HT-CN400DVH/HT-CN400DVE/HT-CN500DVH/HT-CN500DVE
– 2 –
TRANSFORMERS
T001 92LSHV8474-001 J OSC FM SUMIDA S-8N
T002 92LSHV0491-101 J ANT OSC AM 4-6:10T 1-3:86T
T003 92LSHV2020-201 J OSC COIL 108uH (796 KHz)
COIL
T004 92LSHV1492-003 J BIAS COIL 78 KHz
T005,006 92LSHV1492-004 J BIAS COIL 16 KHz
T007 92LSHI9725-059 J FM IFT 10.7MHz Q=60 MIN
T008 92LSHI9724-063 J AM IFT 455KHz Q=130
1 T903 92LTSC2002-020 J TRANSFORMER 42/42
1 T904 92LTSC2001-010 J PWR TRANS.EE16/14
COILS
FB101,102 92LSLF0201-006 J BEAD FERIT DIA3.5x6mm
FB103,104 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
FB111~113 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
FB114 92LSLF0201-006 J BEAD FERIT DIA3.5x6mm
FB115 92LSLF0201-006 J BEAD FERIT DIA3.5x6mm
FB116 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
FB121 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
FB600 92LSLF0201-006 J BEAD FERIT DIA3.5x6mm
FB901,902 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
FB903,904 92LSLF0201-006 J BEAD FERIT DIA3.5x6mm
L001 92LSAC7414-100 J CHOKE 10 uH 10%
L002 92LSIL0603C393 J COIL 39 mH 10%
D6xH11xP5mm
L003 92LSAC7414-100 J CHOKE 10 uH 10%
L007 92LSAC7414-100 J CHOKE 10 uH 10%
L103~106 92LSCC0805-249 J CHIP INDUC 2.4 uH 5% SMD
0805
L500~507 92LSIN0202-300 J INDUCTOR 30uH 15% 1KHZ
0.25V 2A
L508~513 92LSIL0201C200 J COMMON MODE CHOKE COIL
20uH D0.5mm 4PIN
L514,515 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
L516~519 92LSIN0202-300 J INDUCTOR 30uH 15% 1KHZ
0.25V 2A
L602,603 92LSCC0805-100 J CHIP INDUC 10 uH 10% SMD
0805
L801,802 92LSCF0805-601 J CHIP BEAD 600 OHM AT
100MHz
L901 92LSIL1061-609 J INDUCTOR 6uH 10.5Ts 6A
L902,903 92LSIL1062-609 J INDUCTOR 6uH 13.5Ts 2UEW
L904 92LSIL2061-100 J 0OIL 10uH 1.5A 10% 1KHZ/0.3V
D0.3mm
1 T901 92LJFT2011-010 J LINE FILTER ET24
VARIABLE CAPACITORS
TC001 92LMCT0510-006 J COND TRIM 3 - 10 PF NP0
TC002 92LMCT0520-005 J COND TRIM 4.2 - 20 PF N450
VD001,002 92LRHT6066-011 J DIODE TUNG AM TOSHIBA
1SV149B
VIBRATORS
XL001 92LJQC6070-450 J CRYSTAL 4.5000 MHz HC-49/U
30PPM
XL002 92LJQC6070-433 J CRYSTAL 4.332 MHZ HC-49/U
30PPM
XL101 92LJQC0391-270 J CRYSTAL 27.0000MHz HC-
49US +/-20ppm
XL301 92LJRN6078-004 J RESONATOR MURATA CSB
455EB
XL801 92LJQC6070-169 J CRYSTAL 16.9344MHz HC-49u
+/-20ppm
THERMISTOR
SN601 92LRNT0050-103 J NTC 10K OHM 5%PA-5D-103J
ARRAY PARTS
RA101,102 92LQCP0158-330 J RES ARRAY 33 OHMx4 1/10W
5%
RA104~106 92LQCP0158-100 J RES ARRAY 10 OHMx4 1/10W
5%
RA117,118 92LQCP0158-472 J RES ARRAY 4x4.7K 1/10W 5%
RA801~803 92LQCP0158-100 J RES ARRAY 10 OHMx4 1/10W
5%
CAPACITORS
C001 92LPCX1035-330 J CHIP CAP 33 pF 50V 5%
C003 92LPCX1035-509 J CHIP CAP 5 pF 50V 5%
C004 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C006,007 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C008~011 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C012 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C013 92LPCX1035-509 J CHIP CAP 5 pF 50V 5%
C014 92LPCX1035-561 J CHIP CAP 560 pF 50V 5%
