ELECTRICAL REPLACEMENT PARTS LIST
*** OTHERS ***
CP801
9JD06GG240029
CONNECTOR PCB SIDE
A2001WV-4A
CP802
9JD06G5AA1002
CONNECTOR PCB SIDE
USB-A1D102F-4B4N
CP803
9JD06GG260029
CONNECTOR PCB SIDE
A2001WV-6A
CP3601
9JD06GDYL3038
CONNECTOR PCB SIDE
1A0300030
CP4301
9JD06G7S21501
CONNECTOR PCB SIDE
WD-00021-R
CP5801
9JD06GF2G0020
CONNECTOR PCB SIDE
WD-00028-R
DVD MT PCB ASS'Y
*** PCB ***
PCB130
9JDA54C01A130M
DVD MT PCB ASS'Y
DMJ116A
*** DIODES ***
D2301
9JDDDARR730E0
DIODE SCHOTTKY BARRIER
KDR730E-RTK/P
D2302
9JDDDARR730E0
DIODE SCHOTTKY BARRIER
KDR730E-RTK/P
D4001
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
*** ICS ***
!
IC2301
9JDI1UFV5766S
5CH MOTOR DRIVER IC
AM5766
IC4001
9JDIC8K0389LD
DVD MPEG 128PIN MEDIATEK
MT1389DE/L-L
IC4004
-----
MEMORY DATA FLASH 16M SPI 8PIN
AT25DF161-SH-T
IC4005
9JDIGXJ01620F
SDRAM 64M CL=2
HY57V641620FTP-7
IC8501
9JDI0QF045650
DUAL OPEAMP
NJM4565M(TE1)
IC8502
9JDI1ZF981D50
REGULATOR 1.8V
RP131H181D5-T1-F
*** TRANSISTORS ***
Q2301
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q2301
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q2302
9JDTAAA1505SY
TRANSISTOR SILICON
KTA1505S-Y-RTK/P
Q2303
9JDTAAA1505SY
TRANSISTOR SILICON
KTA1505S-Y-RTK/P
Q2304
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q2305
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q8506
9JDT27T035410
FET
2SK3541_T2L
Q8507
9JDT27T035410
FET
2SK3541_T2L
*** COILS ***
B4003
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B4007
9JD024AC5221F
CORE,BEADS
BLM18BD221SN1D
B4008
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B4010
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B4012
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B8501
9JD024HC51216
CORE,BEADS
HCB1608KF-121T20
B8502
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B8503
9JD024HC51216
CORE,BEADS
HCB1608KF-121T20
B8504
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
L8501
9JD021ES11R8K
COIL
1.8 UH
*** CONNECTORS ***
CP2301
9JD069KYOT159
CONNECTOR PCB SIDE
LD07T2-24ND-03
CP2302
9JD069EV5T01G
CONNECTOR PCB SIDE
04 6232 405 008 868+
CP2303
9JD069EV4T01G
CONNECTOR PCB SIDE
04 6232 404 008 868+
*** CRYSTAL & CERAMIC OSCILLATORS ***
X4001
9JD100GT02727
CRYSTAL
SMD-49 C27000J029
*** NETWORKS ***
NR4002
9JD11074330M7
R,NETWORK
CRA108330JV
*** OTHERS ***
CP8501
9JD06GG2E0019
CONNECTOR PCB SIDE
A2001WR-14A
CP8502
9JD06GG280019
CONNECTOR PCB SIDE
A2001WR-8A
SH8501
9JD126D000045
TERMINAL PIN
YQ-12
SH8502
9JD126D000045
TERMINAL PIN
YQ-12
K3-4
