Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
219
LC-30HV4U
LC-30HV4D
DUNTKB401FE07
MAIN Unit (AVC System) (Continued)
DUNTKB493FE07 (LC-30HV4U)
DUNTKB493FE08 (LC-30HV4D)
POWER Unit (AVC System)
INTEGRATED CIRCUITS
IC701 VHiMR2920++-1 J MR2920 AQ
IC721 VHiHA17431U-1Y J HA17431UA-TL AE
IC1701 VHiPQ12DZ1U-1Y J PQ12DZ1U AG
IC1702 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1703 VHiFA3675F/-1 J FA3675F AR
IC1704 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1705 VHiPQ050DZ1-1Y J PQ050DZ01Z AE
IC1753 VHiPQ30RV11-1 J PQ30RV11 AF
TRANSISTORS
Q701 VS2SC3928AR-1Y J 2SC3928AR AB
Q702 VS2SC3928AR-1Y J 2SC3928AR AB
Q721 VSDTC114EKA-1Y J DTC114EKA AB
Q722 VSDTC114EKA-1Y J DTC114EKA AB
Q1701 VS2SA1530AR-1Y J 2SA1530AR AB
Q1702 VSDTC124EE/-1Y J DTC124EE AA
Q1703 VS2SB1132Q/-1Y J 2SB1132Q AC
Q1704 VSDTC114EKA-1Y J DTC114EKA AB
Q1705 VSDTA124EE/-1Y J DTA124EE AB
Q1706 VSDTC124EE/-1Y J DTC124EE AA
Q1707 VSSi4435DY+-1Y J SI4435DY+ AF
Q1708 VSSi4435DY+-1Y J SI4435DY+ AF
Q1756 VSDTC114EE/-1Y J DTC114EE AB
DIODES
D701 RH-DX0476CEZZ J Diode AG
D703 VHD05NU42//-1Y J Diode AD
D704 VHDD1FL20U/-1Y J Diode AC
D705 VHDD1FL20U/-1Y J Diode AC
D706 VHDHSU119//-1Y J Diode AB
D707 RH-EX1280CEZZY J Zener Diode, 16V AB
D708 RH-EX1241CEZZY J Zener Diode, 4.7V AB
D709 VHDHSU119//-1Y J Diode AB
D721 VHDD1FL20U/-1Y J Diode AC
D722 VHDD1FL20U/-1Y J Diode AC
D723 VHDSF30SC6+-1 J Diode AH
D724 VHDSF30SC6+-1 J Diode AH
D725 VHDD1FL20U/-1Y J Diode AC
D726 RH-EX1233CEZZY J Zener Diode, 3.6V AB
D727 RH-EX0747CEZZY J Zener Diode, 39V AB
D728 RH-EX0707CEZZY J Zener Diode, 6.6V AB
D730 RH-EX1259CEZZY J Zener Diode, 8.2V AB
D731 RH-EX1259CEZZY J Zener Diode, 8.2V AB
D1701 RH-EX1244CEZZY J Zener Diode AB
D1702 VHDHSU119//-1Y J Diode AB
D1703 VHDHSU119//-1Y J Diode AB
D1704 RH-EX1241CEZZY J Zener Diode, 4.7V AB
D1705 VHDSFPB74//2EY J Diode AD
D1706 VHDHSU119//-1Y J Diode AB
D1707 RH-EX1241CEZZY J Zener Diode, 4.7V AB
D1708 VHDSFPB74//2EY J Diode AD
D1709 VHDHSU119//-1Y J Diode AB
D1755 VHDHSU119//-1Y J Diode AB
D1756 VHDSFPB74//2EY J Diode AD
D1764 VHDHSU119//-1Y J Diode AB
D1766 VHDSFPB74//2EY J Diode AD
D1767 VHDSFPB74//2EY J Diode AD
D1768 VHDSFPB74//2EY J Diode AD
D1769 VHDSFPB74//2EY J Diode AD
å VA701 RH-VXA018WJZZ J Varistor (LC-30HV4U)
å VA701 RH-VX0044CEZZ J Varistor (LC-30HV4D)
PHOTOCOUPLER
å PC702 RH-FXA005WJZZY J PC123ZY8 AD
å PC703 RH-FXA005WJZZY J PC123ZY8 AD
å PC704 RH-FXA005WJZZY J PC123ZY8 AD
COILS
å L701 RCiLFA021WJZZ J Coil AF
R7216 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R7217 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R7224 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R7225 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R7237 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R7238 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7239 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R7240 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB601 RBLN-0061TAZZY J Ferrite Bead AD
FB602 RBLN-0061TAZZY J Ferrite Bead AD
FB803 RBLN-0061TAZZY J Ferrite Bead AD
FB7002 RBLN-0061TAZZY J Ferrite Bead AD
FB7009 RBLN-0061TAZZY J Ferrite Bead AD
P801 QPLGN0062CEZZY J Plug, 12-pin AE
P1504 QPLGN0060CEZZY J Plug, 10-pin AE
P1505 QPLGN0572FJZZY J Plug, 10-pin AE
P1506 QCNCMA082WJZZY J Plug, 15-pin AF
P1508 QPLGN0056CEZZY J Plug, 6-pin AD
P1801 QPLGN0546FJZZY J Plug, 9-pin AE
P1802 QPLGN0549FJZZY J Plug, 11-pin AE
P1803 QPLGN0548FJZZY J Plug, 12-pin AE
P1901 QPLGN1094CEZZ J Plug, 10-pin AF
SC1501 QSOCN0490FJZZY J Socket, 30-pin AF
SC1502 QSOCN0464FJZZY J Socket, 50-pin AH
SC1504 QSOCN0493FJZZY J Socket, 45-pin AG
LUG800 QLUGHA001WJZZY J Lug AD
LUG801 QLUGHA001WJZZY J Lug AD
LUG802 QLUGHA001WJZZY J Lug AD
LUG803 QLUGHA001WJZZY J Lug AD
TP805 QLUGP0110TAFWY J Lug AB
TP806 QLUGP0110TAFWY J Lug AB
TP810 QLUGP0110TAFWY J Lug AB
TP811 QLUGP0110TAFWY J Lug AB
TP812 QLUGP0110TAFWY J Lug AB
TP813 QLUGP0110TAFWY J Lug AB
TP814 QLUGP0110TAFWY J Lug AB
TP815 QLUGP0110TAFWY J Lug AB
TP816 QLUGP0110TAFWY J Lug AB
TP7003 QLUGP0110TAFWY J Lug AB
TP7004 QLUGP0110TAFWY J Lug AB
TP7005 QLUGP0110TAFWY J Lug AB
