Sharp LC-22DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
POWER PCB ASS'Y
*** PCB ***
PCB240
9JDA54C01A240M
POWER PCB ASS'Y
CEJ511A
*** RESISTORS ***
!
R505
9JDRC31X1125J
RC
1.2M OHM 1W
!
R506
9JDRC31X1126J
RC
12M OHM 1W
!
R507
9JDR63881R22J
R,FUSE
0.22 OHM 1W
!
R510
9JDRC31X1224J
RC
220K OHM 1W
!
R516
9JDR3K78AR56J
R,METAL OXIDE
0.56 OHM 2W
!
R518
9JDR002T4101J
RC
100 OHM 1/4W
!
R7023
9JDR63884100J
R,FUSE
10 OHM 1/4W
*** CAPACITORS ***
!
C501
9JDP4K12D224K
CMPP
0.22 UF 310V
!
C502
9JDCE39E0M13M
CC
0.001 UF 250V E
!
C503
9JDCE39E0M13M
CC
0.001 UF 250V E
!
C504
9JDE8E1F1222D
CE
2200 UF 10V
!
C505
9JDCE39E0M13M
CC
0.001 UF 250V E
!
C506
9JDCE39E0M13M
CC
0.001 UF 250V E
!
C507
9JDP4K12D104K
CMPP
0.1 UF 310V
!
C508
9JDE83FHH101D
CE
100 UF 400V
!
C511
9JDE8EYF4221M
CE
220 UF 35V
!
C514
9JDCS0PB0415K
CC
0.1 UF 50V B
!
C515
9JDC03L0R7H2K
CC
220 PF 2KV R
!
C516
9JDC0PLRR7H2K
CC
220 PF 2KV R
!
C517
9JDP3N5F5103J
CPP
0.01UF 630V PP
!
C519
9JDE8E2U5470D
CE
47 UF 50V
!
C519
9JDE8E2U5470D
CE
47 UF 50V
!
C520
9JDE8E2U54R7D
CE
4.7 UF 50V
!
C522
9JDE8E1F3102M
CE
1000 UF 25V
!
C524
9JDE8E2U54R7D
CE
4.7 UF 50V
!
C525
9JDE7EYF4102M
CE
1000 UF 35V
!
C528
9JDCE39E0M13M
CC
0.001 UF 250V E
!
C529
9JDCE39E0M13M
CC
0.001 UF 250V E
C7023
9JDC339SLBE1J
CC
15 PF 6KV SL
C7026
9JDC339SLBE1J
CC
15 PF 6KV SL
C7027
9JDC339SLBE1J
CC
15 PF 6KV SL
C7030
9JDC339SLBE1J
CC
15 PF 6KV SL
*** DIODES ***
!
D503
9JDD7KE103820
DIODE VARISTA
S10K385E2S5M4
!
D505
9JDDOU011020M
DIODE VARISTA
DA38-102MB-M
!
D506
9JDD2WTRM11C0
DIODE SILICON
RM11C-EIC
!
D507
9JDD2WTRM11C0
DIODE SILICON
RM11C-EIC
!
D508
9JDD2WTRM11C0
DIODE SILICON
RM11C-EIC
!
D509
9JDD2WTRM11C0
DIODE SILICON
RM11C-EIC
!
D510
9JDD2BXARS010
DIODE SILICON
SARS01-V1
D512
9JDD28R11FS40
DIODE SCHOTTKY
EC11FS4-TE12L
!
D514
9JDD2WXRU2AM0
DIODE SILICON
RU2AM-EIC
!
D515
9JDD28A10A200
DIODE SILICON
FCF10A20
!
D516
9JDD2LT001F50
DIODE SILICON
1F5-E
D517
9JDD97U01801B
DIODE,ZENER
MTZJ18B T-77
!
D518
9JDD97U06R81B
DIODE,ZENER
MTZJ6.8B T-77
!
D523
9JDD28A10A061
DIODE SCHOTTKY BARRIER
FCQS10A065
!
D524
9JDD97U02401B
DIODE,ZENER
MTZJ24B T-77
!
D525
9JDD97U03301B
DIODE,ZENER
MTZJ33B T-77
!
D526
9JDD28R11FS40
DIODE SCHOTTKY
EC11FS4-TE12L
D7001
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7002
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7003
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7004
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7005
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7006
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7007
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7008
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7009
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7010
9JDDGERMA1110
DIODE SILICON
MA111-(TX)
D7011
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7012
9JDD1VT001330
DIODE,SILICON
1SS133T-77
K3-5
