Sharp HT-DV30H - Page 62

HT-DV30H
6 – 34
Figure 6-29a: WIRING SIDE OF POWER, MINUS FEEDBACK PWB (TOP VIEW) (1/2)
AC POWER SUPPLY
CORD (233)
AC 220-240V~50Hz
WH
BK
ECB
area enclosed by this line( )
When Servicing, pay attention as the
is directly connected with AC main
voltage.
1
2
3
4
5
6
7
8
9
2
4
N
POWER PWB-B1
Lead-free solder indication
Lead-free solder is used in the POWER, MINUS FEEDBACK PWB.
Refer to "Precautions for handling lead-free solder" for instructions
and precautions.
A
B
C
D
E
F
G
H
1
23456
