Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
237
LC-30HV4U
LC-30HV4D
DUNTKA658FE13 (LC-30HV4U)
DUNTKA658FE12 (LC-30HV4D)
LCD CONTROL Unit (Display) (Continued)
R4528 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4529 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4530 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4531 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4532 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4533 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4534 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4535 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4536 VRS-CB1JF000JY J 0 1/16W Metal Oxide AC
R4552 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4555 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4565 VRS-CB1JF102JY J 1k 1/16W Metal Oxide AA
R4570 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4576 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4579 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4581 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4582 VRS-CB1JF102JY J 1k 1/16W Metal Oxide AA
R4584 VRS-CB1JF330JY J 33 1/16W Metal Oxide AC
R4585 VRS-CB1JF330JY J 33 1/16W Metal Oxide AC
R4586 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4587 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R4590 VRS-CY1JF330JY J 33 1/16W Metal Oxide AA
R4593 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4602 VRS-CB1JF330JY J 33 1/16W Metal Oxide AC
R4607 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R4611 VRS-TV1JD330JY J 33 1/16W Metal Oxide AA
R4613 VRS-CA1JF330JY J 33 1/16W Metal Oxide AC
R4615 VRS-CY1JF470JY J 47 1/16W Metal Oxide AA
R4618 RBLN-0076TAZZ J Ferrite Bead AC
R4620 VRS-CA1JF330JY J 33 1/16W Metal Oxide AC
R4624 VRS-CY1JF393FY J 39k 1/16W Metal Oxide AA
R4627 VRS-CY1JF392JY J 3.9k 1/16W Metal Oxide AA
R4631 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R4632 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4633 VRS-CY1JF154FY J 150k 1/16W Metal Oxide AA
R4634 VRS-CY1JF393FY J 39k 1/16W Metal Oxide AA
R4635 RR-NZ0027TAZZY J
0.056 1/4W Metal Film AC
R4636 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4637 VRS-CY1JF623FY J 62k 1/16W Metal Oxide AA
R4645 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4646 VRS-CY1JF105FY J 1M 1/16W Metal Oxide AA
R4647 VRS-CY1JF105FY J 1M 1/16W Metal Oxide AA
R4649 VRS-CY1JF105FY J 1M 1/16W Metal Oxide AA
R4650 VRS-TW2ED270JY J 27 1/4W Metal Oxide AA
R4651 VRS-TV1JD223JY J 22k 1/16W Metal Oxide AA
R4652 VRS-TX2HF472JY J 4.7k 1/2W Metal Oxide AB
R4653 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R4654 VRS-CY1JF222JY J 2.2k 1/16W Metal Oxide AA
R4655 VRS-TX2HF682JY J 6.8k 1/2W Metal Oxide AB
R4656 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4657 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R4658 VRS-TW2ED821JY J 820 1/4W Metal Oxide AB
R4659 VRS-TV1JD222JY J 2.2k 1/16W Metal Oxide AA
R4660 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4661 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R4676 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4677 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4678 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4679 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4680 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4681 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4682 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4683 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4684 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4685 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4686 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4687 VRS-CB1JF101JY J 100 1/16W Metal Oxide AA
R4691 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4703 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4704 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4707 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4709 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4711 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4712 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4713 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4715 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4717 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4718 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4719 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4726 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4727 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4732 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4733 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4734 VRS-CB1JF102JY J 1k 1/16W Metal Oxide AA
R4738 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4739 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4902 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4903 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4904 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4905 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4908 VRK-CD1JJ220JY J 22 1/16W Metal Comp. AC
R4909 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4910 VRS-CY1JF220JY J 22 1/16W Metal Oxide AA
R4911 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4912 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4914 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4917 VRS-CY1JF472JY J 4.7k 1/16W Metal Oxide AA
R4919 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4925 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4926 VRS-CA1JF101JY J 100 1/16W Metal Oxide AA
R4930 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4931 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R4933 VRS-CB1JF330JY J 33 1/16W Metal Oxide AC
R4934 VRS-CB1JF102JY J 1k 1/16W Metal Oxide AA
R4935 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4936 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R4956 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R4965 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
FB4505 RBLN-0252TAZZY J Ferrite Bead AA
FB4507 RBLN-0252TAZZY J Ferrite Bead AA
FB4511 RBLN-0252TAZZY J Ferrite Bead AA
FB4601 RBLN-0252TAZZY J Ferrite Bead AA
FB4906 RBLN-A005WJZZY J Ferrite Bead AA
FB4907 RBLN-A005WJZZY J Ferrite Bead AA
FB4909 RBLN-A005WJZZY J Ferrite Bead AA
FB4911 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
P4101 QPLGN0177FJZZY J Plug, 5-pin(PC) AC
P4505 QLUGHA001WJZZY J Lug AD
P4506 QLUGHA001WJZZY J Lug AD
P4507 QLUGHA001WJZZY J Lug AD
P4508 QLUGHA001WJZZY J Lug AD
P4509 QLUGHA001WJZZY J Lug AD
P4551 QPLGN0060CEZZY J Plug, 10-pin AE
P4701 QPLGN1074TAZZY J Plug, 10-pin AD
P4901 QCNCM0054CEZZ J Connector, 80-pin AT
P4902 QPLGN1074TAZZY J Plug, 10-pin AD
SC4101 QSOCN0488FJZZY J Socket, 22-pin(MC) AE
SC4501 QSOCN0687FJZZY J Socket, 50-pin(SCN2) AF
SC4502 QSOCN0688FJZZY J Socket, 53-pin(SCN1) AF
SC4503 QSOCN0687FJZZY J Socket, 50-pin(SCN4) AF
SC4504 QSOCN0688FJZZY J Socket, 53-pin(SCN3) AF
SC4551 QSOCN0684FJZZY J Socket, 30-pin(GD) AF
QCNW-A184WJZZ J Connecting Cord AG
