Sharp GX-M10 Service Manual

GX-M10
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
[9] CABINET PARTS / CD MECHANISM PARTS
201 CCABA8678AW02 Front Cabinet Ass'y [ For ORANGE Version ]
201 CCABA8761AW02 Front Cabinet Ass'y [ For RED Version ]
201 CCABA8858AW02 Front Cabinet Ass'y [ For GUN METAL Version ]
202 GCABBA121AWSA Back Cabinet
203 GCABCA110AWSA AR Top Cabinet
204 GCOVAA375AWSA AD Cover, Timer Top
205 GCOVAA376AWZZ AE Cover, Battery (Left)
206 GCOVAA377AWZZ AE Cover, Battery (Right)
207 GCOVAA389AWSA AF Cover, iPod
208 GDORFA058AWSA AK Door, iPod
209 GDORFA059AWSA AN Door, CD
210 GFTABA012AWSA AH Cover, Battery
211 GiTASA300AW02 AS Side Cabinet Ass'y
212 HDECQA643AWSA AG Panel, iPod Door
213 HDECQA644AWSA AF Decoration Panel, Display
214 HDECQA649AW01 AM Panel, LCD Backlight [ For ORANGE and GUN METAL Version ]
214 HDECQA681AW01 AM Panel, LCD Backlight [ For RED Version ]
215 HDECQA701AWSA Decoration Panel, Front (Left) [ For ORANGE Version ]
215 HDECQA650AWSB AQ Decoration Panel, Front (Left) [ For RED Version ]
215 HDECQA650AWSC AP Decoration Panel, Front (Left) [ For GUN METAL Version ]
216 HDECQA702AWSA Decoration Panel, Front (Right) [ For ORANGE Version ]
216 HDECQA651AWSB AQ Decoration Panel, Front (Right) [ For RED Version ]
216 HDECQA651AWSC AP Decoration Panel, Front (Right) [ For GUN METAL Version ]
217 HDECQA703AWSA Decoration Panel, Top (Left) [ For ORANGE Version ]
217 HDECQA652AWSB AM Decoration Panel, Top (Left) [ For RED Version ]
217 HDECQA652AWSC AL Decoration Panel, Top (Left) [ For GUN METAL Version ]
218 HDECQA704AWSA Decoration Panel, Top (Right) [ For ORANGE Version ]
218 HDECQA653AWSB AM Decoration Panel, Top (Right) [ For RED Version ]
218 HDECQA653AWSC AL Decoration Panel, Top (Right) [ For GUN METAL Version ]
219 HDECQA705AWSA Decoration Panel, Bottom (Left) [ For ORANGE Version ]
219 HDECQA654AWSB AL Decoration Panel, Bottom (Left) [ For RED Version ]
219 HDECQA654AWSC AL Decoration Panel, Bottom (Left) [ For GUN METAL Version ]
220 HDECQA706AWSA Decoration Panel, Bottom (Right) [ For ORANGE Version ]
220 HDECQA655AWSB AL Decoration Panel, Bottom (Right) [ For RED Version ]
220 HDECQA655AWSC AL Decoration Panel, Bottom (Right) [ For GUN METAL Version ]
221 JKNBKA079AWSA AC Button, Mic
222 JKNBZA339AWSA AG Button, Function
223 JKNBZA340AWSA AC Button, Eject iPod Door [ For ORANGE Version ]
223 JKNBZA340AWSB AC Button, Eject iPod Door [ For RED Version ]
223 JKNBZA340AWSC AC Button, Eject iPod Door [ For GUN METAL Version ]
224 JKNBZA341AWSA AC Button, Eject CD Door [ For ORANGE Version ]
224 JKNBZA341AWSB AC Button, Eject CD Door [ For RED Version ]
224 JKNBZA341AWSC AC Button, Eject CD Door [ For GUN METAL Version ]
225 LANGKA257AWFW AF Bracket, Jack Support
226 LANGKA261AWFW AE Bracket, PWB Support
227 LANGKA262AWFW AE Bracket, PWB Support
228 LANGKA263AWFW AD Bracket, Antenna Support
229 LCHSMA130AWFW AH Chassis, Main (SMPS)
230 LHLDZA298AWSA AC Holder, Eject iPod Door [ For ORANGE Version ]
230 LHLDZA298AWSB AC Holder, Eject iPod Door [ For RED Version ]
230 LHLDZA298AWSC AC
Holder, Eject iPod Door [ For GUN METAL Version ]
231 LHLDZA299AWZZ AC Holder, Timer LED
232 LHLDZA300AWZZ AC Holder, Flashing LED
233 LHLDZA325AWZZ Holder, PWB
234 LHLDZA302AWZZ AF Holder, iPod
235 LHLDZA303AWSA AC Holder, Eject CD Door [ For ORANGE Version ]
235 LHLDZA303AWSB AC Holder, Eject CD Door [ For RED Version ]
235 LHLDZA303AWSC AC Holder, Eject CD Door [ For GUN METAL Version ]
236 LPLTMA008AWFW AC Plate, Battery Terminal
237 MLiF-A001AWZZ AD Damper
238 MLiF-A002AWZZ AD Damper
239 MSPRCA018AWFJ AB Spring
240 MSPRCA019AWFJ AD Spring, Battery
241 MSPRDA049AWFJ AC Spring
242 MSPRDA050AWFJ AD Spring, CD Door
243 PCOVZA012AWZZ AL Speaker Cup
244 PCUSGA234AWZZ AG Cushion, Leg A
245 PCUSGA235AWZZ AG Cushion, Leg B
246 PCUSSA272AWZZ Cushion, Speaker
247 PCUSSA246AWZZ AB Cushion, Seal A
248 PCUSSA267AWZZ Cushion, Duct Port
249 PCUSSA254AWZZ AC Cushion, Seal (Cup)
250 PCUSSA257AWZZ AB Cushion, Seal B
251 PCUSSA259AWZZ AB Cushion, Seal C
252 PCUSSA260AWZZ AB Cushion, Seal D
253 PCUSSA263AWZZ AB Cushion
254 PCUSSA264AWZZ AB Cushion
255 PCUSSA265AWZZ AB Cushion
256 PDUC-A123AWZZ AG Duct Port
257 PFLT-A188AWZZ AB Felt, A
258 PFLT-A189AWZZ AB Felt, B
259 PFLT-A190AWZZ AC Felt, C
260 PFLT-A191AWZZ AC Felt, C
261 PFLT-A192AWZZ AB Cushion, D
262 PFLT-A194AWZZ AB Felt, Cover
263 PFLT-A195AWZZ AB Felt
264 PFLT-A196AWZZ AB Felt
265 PFLT-A197AWZZ AD Felt
266 PRDARA229AWFW AL Heat Sink
