Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
220
LC-30HV4U
LC-30HV4D
DUNTKB493FE07 (LC-30HV4U)
DUNTKB493FE08 (LC-30HV4D)
POWER Unit (AVC System) (Continued)
å L702 RCiLFA021WJZZ J Coil AF
L721 RCiLPA053WJZZ J Coil AD
L722 RCiLPA053WJZZ J Coil AD
L723 RCiLPA054WJZZ J Coil AD
L1701 RCiLPA112WJZZY J Coil AF
L1703 RCiLPA112WJZZY J Coil AF
TRANSFORMER
å T701 RTRNWA085WJZZ J Transformer AP
CAPACITORS
å C701 RC-FZ037SCEZZ J 0.22 AC275V Polypro Film AD
(LC-30HV4D)
å C702 RC-FZ037SCEZZ J 0.22 AC275V Polypro Film AD
å C703 RC-KZ0105GEZZ J 2200p AC250V Ceramic AD
å C704 RC-KZ0105GEZZ J 2200p AC250V Ceramic AD
å C705 RC-FZ037SCEZZ J 0.22 AC275V Polypro Film AD
C706 RC-EZA084WJZZ J 180 400V Electrolytic AM
C707 RC-KZA065WJZZ J 470p 2kV Ceramic AC
C708 VCEASH1EN107MY J 100 25V Electrolytic AC
C709 VCEAPF1HN475MY J 4.7 50V Electrolytic AC
C710 VCCCCY1HH101JY J 100p 50V Ceramic AA
C711 VCKYCY1HB472KY J 4700p 50V Ceramic AA
å C712 RC-KZ0103GEZZ J 1000p AC250V Ceramic AD
(LC-30HV4U)
å C712 RC-KZ0105GEZZ J 1000p AC250V Ceramic AD
(LC-30HV4D)
å C713 RC-KZ0103GEZZ J 1000p AC250V Ceramic AD
(LC-30HV4U)
å C713 RC-KZ0105GEZZ J 1000p AC250V Ceramic AD
(LC-30HV4D)
å C714 RC-KZ0105GEZZ J 1000p AC250V Ceramic AD
C715 VCKYTV1EB104KY J 0.1 25V Ceramic AB
(LC-30HV4U)
C721 VCEAPX1JN686MY J 68 63V Electrolytic AD
C722 VCEASK1VN337MY J 330 35V Electrolytic AE
C723 VCEASH1VN227MY J 220 35V Electrolytic AD
C724 RC-EZA088WJZZ J 820 25V Electrolytic AE
C725 RC-EZA088WJZZ J 820 25V Electrolytic AE
C726 RC-EZ1360CEZZ J 680 25V Electrolytic AD
C727 VCKYPA2HB472K+ J 4700p 500V Ceramic AB
C728 RC-EZ1076CEZZ J 3300 10V Electrolytic AE
C729 RC-EZ1076CEZZ J 3300 10V Electrolytic AE
C730 RC-EZ1075CEZZ J 3300 10V Electrolytic AF
C731 VCEASH1CN337MY J 330 16V Electrolytic AE
C732 VCKYTV1EB104KY J 0.1 25V Ceramic AB
C733 VCKYTV1CB105KY J 1 16V Ceramic AC
C1701 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1703 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1704 VCEAPF1CN107MY J 100 16V Electrolytic AD
C1705 VCKYCY1CF334ZY J 0.33 16V Ceramic AB
C1706 VCEAPF1CN107MY J 100 16V Electrolytic AD
C1707 VCEAPF1CN106MY J 10 16V Electrolytic AD
C1708 VCEASK1CN477MY J 470 16V Electrolytic AD
C1709 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1711 VCCCCY1HH101JY J 100p 50V Ceramic AA
C1712 VCKYCY1AB474KY J 0.47 10V Ceramic AC
C1713 VCKYTV1CB105KY J 1 16V Ceramic AC
C1714 VCKYTV1CB224KY J 0.22 16V Ceramic AB
C1715 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1716 VCKYCY1EB103KY J 0.01 25V Ceramic AA
C1717 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1718 VCKYTV1CB105KY J 1 16V Ceramic AC
C1719 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C1720 VCKYCY1HB222KY J 2200p 50V Ceramic AA
C1723 VCKYTV1CB105KY J 1 16V Ceramic AC
C1724 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C1725 VCAAPD1CJ396MY J 39 16V Electrolytic AF
C1726 VCAAPD0JJ127MY J 120 6.3V Electrolytic AF
C1727 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1729 VCAAPD1CJ396MY J 39 16V Electrolytic AF
C1730 VCAAPD0JJ127MY J 120 6.3V Electrolytic AF
C1731 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1733 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1735 VCEAPF1CN107MY J 100 16V Electrolytic AD
C1736 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1738 VCEAPF1CN107MY J 100 16V Electrolytic AD
