Sharp GX-M10 Service Manual

GX-M10
15
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
267 PSHEZA310AWZZ AD Double Sided Tape
268 QANTRA004AWSA AM FM Rod Antenna
269 TLABZC132AWZZ AD Label, iPod/USB Rating
270 TLABZC133AWZZ AE Label, CUL Safety
271 TSPC-B766AWZZ AF Label, Specification [ For ORANGE Version ]
271 TSPC-B767AWZZ Label, Specification [ For RED Version ]
271 TSPC-B812AWZZ AF Label, Specification [ For GUN METAL Version ]
272 92LNBAND1318A AA Nylon Band, 80mm
273 PCUSGA232AWZZ Cushion, CD Door
274 PCUSGA233AWZZ Cushion, iPod Door
275 PCUSSA266AWZZ Cushion
301 KMECZA039AWZZ AY CD Mechanism Unit
302 PCOVPA015AWZZ AD Cover, Dust
303 PCUSG0001AWSA AD Cushion
304 PCUSG0004AWSA AD Cushion
305 PCUSGA099AWSA AC Cushion
SP 1,2 RSP-ZA389AWZZ AY Subwoofer
SP 3,4 RSP-ZA388AWZZ AT Speaker
601 LX-EZ0005AWF7 AA Screw, Special
602 XEBSN30P30000 AB Screw, M3 X30mm
603 XEBY726P08000 AA Screw, M2.6 X8mm
604 XEBY730P06000 AB Screw, M3 X6mm
605 XEBY730P08000 AA Screw, M3 X8mm
606 XEBY730P10000 AA Screw, M3 X10mm
607 XEBY735P10000 AB Screw, M3.5 X10mm
608 XEBY830P10000 AB Screw, M3 X10mm
609 XEPY717P05000 AB Screw, Special
611 XHBY830P10000 AB Screw, M3 X10mm
612 XJBY730P08000 AA Screw, M3 X8mm
[10] ACCESSORIES / PACKING PARTS
1 GiTAUA014AW01 AR Stand for iPad
2 JHNDZA001AW01 AR Carry Strap Ass'y
3 PSPAGA003AWZZ AE iPod Spacer
! 4 QACCD0025AWZZ AN AC Power Supply Cord
5 RRMCGA293AWSA AR Remote Control
6 TiNSKA080AWZZ AE Operation Manual (Francais)
7 TiNSZB414AWZZ AE Operation Manual (English/Espanol)
[11] P.W.B. ASSEMBLY
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
REMARK
(interchangeable)
No. of
PWB cavity
DESCRIPTION
PWB-A 92LPWB8678MANS BY S.X Category 1 Main(A1), iPod (A2), Door Switch (A3)
! PWB-B RUiTZA056AWZZ BK X Category 1 SMPS
PWB-C 92LPWB8678DPLS BK S.X Category 2
Display (C1) / Key (C2) / USB (C3) / Transit (C4) /
Subwoofer Flash (L-CH) (C5) / Subwoofer Flash
(R-CH) (C6) / Battery Terminal 1 (C7) /
Battery Terminal 2 (C8) / AC Inlet (C9)
[ For ORANGE and GUN METAL Version ]
PWB-C 92LPWB8761DPLS BK S.X Category 2
Display (C1) / Key (C2) / USB (C3) / Transit (C4) /
Subwoofer Flash (L-CH) (C5) / Subwoofer Flash
(R-CH) (C6) / Battery Terminal 1 (C7) /
Battery Terminal 2 (C8) / AC Inlet (C9)
[ For RED Version ]
NOTE : FOR CD MECHANISM PARTS, ITEM NO. ARE 3XX
[9] CABINET PARTS / CD MECHANISM PARTS
