554 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q591 VSKTC3875GR-1 AB Silicon, NPN, KTC3875 GR
Q593 VSKTC3875GR-1 AB Silicon, NPN, KTC3875 GR
Q671 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q672 VSKTA1504GR-1 AB Silicon, PNP, KTA1504 GR
Q681 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q682 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q701 VSMPS8050S/-1 AB S8050
Q702 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q801 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q803 VSKRC104S//-1 AC Digital, PNP, KRC104S
Q804 VSSSM3J332R-1 AE P-CH FET
[3] DIODES
D200 VHDDA1010++-1 AB Silicon, DA1010
D201 VHDDA1010++-1 AB Silicon, DA1010
D202 VHDDA1010++-1 AB Silicon, DA1010
D203 VHDDA1010++-1 AB Silicon, DA1010
D301 VHDDA1010++-1 AB Silicon, DA1010
D302 VHDDA1010++-1 AB Silicon, DA1010
D451 VHDDA1010++-1 AB Silicon, DA1010
D452 VHDDA1010++-1 AB Silicon, DA1010
D551 VHDDA1010++-1 AB Silicon, DA1010
D552 VHDDA1010++-1 AB Silicon, DA1010
D571 VHDDA1010++-1 AB Silicon, DA1010
D572 VHDDA1010++-1 AB Silicon, DA1010
D573 VHDDA1010++-1 AB Silicon, DA1010
D574 VHDDA1010++-1 AB Silicon, DA1010
D601 VHDGS1GLTP+-1 AB Rectifier, GS1GLTP
D602 VHDGS1GLTP+-1 AB Rectifier, GS1GLTP
D603 VHDDA1010++-1 AB Silicon, DA1010
D604 VHDDA1010++-1 AB Silicon, DA1010
D681 VHDDA1010++-1 AB Silicon, DA1010
D781 VHDDA1010++-1 AB Silicon, DA1010
D782 VHDDA1010++-1 AB Silicon, DA1010
D783 VHDDA1010++-1 AB Silicon, DA1010
D784 VHDDA1010++-1 AB Silicon, DA1010
D802 VHDDA1010++-1 AB Silicon, DA1010
D804 VHDDA1010++-1 AB Silicon, DA1010
D806 VHDDA1010++-1 AB Silicon, DA1010
D808 VHDDA1010++-1 AB Silicon, DA1010
D810 VHDDA1010++-1 AB Silicon, DA1010
D812 VHDDA1010++-1 AB Silicon, DA1010
D813 VHDDA1010++-1 AB Silicon, DA1010
