TROUBLESHOOTING GUIDE
(DVD SECTION)
DOES NOT
DISPLAY DVD
Does this display
logo picture?
Does IC4001 gets
P.CON+3.3V and
P.CON+1.8V?
Check
pins 8 and 10 of
CP8501 and peripheral circuit.
Yes
No
Yes
Change IC4001.
Check the disc.
Yes
No
Does this have signal
at pins 102 and 103 of
IC4001?
E-5
Check P.CON+3.3V and
P.CON+1.8V line.
No
E-5
30
32
Table of Contents
Table of Contents
1
Impotant Warning
2
Servicing Notices on Checking
3
How to Order Parts
3
Important
3
When Replacing DVD Deck
4
Preparation of Servicing
4
Disc Removal Method at no Power Supply
5
ABOUT LEAD FREE SOLDER (Pbf)
6
Hotel Mode Function
7
General Specifications
8
Disassembly Instructions
14
Service Mode List
24
Servicing Fixtures and Tools
25
Re-Write for DVD Firmware
25
Parts Location Guide (Wiring Connection
26
Troubleshooting Guide
27
DVD Block Diagram
36
Printed Circuit Boards
46
Sound Amp
65
Schematic Diagrams
65
Waveforms
65
Mechanical Exploded Views
69
DVD Deck Exploded Views
70
