Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
222
LC-30HV4U
LC-30HV4D
DUNTKB593DE30 (LC-30HV4U)
DUNTKB593DE31 (LC-30HV4D)
FRONT Unit (AVC System) (Continued)
C2442 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2443 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2444 VCCCCY1HH560JY J 56p 50V Ceramic AB
C2445 VCCCCY1HH560JY J 56p 50V Ceramic AB
RESISTORS
R2401 VRS-TQ2BD561JY J 560 1/8W Metal Oxide AA
R2402 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2403 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2404 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2405 VRS-TQ2BD561JY J 560 1/8W Metal Oxide AA
R2406 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2407 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2408 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2409 VRS-TQ2BD561JY J 560 1/8W Metal Oxide AA
R2410 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2411 VRS-CY1JF562JY J 5.6k 1/16W Metal Oxide AA
R2412 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2413 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2414 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2415 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2416 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2417 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2418 VRS-CY1JF473JY J 47k 1/16W Metal Oxide AA
R2422 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2423 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2424 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2425 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2427 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2428 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2429 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2430 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2431 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2432 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2433 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2434 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2435 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2436 VRS-CY1JF274JY J 270k 1/16W Metal Oxide AA
R2437 VRS-TW2ED750JY J 75 1/4W Metal Oxide AA
R2439 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2440 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2441 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2442 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2443 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2444 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2445 VRS-TW2ED4R7JY J 4.7 1/4W Metal Oxide AB
R2446 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2447 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2448 VRS-TW2ED4R7JY J 4.7 1/4W Metal Oxide AB
R2449 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2450 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2451 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2453 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2454 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R2457 VRS-TX2HF220JY J 22 1/2W Metal Oxide AB
R2458 VRS-TX2HF220JY J 22 1/2W Metal Oxide AB
R2459 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2460 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2461 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R2462 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2464 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2465 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2466 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2467 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2468 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2469 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2470 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R2471 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2472 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2473 VRS-CY1JF182JY J 1.8k 1/16W Metal Oxide AA
R2474 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2475 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2476 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2477 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2478 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
SWITCH
SW2401QSW-K0069CEZZ J Switch, Clear AB
MISCELLANEOUS PARTS
FB2401 RBLN-0076TAZZY J Ferrite Bead AC
FB2402 RBLN-0060TAZZY J Ferrite Bead AB
FB2403 RBLN-0060TAZZY J Ferrite Bead AB
FB2404 RBLN-0060TAZZY J Ferrite Bead AB
FB2405 RBLN-0062TAZZY J Ferrite Bead AB
FB2406 RBLN-0062TAZZY J Ferrite Bead AB
FB2408 RBLN-0062TAZZY J Ferrite Bead AB
FB2410 RBLN-0062TAZZY J Ferrite Bead AB
FB2411 RBLN-0062TAZZY J Ferrite Bead AB
FB2412 RBLN-0062TAZZY J Ferrite Bead AB
J2401 QSOCD0439CEZZ J Input 4 Terminal(S-VIDEO) AF
J2402 QJAKJ0080CEZZ J Headphone AF
J2403 QJAKJ0080CEZZ J PC Input Terminal(Audio) AF
J2404 QJAKGA021WJZZ J Input 4 Terminal(A/V) AF
P2401 QPLGN1280GEZZ J Plug, 12-pin AC
P2402 QPLGN0437FJZZ J Plug, 26-pin AD
SC2401 QSOCN0344FJZZ J PC Input Terminal AM
(Analog RGB)
LUG2401 QLUGHA001WJZZY J Lug AD
LUG2402 QLUGHA001WJZZY J Lug AD
QCNW-A833WJZZ J Connecting Cord(AV-Front) AE
QCNW-A838WJZZ J Connecting Cord AK
(Front-PC I/F)
