Sharp GX-M10 Service Manual

GX-M10
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
D814 VHDDA1010++-1 AB Silicon, DA1010
D901 VHDRB521M30-1 AB Schottky Diode
DZ451 RH-EXA680WJQZ AB Zener, 2.4V
DZ801 RH-EXA741WJQZ AB Zener, 5.6V
DZ802 RH-EXA701WJQZ AB Zener, 6.8V
DZ803 RH-EXA718WJQZ AB Zener
DZ804 RH-EXA701WJQZ AB Zener, 6.8V
DZ805 RH-EXA701WJQZ AB Zener, 6.8V
DZ806 RH-EXA732WJQZ AB Zener, 27V
DZ807 VHDGDSK14++-1 AC Schottky Diode
LED701 VHPSLR343VC3F AC LED, Red
LED704 VHPM3NR2UDO-1 AC LED, Red ( Red Version )
LED705 VHPM3NR2UDO-1 AC LED, Red ( Red Version )
LED706 VHPM3NR2UDO-1 AC LED, Red ( Red Version )
LED707 VHPM3NR2UDO-1 AC LED, Red ( Red Version )
LED704 VHPSLi343YC3F AD LED, Yellow ( Orange and Gun Metal Version )
LED705 VHPSLi343YC3F AD LED, Yellow ( Orange and Gun Metal Version )
LED706 VHPSLi343YC3F AD LED, Yellow ( Orange and Gun Metal Version )
LED707 VHPSLi343YC3F AD LED, Yellow ( Orange and Gun Metal Version )
SD802 VHDRB080L30-1 AD Schottky Barrier
SD805 VHDGDSK52B+-1 AE Schottky Diode
[4] COILS
C96 RFiLNA023AFZZ AB Ferrite Bead
C532 RFiLNA023AFZZ AB Ferrite Bead
C533 RFiLNA023AFZZ AB Ferrite Bead
C534 RFiLNA023AFZZ AB Ferrite Bead
FB41 RBLN-0077TAZZ AB Balun
FB42 RBLN-0006TAZZ AA Balun
FB451 RBLN-A012AWZZ AA Ferrite Bead
FB501 RFiLN5044NCPZ AB Ferrite Bead
FB502 RBLN-0077TAZZ AB Balun
FB651 RBLN-A012AWZZ AB Ferrite Bead
FB781 RBLN-0081TAZZ AA Ferrite Bead, 100MHz 600 Ohm
FB803 RBLN-0210TAZZ AB Ferrite Bead
FB804 RBLN-0210TAZZ AB Ferrite Bead
FB902 RBLN-0077TAZZ AB Balun
FB903 RBLN-0077TAZZ AB Balun
L1 VPBNN100K0000 AC Peaking Coill, 10 µH
L2 VPBNN100K0000 AC Peaking Coill, 10 µH
L802 RCiLPB299WJQZ AC Coil, 10 µH
L803 RCiLZA100AWZZ AF Coil, 150 µH
L804 RCiLPB157WJQZ AD Coil, 10 µH
L806 RCiLZ2130SCT5 AC Coil
L807 RCiLZ2130SCT5 AC Coil
L808 RCiLZ2130SCT5 AC Coil
L809 RBLN-0207TAZZ AB Ferrite Bead
L810 RCiLZ2130SCT5 AC Coil
L901 RCiLPB299WJQZ AC Coil, 10 µH
L902 RCiLPB299WJQZ AC Coil, 10 µH
L903 RCiLZ0055AWZZ AH Coil
L904 RCiLZ0055AWZZ AH Coil
L905 RCiLZA094AWZZ AK Coil, 10 µH
L906 RCiLZ0055AWZZ AH Coil
L907 RCORF0015AWZZ AB Coil, 10 µH
R45 RBLN-A012AWZZ AB Ferrite Bead
R50 RBLN-0077TAZZ AB Balun
R51 RFiLNA024AWZZ AB Ferrite Bead
R55 RBLN-A019AWZZ AA Ferrite Bead
R56 RBLN-A019AWZZ AA Ferrite Bead
R57 RBLN-A019AWZZ AA Ferrite Bead
R60 RBLN-A012AWZZ AB Ferrite Bead
R61 RBLN-A012AWZZ AB Ferrite Bead
R73 RBLN-A019AWZZ AA Ferrite Bead
R74 RBLN-A019AWZZ AA Ferrite Bead
R75 RBLN-A019AWZZ AA Ferrite Bead
R76 RFiLNA023AFZZ AB Ferrite Bead
R503 RBLN-0061TAZZ AB Balun
R504 RFiLNA023AFZZ AB Ferrite Bead
R505 RFiLNA023AFZZ AB Ferrite Bead
R506 RFiLNA023AFZZ AB Ferrite Bead
R507 RFiLNA023AFZZ AB Ferrite Bead
R513 RFiLNA023AFZZ AB Ferrite Bead
R535 RFiLNA023AFZZ AB
Ferrite Bead
R575 RBLN-0061TAZZ AB Balun
R576 RBLN-0061TAZZ AB Balun
R581 RFiLNA023AFZZ AB Ferrite Bead
R582 RBLN-A019AWZZ AA Ferrite Bead
R583 RBLN-A019AWZZ AA Ferrite Bead
R584 RBLN-A019AWZZ AA Ferrite Bead
JP250 RBLN-0081TAZZ AA Ferrite Bead, 100MHz 600 Ohm
JP252 RBLN-0081TAZZ AA Ferrite Bead, 100MHz 600 Ohm
L701 VPBNN100K0000 AC Peaking Coill, 10 µH
CORE1 RCORFA033AWZZ AG Ferrite Core, Ring
CORE2 RCORFA034AWZZ AD Ferrite Core, Ring
CORE3 RCORFA034AWZZ AD Ferrite Core, Ring
CORE4 RCORFA034AWZZ AD Ferrite Core, Ring
CORE5 RCORFA034AWZZ AD Ferrite Core, Ring
[3] DIODES
