Sharp LC-22DV200E Service Manual

ELECTRICAL REPLACEMENT PARTS LIST
D7013
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7014
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7015
9JDD1VT001330
DIODE,SILICON
1SS133T-77
D7016
9JDD1VT001330
DIODE,SILICON
1SS133T-77
*** ICS ***
!
IC301
9JDI03SP20520
SOUND AMP 5W 2CH
LA42052-E
!
IC501
9JDI2BT0Y6760
VDSS=800V RON=2.1OHM
STR-Y6765
!
IC502
9JDI1KJ9A431A
VARIABLE SHUNT REGULATOR TAPE
KIA431A-AT
!
IC505
9JD000220002W
PHOTO COUPLER
PS2561AL1-1-V(W)
IC7001
9JDI1JF010080
1CH HALF-BRIDGE INVERTER IC
MP1008-ES-LF-Z
*** TRANSISTORS ***
Q505
9JDTAAA1504SY
TRANSISTOR SILICON
KTA1504S_Y_RTK
!
Q7001
9JDTJ3MTP2010
FET
ATP201-V-TL-H
Q7002
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7003
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7004
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
!
Q7005
9JDTJ3MTP2010
FET
ATP201-V-TL-H
Q7006
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7007
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7008
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7009
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
Q7010
9JDTCAA3875SY
TRANSISTOR SILICON
KTC3875S_Y_RTK
*** COILS ***
B304
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B305
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B306
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B307
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B307
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B308
9JD024HC13914
CORE,BEADS
HCB3216KF-391T20
B309
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B310
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B312
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B313
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B501
9JD024HT03564
CORE,BEADS
W4BRH3.5X6X1.0
B8101
9JD024HC51513
CORE,BEADS
FCM1608KF-151T06
B8102
9JD024HC51513
CORE,BEADS
FCM1608KF-151T06
B8103
9JD024HC51513
CORE,BEADS
FCM1608KF-151T06
B8104
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B8105
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B8106
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
B8107
9JD024HC51023
CORE,BEADS
FCM1608KF-102T02
!
L501
9JD029X000121
COIL,LINE FILTER
SS24H-K08240-CH
L503
9JD02167E220K
COIL
22 UH
L504
9JD02167E100K
COIL
10 UH
*** TRANSFORMERS ***
!
T501
9JD0481291594
TRANSFORMER,SWITCHING
81291594
!
T7001
9JD048137002R
TRANSFORMER,SWITCHING
8137002R
!
T7002
9JD048137002R
TRANSFORMER,SWITCHING
8137002R
*** JACKS ***
!
J301
9JD060R131024
HEADPHONE JACK
PJ-364H
!
J501
9JD064Q2A0004
JACK,AC
CCT2302-0721C
J8102
9JD060R411058
RCA JACK
RCA-341H(NI)-09
J8103
9JD060R431039
RCA JACK
RCA-228H(3)NI-02
J8104
9JD060R431040
RCA JACK
RCA-341H(2)NI-06
*** CONNECTORS ***
CD301
9JD06CH142102
CORD CONNECTOR
CH142102
CP501
9JD06977NM020
CONNECTOR PCB SIDE
127301123K2
CD7602
9JD06CH251204
CORD CONNECTOR
CH251204
CP7001
9JD069SJ20010
CONNECTOR PCB SIDE
C3502WR0-2P-HK-PBTHF
CP7002
9JD069SJ20010
CONNECTOR PCB SIDE
C3502WR0-2P-HK-PBTHF
CP7003
9JD069SJ20010
CONNECTOR PCB SIDE
C3502WR0-2P-HK-PBTHF
CP7004
9JD069SJ20010
CONNECTOR PCB SIDE
C3502WR0-2P-HK-PBTHF
CP8101
9JD06977NM020
CONNECTOR PCB SIDE
127301123K2
K3-6
