Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
221
LC-30HV4U
LC-30HV4D
DUNTKB493FE07 (LC-30HV4U)
DUNTKB493FE08 (LC-30HV4D)
POWER Unit (AVC System) (Continued)
R1734 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R1735 VRS-CY1JF331FY J 330 1/16W Metal Oxide AA
R1736 VRS-CY1JF152FY J 1.5k 1/16W Metal Oxide AA
R1737 VRS-CY1JF473FY J 47k 1/16W Metal Oxide AA
R1738 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1739 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1741 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1742 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R1764 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R1786 VRS-CY1JF682FY J 6.8k 1/16W Metal Oxide AA
R1787 VRS-CY1JF152FY J 1.5k 1/16W Metal Oxide AA
R1789 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
SWITCH
å SW701 QSW-P0591CEZZ J MAIN POWER AQ
MISCELLANEOUS PARTS
å F701 QFS-D0008CEZZ J Fuse, 2A/250V AE
FH701 QFSHD1002CEZZ J Fuse Holder AA
FH702 QFSHD1002CEZZ J Fuse Holder AA
FB701 RBLN-0037CEZZY J Ferrite Bead AB
FB1701 RBLN-0210TAZZY J Ferrite Bead AB
FB1702 RBLN-0210TAZZY J Ferrite Bead AB
FB1703 RBLN-0210TAZZY J Ferrite Bead AB
FB1704 RBLN-0210TAZZY J Ferrite Bead AB
FB1705 RBLN-0210TAZZY J Ferrite Bead AB
FB1706 RBLN-0210TAZZY J Ferrite Bead AB
FB1707 RBLN-0210TAZZY J Ferrite Bead AB
FB1708 RBLN-0210TAZZY J Ferrite Bead AB
FB1709 RBLN-0210TAZZY J Ferrite Bead AB
FB1710 RBLN-0210TAZZY J Ferrite Bead AB
FB1711 RBLN-0210TAZZY J Ferrite Bead AB
FB1712 RBLN-0210TAZZY J Ferrite Bead AB
FB1713 RBLN-0210TAZZY J Ferrite Bead AB
FB1714 RBLN-0210TAZZY J Ferrite Bead AB
FB1715 RBLN-0210TAZZY J Ferrite Bead AB
FB1716 RBLN-0210TAZZY J Ferrite Bead AB
FB1717 RBLN-0210TAZZY J Ferrite Bead AB
J1751 QJAKCA005WJZZ J DC OUTPUT Terminal AE
P704 QTiPM0083CEZZ J Tip(LC-30HV4U) AB
P1701 QPLGN0550FJZZY J Plug, 13-pin AF
P1702 QPLGN1278GEZZ J Plug, 12-pin AC
P1703 QPLGN1178GEZZ J Plug, 11-pin AC
å SC701 QSOCAA003WJZZ J AC INPUT Terminal AD
(LC-30HV4U)
å SC701 QSOCA0021TAZZ J AC INPUT Terminal
(LC-30HV4D)
LUG701 QLUGHA001WJZZY J Lug AD
LUG702 QLUGHA001WJZZY J Lug AD
LUG703 QLUGHA001WJZZY J Lug AD
LUG704 QLUGHA002WJZZ J Lug AB
LUG705 QLUGHA002WJZZ J Lug AB
PRD5701 PRDAR3203CEFW J Heat Sink, for IC1753 AD
RDA701 PRDARA047WJFW J Heat Sink, for IC701 AF
RDA721 PRDAR3203CEFW J Heat Sink, for D723 AD
RDA722 PRDARA047WJFW J Heat Sink, for D724 AF
QCNW-A825WJZZ J Connecting Cord AK
(MAIN-POW)
QCNW-A826WJZZ J Connecting Cord AG
(MAIN-POW)
QCNW-A846WJZZ J Connecting Cord AH
(POW-PC I/F)
XBPSD30P10JS0 J Screw, x2 AA
DUNTKB593DE30 (LC-30HV4U)
DUNTKB593DE31 (LC-30HV4D)
FRONT Unit (AVC System)
INTEGRATED CIRCUITS
IC2401 VHi24LC21++5ES J 24LC21
IC2402 VHiVHCT14AF-1Y J TC74VHCT14AF AD
TRANSISTORS
Q2401 VS2SC2735//1EY J 2SC2735 AC
Q2402 VS2SC2735//1EY J 2SC2735 AC
Q2403 VS2SC2735//1EY J 2SC2735 AC
Q2404 VS2SC3928AR-1Y J 2SC3928AR AB
Q2405 VS2SC3928AR-1Y J 2SC3928AR AB
Q2406 VSDTC144EE/-1Y J DTC144EE AA
Q2407 VSDTC144EE/-1Y J DTC144EE AA
Q2408 VSDTC144EE/-1Y J DTC144EE AA
DIODES
D2401 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D2402 VHDMA3120WA-1Y J Diode AD
D2403 VHDMA3120WA-1Y J Diode AD
D2404 VHDMA3120WA-1Y J Diode AD
D2405 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D2406 RH-EX1247CEZZY J Zener Diode, 5.6V AB
D2407 RH-EX1271CEZZY J Zener Diode AB
D2408 RH-EX1271CEZZY J Zener Diode AB
D2409 VHDDAN202K/-1Y J Diode AB
D2410 RH-PX0421CEZZY J STANDBY/ON Indicator AD
FILTERS AND COILS
FL2401 RFiLN0003TAZZY J Filter AD
FL2402 RFiLN0003TAZZY J Filter AD
FL2403 RFiLN0003TAZZY J Filter AD
FL2412 RFiLN0017TAZZY J Filter AC
FL2413 RFiLN0017TAZZY J Filter AC
FL2414 RFiLN0017TAZZY J Filter AC
L2401 VPD9M100J1R7NY J Peaking 10µH AC
CAPACITORS
C2401 VCEAPF0JW107MY J 100 6.3V Electrolytic AC
C2402 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2403 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2404 VCEAPF1CN476MY J 47 16V Electrolytic AD
C2405 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2406 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2407 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2408 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2409 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2410 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2411 VCKYTV1CB105KY J 1 16V Ceramic AC
C2412 VCKYTV1CB105KY J 1 16V Ceramic AC
C2414 VCCCCY1HH100DY J 10p 50V Ceramic AA
C2415 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2416 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2417 VCCCCY1HH100DY J 10p 50V Ceramic AA
C2418 RC-KZ0069TAZZY J 10 16V Ceramic AE
C2420 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2421 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2422 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2423 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2428 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2429 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2430 VCCCCY1HH560JY J 56p 50V Ceramic AB
C2431 VCCCCY1HH560JY J 56p 50V Ceramic AB
C2432 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2433 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2434 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2435 VCCCCY1HH101JY J 100p 50V Ceramic AA
C2436 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2437 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2438 VCEAPF1CN476MY J 47 16V Electrolytic AD
C2439 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2440 VCKYTV1CB105KY J 1 16V Ceramic AC
C2441 VCKYTV1CB105KY J 1 16V Ceramic AC
