Sharp LC-30HV4U - Page 238

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
238
LC-30HV4U
LC-30HV4D
DKEYHB797FE11 (LC-30HV4U)
DKEYHB797FE12 (LC-30HV4D)
MAIN Unit (Display)
INTEGRATED CIRCUITS
IC2001 RH-iXA541WJN2Q J I.C. BD
IC2002 VHiPST529DM-1Y J PST529DMT AE
IC2003 VHiBR24C08F-1Y J BR24C08F-E2 AF
IC2005 VHiNJM2904M-1Y J NJM2904M AE
IC2006 VHiNJM2904M-1Y J NJM2904M AE
IC2007 VHiTC4066BF1EY J TC4066BF AE
IC2101 VHiAN8005M/-1Y J AN8005M AD
IC2102 VHiPQ20WZ11-1Y J PQ20WZ1U AF
IC2104 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC2105 VHiPQ1CZ21H-1Y J PQ1CZ21H2ZP AH
IC2203 VHiHN24128F-1Y J HN58X24128FPI AP
IC2204 VHi24LC21++8EY J 24LC21
IC2205 VHiTC7W34U/-1Y J TC7W34FU AE
Note: When replace the following parts, PWB replacement
correspondence.
IC2201 — – TMDS Receiver —
IC2202 — – KEY —
TRANSISTORS
Q2003 VS2SC3928AR-1Y J 2SC3928AR AB
Q2004 VSNDS355AN/-1Y J NDS355AN AE
Q2005 VSNDS355AN/-1Y J NDS355AN AE
Q2006 VS2SA1530AR-1Y J 2SA1530AR AB
Q2007 VSDTC114EE/-1Y J DTC114EE AB
Q2008 VSDTA114EE/-1Y J DTA114EE AB
Q2013 VSDTC114EE/-1Y J DTC114EE AB
Q2014 VSDTA114EE/-1Y J DTA114EE AB
Q2015 VSDTC114EE/-1Y J DTC114EE AB
Q2101 VSDTA114EE/-1Y J DTA114EE AB
Q2102 VSDTC114EE/-1Y J DTC114EE AB
Q2103 VSDTA114EE/-1Y J DTA114EE AB
Q2104 VSDTC114EE/-1Y J DTC114EE AB
Q2105 VS2SC3928AR-1Y J 2SC3928AR AB
Q2106 VS2SC3928AR-1Y J 2SC3928AR AB
Q2203 VSNDS355AN/-1Y J NDS355AN AE
Q2204 VSNDS355AN/-1Y J NDS355AN AE
Q2205 VSDTA114EE/-1Y J DTA114EE AB
Q2206 VSDTC114EE/-1Y J DTC114EE AB
Q2207 VS2SA1530AR-1Y J 2SA1530AR AB
Q2208 VSDTC114EE/-1Y J DTC114EE AB
Q2209 VSDTC114EE/-1Y J DTC114EE AB
Q2210 VS2SA1530AR-1Y J 2SA1530AR AB
Q2211 VSDTC114EE/-1Y J DTC114EE AB
Q2212 VSDTA114EE/-1Y J DTA114EE AB
Q2213 VSDTC114EE/-1Y J DTC114EE AB
Q2214 VSDTA114EE/-1Y J DTA114EE AB
Q2215 VSDTC114EE/-1Y J DTC114EE AB
Q2216 VSDTA114EE/-1Y J DTA114EE AB
DIODES
D2001 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2002 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2003 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2004 RH-EX1249CEZZY J Zener Diode, 6.2V AB
D2101 VHDHSU119//-1Y J Diode AB
D2103 VHDSFPB74//2EY J Diode AD
D2104 VHDSFPB74//2EY J Diode AD
D2201 VHDDA221///-1Y J Diode AB
D2202 VHDDAN222//-1Y J Diode AA
D2203 VHDDA221///-1Y J Diode AB
D2204 VHDHSU119//-1Y J Diode AB
D2210 VHDHSU119//-1Y J Diode AB
TH2001 VHHM1103J03-1Y J Thermistor AC
PACKAGED CIRCUIT
X2201 RCRSZ0093CEZZY J Crystal AM
FILTERS AND COILS
CF2001 RFiLZ0169TAZZY J Ceramic Filter AD
FL2201 RFiLNA022WJZZY J Filter AE
FL2202 RFiLNA022WJZZY J Filter AE
FL2203 RFiLNA022WJZZY J Filter AE
FL2204 RFiLNA022WJZZY J Filter AE
FL2205 RFiLNA022WJZZY J Filter AE
FL2206 RFiLNA022WJZZY J Filter AE
FL2207 RFiLNA022WJZZY J Filter AE
FL2208 RFiLNA022WJZZY J Filter AE
FL2209 RFiLNA022WJZZY J Filter AE
FL2210 RFiLNA022WJZZY J Filter AE
FL2211 RFiLNA022WJZZY J Filter AE
FL2212 RFiLNA022WJZZY J Filter AE
FL2213 RFiLNA022WJZZY J Filter AE
FL2214 RFiLNA022WJZZY J Filter AE
FL2215 RFiLNA029WJZZY J Filter
L2103 RCiLP0422CEZZY J Coil AF
L2104 RCiLP0422CEZZY J Coil AF
CAPACITORS
C2001 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2002 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2003 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2004 VCKYCY1HB102KY J 1000p 50V Ceramic AA
C2006 VCEAPF0JN107MY J 100 6.3V Electrolytic AD
C2007 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2008 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2009 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2010 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2011 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2012 VCEAPF1CN476MY J 47 16V Electrolytic AD
C2013 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2014 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2016 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2017 VCKYCY1HB103KY J 0.01 50V Ceramic AA
C2019 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2101 VCEAPF1CN107MY J 100 16V Electrolytic AD
C2102 VCEAPF1CN226MY J 22 16V Electrolytic AD
C2103 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2104 VCEASK1CN107MY J 100 16V Electrolytic AC
C2106 VCEASK1CN337MY J 330 16V Electrolytic AD
C2107 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2111 VCEASK1CN227MY J 220 16V Electrolytic AC
C2112 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2113 VCEASK1CN477MY J 470 16V Electrolytic AD
C2114 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2115 VCEASK1CN477MY J 470 16V Electrolytic AD
C2116 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2117 VCEASK1CN477MY J 470 16V Electrolytic AD
C2118 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2119 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2120 VCEASK1CN107MY J 100 16V Electrolytic AC
C2121 VCEAPF1CN106MY J 10 16V Electrolytic AD
C2122 VCEAPF1CN106MY J 10 16V Electrolytic AD
C2123 VCEAPF1CN106MY J 10 16V Electrolytic AD
C2124 VCEAPF1CN106MY J 10 16V Electrolytic AD
C2201 VCEAPF1CN476MY J 47 16V Electrolytic AD
C2202 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2203 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2204 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2205 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2206 VCAAPC0JJ336MY J 33 6.3V Electrolytic AF
C2207 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2208 VCKYCY1HB331KY J 330p 50V Ceramic AA
C2209 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2211 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2212 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2216 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
C2217 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2218 VCCCCY1HH470JY J 47p 50V Ceramic AA
C2219 VCEAPF0JN226MY J 22 6.3V Electrolytic AD
C2220 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2221 VCAAPC0JJ336MY J 33 6.3V Electrolytic AF
C2222 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C2223 VCKYCY1HB331KY J 330p 50V Ceramic AA
C2224 VCCCCY1HH820JY J 82p 50V Ceramic AA
C2225 VCAAPC0JJ336MY J 33 6.3V Electrolytic AF
