Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
243
LC-30HV4U
LC-30HV4D
DUNTKB799DE02 (LC-30HV4U)
DUNTKB799DE03 (LC-30HV4D)
INVERTER-1 Unit (Display)
TRANSISTORS
Q6551 VS2SC5707++-1Y J 2SC5707++ AE
Q6552 VS2SC5707++-1Y J 2SC5707++ AE
Q6553 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6554 VS2SC5707++-1Y J 2SC5707++ AE
Q6555 VS2SC5707++-1Y J 2SC5707++ AE
Q6556 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6557 VS2SC5707++-1Y J 2SC5707++ AE
Q6558 VS2SC5707++-1Y J 2SC5707++ AE
Q6559 VS2SA1037KQ-1Y J 2SA1037KQ AA
COILS
L6551 RCiLPA034WJZZ J Coil AD
L6553 RCiLPA034WJZZ J Coil AD
L6555 RCiLPA034WJZZ J Coil AD
TRANSFORMERS
å T6551 RTRNZA007WJZZQ J Transformer AM
å T6552 RTRNZA007WJZZQ J Transformer AM
å T6553 RTRNZA007WJZZQ J Transformer AM
å T6554 RTRNZA007WJZZQ J Transformer AM
å T6555 RTRNZA007WJZZQ J Transformer AM
å T6556 RTRNZA007WJZZQ J Transformer AM
CAPACITORS
C6555 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6556 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6557 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6563 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6564 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6565 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6571 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6572 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6573 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6602 RC-FZA037WJZZ J 0.18 250V Film AE
C6604 RC-FZA037WJZZ J 0.18 250V Film AE
C6606 RC-FZA037WJZZ J 0.18 250V Film AE
RESISTORS
R6551 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6552 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6553 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6554 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6555 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6556 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6557 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6558 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6559 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6560 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6561 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6562 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
å F6551 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
å F6552 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
å F6553 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
FH6551 QFSHD1002CEZZ J Fuse Holder AA
FH6552 QFSHD1002CEZZ J Fuse Holder AA
FH6553 QFSHD1002CEZZ J Fuse Holder AA
FH6554 QFSHD1002CEZZ J Fuse Holder AA
FH6555 QFSHD1002CEZZ J Fuse Holder AA
FH6556 QFSHD1002CEZZ J Fuse Holder AA
P6551 QPLGN0155FJZZY J Plug, 3-pin(LA) AE
P6553 QPLGN0155FJZZY J Plug, 3-pin(LB) AE
P6555 QPLGN0155FJZZY J Plug, 3-pin(LC) AE
P6557 QPLGNA059WJZZ J Plug, 5-pin(PG) AC
P6565 QLUGHA001WJZZY J Lug AD
P6566 QLUGHA001WJZZY J Lug AD
P6567 QLUGHA001WJZZY J Lug AD
DUNTKB800DE02 (LC-30HV4U)
DUNTKB800DE03 (LC-30HV4D)
INVERTER-2 Unit (Display)
TRANSISTORS
Q6560 VS2SC5707++-1Y J 2SC5707++ AE
Q6561 VS2SC5707++-1Y J 2SC5707++ AE
Q6562 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6563 VS2SC5707++-1Y J 2SC5707++ AE
Q6564 VS2SC5707++-1Y J 2SC5707++ AE
Q6565 VS2SA1037KQ-1Y J 2SA1037KQ AA
Q6566 VS2SC5707++-1Y J 2SC5707++ AE
Q6567 VS2SC5707++-1Y J 2SC5707++ AE
Q6568 VS2SA1037KQ-1Y J 2SA1037KQ AA
COILS
L6557 RCiLPA034WJZZ J Coil AD
L6559 RCiLPA034WJZZ J Coil AD
L6561 RCiLPA034WJZZ J Coil AD
TRANSFORMERS
å T6557 RTRNZA007WJZZQ J Transformer AM
å T6558 RTRNZA007WJZZQ J Transformer AM
å T6559 RTRNZA007WJZZQ J Transformer AM
å T6560 RTRNZA007WJZZQ J Transformer AM
å T6561 RTRNZA007WJZZQ J Transformer AM
å T6562 RTRNZA007WJZZQ J Transformer AM
CAPACITORS
C6579 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6580 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6581 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6587 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6588 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6589 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6595 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6596 VCKYCY1CB333KY J 0.033 16V Ceramic AA
C6597 RC-EZA010WJZZ J 1000 16V Electrolytic AD
C6608 RC-FZA037WJZZ J 0.18 250V Film AE
C6610 RC-FZA037WJZZ J 0.18 250V Film AE
C6612 RC-FZA037WJZZ J 0.18 250V Film AE
RESISTORS
R6563 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6564 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6565 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6566 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6567 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6568 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6569 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6570 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R6571 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6572 VRS-TW2ED222JY J 2.2k 1/4W Metal Oxide AA
R6573 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R6574 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
å F6554 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
å F6555 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
å F6556 QFS-D0009CEZZ J Fuse, 2.5A/250V AE
FH6557 QFSHD1002CEZZ J Fuse Holder AA
FH6558 QFSHD1002CEZZ J Fuse Holder AA
FH6559 QFSHD1002CEZZ J Fuse Holder AA
FH6560 QFSHD1002CEZZ J Fuse Holder AA
FH6561 QFSHD1002CEZZ J Fuse Holder AA
FH6562 QFSHD1002CEZZ J Fuse Holder AA
P6558 QPLGN0155FJZZY J Plug, 3-pin(LD) AE
P6560 QPLGN0155FJZZY J Plug, 3-pin(LE) AE
P6562 QPLGN0155FJZZY J Plug, 3-pin(LF) AE
P6564 QPLGNA059WJZZ J Plug, 5-pin(PH) AC
P6568 QLUGHA001WJZZY J Lug AD
P6569 QLUGHA001WJZZY J Lug AD
