TROUBLESHOOTING GUIDE
Is setting of color
normal?
Is the color signal
received?
Is there color signal at
IC800?
Adjust the color.
Receive the color signal.
Check
IC800 and peripheral
circuit.
No
THE COLOR DOES NOT
APPEAR
Yes
No
Yes
No
E-4
Change DIGIT
AL PCB.
Yes
E-4
29
31
Table of Contents
Table of Contents
1
Impotant Warning
2
Servicing Notices on Checking
3
How to Order Parts
3
Important
3
When Replacing DVD Deck
4
Preparation of Servicing
4
Disc Removal Method at no Power Supply
5
ABOUT LEAD FREE SOLDER (Pbf)
6
Hotel Mode Function
7
General Specifications
8
Disassembly Instructions
14
Service Mode List
24
Servicing Fixtures and Tools
25
Re-Write for DVD Firmware
25
Parts Location Guide (Wiring Connection
26
Troubleshooting Guide
27
DVD Block Diagram
36
Printed Circuit Boards
46
Sound Amp
65
Schematic Diagrams
65
Waveforms
65
Mechanical Exploded Views
69
DVD Deck Exploded Views
70
