HT-DV30H
10
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
CP635 VCCCCY1HH221J AA 220 pF (CH),50V
CP636 VCKYCY1HB104K AD 0.1 µ F,50V
CP637 VCEAZA1HW105M AB 1 µ F,50V,Electrolytic
CP638 VCEAZA1HW105M AB 1 µ F,50V,Electrolytic
[8] THERMISTORS
R802 RH-QX1067AFZZ AE Thermistor
R805 RH-QX1067AFZZ AE Thermistor
! TH901 RH-QXA001AWZ AH Thermistor
! THM1 RH-QX0006AWZZ AE Posistor
VA1 RH-VXA074WJZZ AC Varistor
VA2 RH-VXA074WJZZ AC Posistor
VA3 RH-VXA074WJZZ AC Varistor
VA4 RH-VXA074WJZZ AC Varistor
VA5 RH-VXA074WJZZ AC Varistor
VA6 RH-VXA074WJZZ AC Varistor
VA7 RH-VXA074WJZZ AC Varistor
VA8 RH-VXA074WJZZ AC Varistor
VA9 RH-VXA074WJZZ AC Varistor
VA10 RH-VXA074WJZZ AC Varistor
VA11 RH-VXA074WJZZ AC Varistor
VA12 RH-VXA074WJZZ AC Varistor
! VA900 VHVSVS14K42-1 AF Varistor
[9] RESISTORS
CM19 VRS-CY1JB102J AA 1 kohms,1/16W
JF3 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JF4 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP701 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP801 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP807 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP810 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP812 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP813 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP814 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP815 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP816 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP820 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP821 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP822 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP824 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP826 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
JP901 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
JP903 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
L207 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
L208 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
L209 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
L210 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
R1 VRS-CY1JB391J AA 390 ohms,1/16W [ Use in DVD PWB-C ]
R1 VRS-CY1JB103J AA
10 kohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R2 VRS-CY1JB101J AA 100 ohms,1/16W [ Use in DVD PWB-C ]
R2 VRS-CY1JB822J AA
8.2 kohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R3 VRS-CY1JB101J AA 100 ohms,1/16W [ Use in DVD PWB-C ]
R3 VRS-CY1JB103J AA
10 kohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R4 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm [ Use in DVD PWB-C ]
R4 VRS-CY1JB272J AA
2.7 kohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R5 VRS-CY1JB471J AA
470 ohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R6 VRS-CY1JB103J AA
10 kohms,1/16W [ Use in MINUS FEEDBACK PWB-D &
Use for S/No 71100020 ~ 71200719 only]
R8 VRS-CY1JB1R0J AA 1 ohms,1/16W
R9 VRS-CY1JB154J AA 150 kohms,1/16W
R10 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R11 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R12 VRS-CY1JB3R3J AA 3.3 ohms,1/16W
R16 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R18 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R21 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R22 VRS-CY1JB154J AA 150 kohms,1/16W
R23 VRS-CY1JB474J AA 470 kohms,1/16W
R24 VRS-CY1JB104J AA 100 kohms,1/16W
R25 VRS-CY1JB104J AA 100 kohms,1/16W
R27 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
R29 VRS-CY1JB3R3J AA 3.3 ohms,1/16W
R30 VRS-CY1JB471J AA
470 ohms,1/16W
R32 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R33 VRS-CY1JB471J AA 470 ohms,1/16W
R34 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R36 VRS-CY1JB474J AA 470 kohms,1/16W
R37 VRS-CY1JB2R2J AA 2.2 ohms,1/16W
R38 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R43 VRS-TV2AB000J AA 0 ohms,Jumper,1.25x2mm
R45 VRS-CY1JB000J AA 0 ohms,Jumper,0.8x1.55mm
R46 VRS-CY1JB222J AA 2.2 kohms,1/16W
[7] CAPACITORS
