Sharp GX-M10 Service Manual

GX-M10
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
[5] CRYSTALS / VIBRATORS
X1 RCRSPA038AWZZ AD Crystal, 33.8688 MHz
X501 RCRSPA039AWZZ AD Crystal, 13.50 MHz
X601 RCRSPA037AWZZ AD Crystal, 32.768 KHz
[6] CAPACITORS
C2 VCKYCZ1EF104Z AA 0.1 µF, 25V
C3 VCCCCY1HH222J AB 2200 pF, 50V
C4 VCKYCY1HB472K AA 4700 pF, 50V
C5 VCKYCY1EF104Z AA 0.1 µF, 25V
C6 VCKYCZ1EF104Z AA 0.1 µF, 25V
C7 VCKYCZ1EF104Z AA 0.1 µF, 25V
C8 VCKYCY1HB152K AA 2200 pF, 50V
C9 VCKYCY1HB123K AB 0.012 µF, 50V
C10 VCKYCY1EF104Z AA 0.1 µF, 25V
C12 VCKYCZ1EF104Z AA 0.1 µF, 25V
C14 VCKYCZ1EF104Z AA 0.1 µF, 25V
C15 VCKYCY1EF104Z AA 0.1 µF, 25V
C20 VCKYCY1EF104Z AA 0.1 µF, 25V
C21 VCKYCY1EF104Z AA 0.1 µF, 25V
C22 VCKYCY1EF104Z AA 0.1 µF, 25V
C23 VCKYCY1EF104Z AA 0.1 µF, 25V
C24 VCKYCY1EF104Z AA 0.1 µF, 25V
C25 VCKYCY1EF104Z AA 0.1 µF, 25V
C26 VCKYCY1EF104Z AA 0.1 µF, 25V
C27 VCKYCY1HB103K AA 0.01 µF, 50V
C28 VCKYCZ1EF104Z AA 0.1 µF, 25V
C29 VCKYCY1EF104Z AA 0.1 µF, 25V
C30 VCCCCY1HH151J AA 150 pF (CH), 50V
C31 VCKYCY1AB105K AB 1 µF, 10V
C32 VCKYCZ1EF104Z AA 0.1 µF, 25V
C33 VCKYCZ1EF104Z AA 0.1 µF, 25V
C34 VCKYCY1EF104Z AA 0.1 µF, 25V
C37 VCKYCZ1EF104Z AA 0.1 µF, 25V
C38 VCKYTV1EB106K AC 10 µF, 50V
C39 VCKYCY1AB334K AC 0.33 µF, 10V
C40 VCKYTV1EB475K AB 4.7 µF, 25V, Electrolytic
C41 VCKYCZ1EF104Z AA 0.1 µF, 25V
C42 VCKYCY1EF104Z AA 0.1 µF, 25V
C43 VCKYCZ1EF104Z AA 0.1 µF, 25V
C44 VCKYCY1AB105K AB 1 µF, 10V
C45 VCKYCY1EF104Z AA 0.1 µF, 25V
C47 VCKYCZ1EF104Z AA 0.1 µF, 25V
C48 VCKYTV1EB106K AC 10 µF, 50V
C49 VCKYCZ1EF104Z AA 0.1 µF, 25V
C50 VCKYCZ1EF104Z AA 0.1 µF, 25V
C51 VCKYCZ1EF104Z AA 0.1 µF, 25V
C52 VCKYCY1AB334K AC 0.33 µF, 10V
C54 VCKYTV1EB106K AC 10 µF, 50V
C55 VCKYCY1HB223K AA 0.022 µF, 50V
C56 VCCCCZ1HH680J AB 68 pF (CH), 50V
C57 VCKYTV1EB106K AC 10 µF, 50V
C58 VCKYCY1HB332K AA 3300 pF, 50V
C59 VCKYCY1HB332K AA 3300 pF, 50V
C60 VCKYCZ1EF104Z AA 0.1 µF, 25V
C61 VCCCCZ1HH681J AH 680 pF (CH), 50V
C62 VCKYCY1HB223K AA
0.022 µF, 50V
C63 VCKYCY1HB102K AA 1000 pF, 50V
C64 VCKYCY1CB823K AB 0.082 µF, 16V
C65 VCKYCY1AB334K AC 0.33 µF, 10V
C66 VCKYCZ1HB102K AB 1000 pF, 50V
C67 VCKYCY1EF104Z AA 0.1 µF, 25V
C68 VCKYTV1EB106K AC 10 µF, 50V
C69 VCKYCZ1EF104Z AA 0.1 µF, 25V
C70 VCCCCY1HH180J AA 18 pF (CH), 50V
C71 VCCCCY1HH180J AA 18 pF (CH), 50V
C72 VCKYCZ1EF104Z AA 0.1 µF, 25V
C73 VCKYTV1EB225K AB 2.2 µF, 25V
C74 VCKYCZ1EF104Z AA 0.1 µF, 25V
C75 VCKYCY1EF104Z AA 0.1 µF, 25V
C76 VCKYCY1EF104Z AA 0.1 µF, 25V
C77 VCKYCZ1EF104Z AA 0.1 µF, 25V
C78 VCKYCZ1EF104Z AA 0.1 µF, 25V
C79 VCCCCZ1HH330J AB 33 pF (CH), 50V
C80 VCCCCZ1HH330J AB 33 pF (CH), 50V
C81 VCCCCZ1HH330J AB 33 pF (CH), 50V
C82 VCCCCZ1HH330J AB 33 pF (CH), 50V
C83 VCCCCZ1HH330J AB 33 pF (CH), 50V
C84 VCCCCZ1HH330J AB 33 pF (CH), 50V
C85 VCCCCY1HH330J AA 33 pF (CH), 50V
C86 VCCCCY1HH330J AA 33 pF (CH), 50V
C87 VCCCCY1HH330J AA 33 pF (CH), 50V
C89 VCKYCZ1EF104Z AA 0.1 µF, 25V
C90 VCKYCY1AB105K AB 1 µF, 10V
C91 VCKYCY1EF104Z AA 0.1 µF, 25V
C92 VCKYCY1EF104Z AA 0.1 µF, 25V
C93 VCKYCY1EF104Z AA 0.1 µF, 25V
C94 VCKYCZ1EF104Z AA 0.1 µF, 25V
C95 VCKYCZ1EF104Z AA 0.1 µF, 25V
C97 VCKYCY1HB102K AA 1000 pF, 50V
