Figure 6-33: WIRING SIDE OF DISPLAY PWB (TOP VIEW) (1/2)
123456789
10 11 12 13 14 15 16 17 18 19
20
21 22 23 24 25 26 27 28 303129
1234
Lead-free solder indication
Lead-free solder is used in the DISPLAY PWB.
Refer to "Precautions for handling lead-free solder" for instructions
and precautions.
DISPLAY PWB-B2
