Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
244
LC-30HV4U
LC-30HV4D
DIODES
D130 RH-EX0879CEZZY J Zener Diode, 12V AD
D131 RH-EX0879CEZZY J Zener Diode, 12V AD
RESISTORS
R130 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R131 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R132 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R133 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
SWITCHES
SW130 QSW-K0095CEZZ J Switch, VOL-DOWN AB
SW131 QSW-K0095CEZZ J Switch, VOL-UP AB
SW132 QSW-K0095CEZZ J Switch, CH-DOWN AB
SW133 QSW-K0095CEZZ J Switch, CH-UP AB
SW134 QSW-K0095CEZZ J Switch, INPUT AB
SW135 QSW-K0095CEZZ J Switch, POWER AB
SW136 QSW-P0591CEZZ J Switch, MAIN POWER AQ
MISCELLANEOUS PARTS
P130 QPLGN0364TAZZY J Plug, 3-pin(KK) AC
P131 QPLGNA007WJZZ J Plug, 5-pin(AA) AE
DUNTKB801DE02 (LC-30HV4U)
DUNTKB801DE03 (LC-30HV4D)
INVERTER-GND Unit (Display)
DUNTKB802DE02 (LC-30HV4U)
DUNTKB802DE03 (LC-30HV4D)
OPERATION Unit (Display)
TRANSISTORS
Q6901 VSUPA606T//-1Y J UPA606T AD
Q6902 VSUPA606T//-1Y J UPA606T AD
Q6903 VSUPA606T//-1Y J UPA606T AD
Q6904 VSUPA606T//-1Y J UPA606T AD
Q6905 VSUPA606T//-1Y J UPA606T AD
Q6906 VSUPA606T//-1Y J UPA606T AD
DIODES
D6901 VHDiMN10///-1Y J Diode AB
D6902 VHDiMN10///-1Y J Diode AB
D6903 VHDiMN10///-1Y J Diode AB
D6904 VHDiMN10///-1Y J Diode AB
D6905 VHDiMN10///-1Y J Diode AB
D6906 VHDiMN10///-1Y J Diode AB
D6907 VHDiMN10///-1Y J Diode AB
D6908 VHDiMN10///-1Y J Diode AB
CAPACITORS
C6901 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6902 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6903 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6904 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6905 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6906 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6907 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6908 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6909 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6910 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6911 VCKYTV1EB474KY J 0.47 25V Ceramic AC
C6912 VCKYTV1EB474KY J 0.47 25V Ceramic AC
RESISTORS
R6901 VRS-CA1JF272JY J 2.7k 1/16W Metal Oxide AA
R6902 VRS-CB1JF272JY J 2.7k 1/16W Metal Oxide AA
R6903 VRS-CA1JF272JY J 2.7k 1/16W Metal Oxide AA
R6904 VRS-CB1JF272JY J 2.7k 1/16W Metal Oxide AA
R6905 VRS-CA1JF394JY J 390k 1/16W Metal Oxide AA
R6906 VRS-CB1JF394JY J 390k 1/16W Metal Oxide AA
R6907 VRS-CB1JF394JY J 390k 1/16W Metal Oxide AA
R6908 VRS-CA1JF394JY J 390k 1/16W Metal Oxide AA
R6909 VRS-CB1JF562JY J 5.6k 1/16W Metal Oxide AC
R6910 VRS-CA1JF562JY J 5.6k 1/16W Metal Oxide AA
R6911 VRS-CB1JF562JY J 5.6k 1/16W Metal Oxide AC
R6912 VRS-CA1JF562JY J 5.6k 1/16W Metal Oxide AA
R6913 VRS-CY1JF563JY J 56k 1/16W Metal Oxide AA
R6914 VRS-TW2ED000JY J 0 1/4W Metal Oxide AB
MISCELLANEOUS PARTS
P6901 QPLGN0155FJZZY J Plug, 3-pin(GA) AE
P6902 QPLGN0155FJZZY J Plug, 3-pin(GB) AE
P6903 QPLGN0155FJZZY J Plug, 3-pin(GC) AE
P6904 QPLGN0155FJZZY J Plug, 3-pin(GD) AE
P6905 QPLGN0155FJZZY J Plug, 3-pin(GE) AE
P6906 QPLGN0155FJZZY J Plug, 3-pin(GF) AE
P6907 QPLGN0364TAZZY J Plug, 3-pin(MD) AC
P6908 QLUGHA001WJZZY J Lug AD
P6909 QLUGHA001WJZZY J Lug AD