C016 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C017 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C018 92LPRE3952-330 J COND ELECT 33 uF 16 V 20%
C019 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C020 92LPRE3952-330 J COND ELECT 33 uF 16 V 20%
C021 92LPME3954-220 J COND ELECT 22 uF 16V 20%
C022 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C023 92LPME3955-100 J COND ELECT 10 uF 50V 20%
C024 92LPCX1035-221 J CHIP CAP 220 pF 50V 5%
C025 92LPCX1035-300 J CHIP CAP 30 pF 50V 5%
C026 92LPCX5645-473 J CHIP CAP 0.047 uF 50V 10%
C027 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C028 92LPCX5632-273 J CHIP CAP 0.027 uF 16V 5%
C029 92LPCX5645-473 J CHIP CAP 0.047 uF 50V 10%
C030 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C031 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C032 92LPCX3955-105 J CHIP CAP 1uF 50V 20%
C033 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C034 92LPCX1035-220 J CHIP CAP 22 pF 50V 5%
C036 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C037 92LPCX3955-105 J CHIP CAP 1uF 50V 20%
C038 92LPCX3962-474 J CHIP CAP 0.47 uF 16V +80%-
20%
C039,040 92LPME3955-100 J COND ELECT 10 uF 50V 20%
C041 92LPCX3955-105 J CHIP CAP 1uF 50V 20%
C042,043 92LPCX5645-222 J CHIP CAP 0.0022 uF 50V 10%
C044,045 92LPCX5645-472 J CHIP CAP 0.0047uF 50V 10%
C046,047 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C048,049 92LPCX5645-152 J CHIP CAP 0.0015 uF 50V 10%
C050 92LPCX5645-153 J CHIP CAP 0.015 uF 50V 10%
C051 92LPME3957-479 J COND ELECT 4.7 uF 50V 20%
C052 92LPCX5645-153 J CHIP CAP 0.015 uF 50V 10%
C053 92LPME3957-479 J COND ELECT 4.7 uF 50V 20%
C054 92LPCX5645-472 J CHIP CAP 0.0047uF 50V 10%
C055 92LPCX5645-472 J CHIP CAP 0.0047uF 50V 10%
C056 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C057,058 92LPCX1035-150 J CHIP CAP 15 pF 50V 5%
C059 92LPCX1035-101 J CHIP CAP 100 pF 50V 5%
C060 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C061 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C062 92LPME3957-339 J COND ELECT 3.3 uF 50V 20%
C063 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C064 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C065 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C066 92LPCX1035-102 J CHIP CAP 1000 pF 50V 5%
C067,068 92LPCX1035-220 J CHIP CAP 22 pF 50V 5%
C069 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C070 92LPCX1035-561 J CHIP CAP 560 pF 50V 5%
C071 92LPME3954-470 J COND ELECT 47 uF 16V 20%
C072 92LPME3955-100 J COND ELECT 10 uF 50V 20%
C073,074 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C075 92LPCX1035-331 J CHIP CAP 330 pF 50V 5%
C076,077 92LPCX5645-223 J CHIP CAP 0.022 uF 50V 10%
C1 92LPRL4855-105 J COND MULTI 1 uF 50V 20%
C41,42 92LPME3955-100 J COND ELECT 10 uF 50V 20%
C81 92LPCX1035-221 J CHIP CAP 220 pF 50V 5%
C100 92LPCX1035-100 J CHIP CAP 10 pF 50V 5%
C101 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C102 92LPME3955-100 J COND ELECT 10 uF 50V 20%
C103~107 92LPCX3955-104 J CHIP CAP 0.1 uF 50V 20%
C108 92LPME3955-100 J COND ELECT 10 uF 50V 20%
