– 48 –
HT-CN400DVH/HT-CN400DVE/HT-CN500DVH/HT-CN500DVE
IC106 92LRCI6028-001: Microcomputer (ES6028) (1/5)
1 VEE Input I/O power supply.
2-7 LA4-LA9 Output Device address output.
8 VSS Input Ground.
9 VCC Input Core power supply.
10-16 LA10-LA16 Output Device address output.
17 VSS Input Ground.
18 VEE Input I/O power supply.
19-22*,23* LA17-LA21 Output Device address output.
24 RESET# Input Reset input, active low.
25 TDMDX Output TDM transmit data.
RSEL Input ROM Select.
26 VSS Input Ground.
27 VEE Input I/O power supply.
28 TDMDR Input TDM receive data.
29 TDMCLK Input TDM clock input.
30 TDMFS Input TDM frame sync.
31* TDMTSC# Output TDM output enable.
32 TWS Output Audio transmit frame sync.
SEL_PLL2 Input System and DSCK output clock frequency selection is made at the rising edge of RESET#.
The matrix below lists the available clock frequencies and their respective PLL bit settings.
33 TSD0 Output Audio transmit serial data port 0.
SEL_PLL0 Input Refer to the description and matrix for SEL_PLL2 pin 32.
34 VSS Input Ground.
35 VCC Input Core power supply.
36 TSD1 Output Audio transmit serial data port 1.
SEL_PLL1 Input Refer to the description and matrix for SEL_PLL2 pin 32.
37 TSD2 Output Audio transmit serial data output 2.
38* TSD3 Output Audio transmit serial data output 3
39 MCLK Input/Output Audio master clock for audio DAC.
40 TBCK Output Audio transmit bit clock.
41 SPDIF Output S/PDIF output.
SEL_PLL3 Input Clock source select.
42* N.C. No connect pins. Leave open.
43 VSS Input Ground.
44 VCC Input Core power supply.
45* RSD Input Audio receive serial data.
46* RWS Input Audio receive frame sync.
47* RBCK Input Audio receive bit clock.
48* N.C. No connect pins. Leave open.
49 XIN Input Crystal input.
50 XOUT Output Crystal output.
51 AVEE Input Analog power for PLL.
52 VSS Input Ground.
53 DMA0 Output DRAM address bus 0.
54 DMA1 Output DRAM address bus 1.
55 DMA2 Output DRAM address bus 2.
56 DMA3 Output DRAM address bus 3.
57 DMA4 Output DRAM address bus 4.
58 DMA5 Output DRAM address bus 5.
59 VEE Input I/O power supply.
60 VSS Input Ground.
61 DMA6 Output DRAM address bus 6.
62 DMA7 Output DRAM address bus 7.
Port NamePin No. Input/Output
Function
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