C1739 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1740 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1741 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C1742 VCKYTV1CB105KY J 1 16V Ceramic AC
C1763 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1765 VCEAPF1CN107MY J 100 16V Electrolytic AD
RESISTORS
å R701 RR-HZ0122CEZZ J 470k 1/2W Solid AA
(LC-30HV4U)
R702 VRW-KQ3NC1R5K J 1.5 7W Cement AE
R705 VRN-VV3DBR22J J 0.22 2W Metal Film AB
R706 VRS-TQ2BD393FY J 39k 1/8W Metal Oxide AA
R707 VRS-TQ2BD272JY J 2.7k 1/8W Metal Oxide AB
R708 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R709 VRS-TQ2BD243FY J 24k 1/8W Metal Oxide AA
R710 VRS-TQ2BD104JY J 100k 1/8W Metal Oxide AA
R711 RR-HZ0048CEZZ J 3.9M 1/2W Solid AB
(LC-30HV4U)
R712 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R713 VRS-TQ2BD103JY J 10k 1/8W Metal Oxide AA
R714 VRS-TX2HF101JY J 100 1/2W Metal Oxide AA
å R721 RR-XZA002WJZZY J 10 1/4W Fuse Resistor AD
(RF732ETTD100J)
R722 VRS-TW2ED102JY J 1k 1/4W Metal Oxide AA
R723 VRS-TQ2BD223JY J 22k 1/8W Metal Oxide AA
R724 VRS-TQ2BD223JY J 22k 1/8W Metal Oxide AA
å R725 RR-XZA001WJZZY J 1 1/4W Fuse Resistor AD
(RF732ETTD1R03)
R726 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R727 VRS-CY1JF331JY J 330 1/16W Metal Oxide AA
R728 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R729 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R730 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R731 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R732 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R733 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R734 VRS-CY1JF561FY J 560 1/16W Metal Oxide AA
R735 VRS-CY1JF302FY J 3k 1/16W Metal Oxide AA
R736 VRS-CY1JF242FY J 2.4k 1/16W Metal Oxide AA
R737 VRS-TW2ED101JY J 100 1/4W Metal Oxide AA
R738 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R739 VRS-TW2ED391JY J 390 1/4W Metal Oxide AA
R1701 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1702 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R1703 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R1704 VRS-TW2ED101JY J 100 1/4W Metal Oxide AA
R1705 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R1706 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R1707 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R1708 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1709 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1710 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1711 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R1716 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1717 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1718 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1719 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1720 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1722 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R1724 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1725 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R1726 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1727 VRS-TW2ED120JY J 12 1/4W Metal Oxide AA
R1728 VRS-CY1JF272FY J 2.7k 1/16W Metal Oxide AA
R1729 VRS-CY1JF331FY J 330 1/16W Metal Oxide AA
R1730 VRS-CY1JF182FY J 1.8k 1/16W Metal Oxide AA
R1731 VRS-CY1JF123FY J 12k 1/16W Metal Oxide AA
R1732 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R1733 VRS-TW2ED120JY J 12 1/4W Metal Oxide AA
